3774-4. Interior Equipment
4
Interior Features
The overhead lights turn on when any of the following operations is
done with the overhead light switch in the DOOR position and the igni-
tion switched off. • Turn on for about 30 seconds wh en the driver’s door is unlocked.
• Turn on for about 15 seconds w hen a door is opened with a key left
in the vehicle and then the door is closed.
• Turn on for about 5 seconds when a door is opened from the out -
side with a key bei ng carried and then t he door is closed.
The overhead lights turn on for about 15 seconds when the ignit ion is
switched off with the overhead light switch in the DOOR positio n.
The overhead lights turn off immediately in the following cases :
• The ignition is switched on and all doors are closed.
• The driver’s door is locked.
● Battery saver
If any door is left open with the overhead light switch in the DOOR position,
or the trunk lid is left open, the overhead light or trunk light turns off after
about 30 minutes to prevent battery depletion.
● To prevent battery depletion, if the interior lights remain turned on (the inte-
rior light switch is in the ON position or an interior light is turned on by press-
ing the lens of the interior light), they turn off automaticall y under the
following conditions:
• No operations are done for about 30 minutes after the ignition is switched
off.
• When the LOCK button on the key is pressed after the ignition is switched
off (interior lights turn off a few seconds).
In addition, if the following operations are performed after tu rning the inte-
rior lights off, they will turn on again.
• The ignition is switched to a position other than OFF.
• A door is opened.
• A door is unlocked.
● The operation of the illuminated entry system can be changed.
Refer to Customizable Features on P. 555.
Illuminated Entry System

378
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-4. Interior Equipment
Accessor y Socket
Only use genuine Toyota accessories or the equivalent requiring no
greater than 120 W (DC 12 V, 10 A).
The ignition must be s witched to ACC or ON.
Ty p e AType B
NOTICE
●To prevent accessory socket damage or electrical failure, pay a ttention to
the following:
• Do not use accessories that require more than 120 W (DC 12 V, 10 A).
• Do not use accessories that are not genuine Toyota accessories or the
equivalent.
• Close the cover when the accessory socket is not in use to pre vent for-
eign objects and liquids from getting into the accessory socket .
• Correctly insert the plug into the accessory socket.
• Do not insert the cigarette lighter into the accessory socket.
● Noise may occur on the audio playback depending on the device con-
nected to the accessory socket.
● Depending on the device connected to the accessory socket, the vehicle’s
electrical system may be affected, which could cause the warning light to
illuminate. Disconnect the connected device and make sure that the prob-
lem is resolved. If the problem is resolved, disconnect the device from the
socket and switch the ignition off. If the problem is not resol ved, consult
your Toyota dealer.
● To prevent discharging of the battery, do not use the socket for long peri-
ods with the engine off or idling.

379
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-4. Interior Equipment
4
Interior Features
Cup Holder
WARNING
■Never use a cup holder to hold hot liquids while the vehicle is moving
Using a cup holder to hold hot liquids while the vehicle is mov ing is danger-
ous. If the contents spill, you could be scalded.
■ Do not put anything other than cups or drink cans in cup holder s
Putting objects other than cups or drink cans in a cup holder is dangerous.
During sudden braking or maneuvering, occupants could be hit and injured,
or objects could be thrown around the vehicle, causing interfer ence with the
driver and the possibility of an accident. Only use a cup holde r for cups or
drink cans.

380
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-4. Interior Equipment
Bottle Holder
Bottle holders are on the inside of
the front doors.
Bottle holder
NOTICE
Do not use the bottle holders for containers without caps. The contents may
spill when opening/closing the door or while driving the vehicl e.

381
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-4. Interior Equipment
4
Interior Features
Storage Compartments
This console box is designed to store eyeglasses or other accesso-
ries.
Push and release to open.
WARNING
■ Keep storage boxes cl osed when driving
Driving with the storage boxes open is dangerous. To reduce the possibility
of injury in an accident or a sudden stop, keep the storage boxes closed
when driving.
■ Do not put articles in storage spaces with no lid
Putting articles in storage spaces with no lid is dangerous as they could be
thrown around the cabin if the vehicle is suddenly accelerated and cause
injury depending on how the article is stored.
NOTICE
Do not leave lighters or eyeglasses in the storage boxes while parked under
the sun. A lighter could explode or the plastic material in eye glasses could
deform and crack from high temperature.
Overhead Console

382
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-4. Interior Equipment
To open the glove compartment,
pull the latch toward you.
To close the glove compartment,
firmly press in the center of the
glove compartment lid.
A cup or small items can be placed on the center console tray using
the center console divider.
The center console tray is large
enough to place a small item
when the center console divider is
not in use.
Glove Compartment
Center Console Tray
WARNING
■ Never use a cup holder to hold hot liquids while the vehicle is moving
Using a cup holder to hold hot liquids while the vehicle is mov ing is danger-
ous. If the contents spill, you could be scalded.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3834-4. Interior Equipment
4
Interior Features
Lift the trunk mat.
Always hang clothes on the coat
hooks and the assist grips without
hangers.
Cargo Sub-Compartment (4-Door)
Rear Coat Hooks
WARNING
■Never hang heavy or sharp objects on the assist grips and coat hooks
Hanging heavy or sharp-ended objects such as a coat hanger from the
assist grips or coat hooks is dangerous as they can fly off and hit an occu-
pant in the cabin if a curtain air bag was to deploy, which cou ld result in seri-
ous injury or death.

384
