2020 TOYOTA YARIS HATCHBACK warning light

3
1
8 7
6 4 3
2
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
5
2-5. Steering WheelSteering Wheel.................. 127
2-6. Mirrors Mirrors ............................... 129
2-7. Windows Power Windows ................ 132
2-8. Security System Modification and Add-On Equipment ......... 135
Immobilizer System ........... 136
Theft Deterrent System ..... 138
2-9. Driving Tips Break-In Period ................. 141
Saving Fuel and Protection of the
Environment .................... 142
Hazardous Driving............. 143
Floor Mat ........................... 144
Rocking the Vehicle .......... 145
Winter Driving.................... 146
Driving In Flooded Area ................................ 149
Overloading ....................... 150
Driving on Uneven Road ............................... 151
2-10. Towing Trailer Towing ................... 152
Recreational Towing ......... 153 3-1. Start/Stop Engine
Ignition Switch ................... 156
Starting the Engine ............ 158
Turning the Engine Off ...... 163
3-2. Combination Meter and Display
Meters and Gauges ........... 164
Warning/Indicator Lights ............................... 173
3-3. Transaxle Manual Transaxle Operation......................... 177
Automatic Transaxle Controls ........................... 181
3-4. Switches and Controls Lighting Control ................. 192
Fog Lights .......................... 198
Turn and Lane-Change Signals............................. 199
Windshield Wipers and Washer ..................... 201
Rear Window Wiper and Washer ............................ 206
Rear Window Defogger.......................... 207
Hazard Warning Flasher ............................ 208
3-5. Brake Brake System .................... 209
Hill Launch Assist (HLA) .... 213
3When Driving

5
1
8 7
6 4 3
2
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
5
5-1. Essential InformationIntroduction ....................... 386
5-2. Scheduled Maintenance Maintenance Monitor......... 388
5-3. Owner Maintenance Owner Maintenance Precautions ..................... 390
Hood.................................. 392
Engine Compartment Overview ......................... 394
Engine Oil.......................... 395
Engine Coolant.................. 398
Brake/Clutch Fluid ............. 401
Window Washer Fluid ....... 402
Body Lubrication ............... 403
Wiper Blades ..................... 404
Battery ............................... 408
Key Battery Replacement ................... 410
Tires .................................. 413
Light Bulbs ........................ 419
Fuses ................................ 435
5-4. Appearance Care Exterior Care ..................... 442
Interior Care ...................... 450 6-1. Parking in an Emergency
Parking in an Emergency ...................... 456
6-2. Flat Tire Spare Tire and Tool Storage ............................ 457
Changing a Flat Tire .......... 463
6-3. Battery Runs Out Jump-Starting .................... 478
6-4. Emergency Starting Starting a Flooded Engine ............................. 482
Push-Starting ..................... 483
6-5. Overheating Overheating ....................... 484
6-6. Emergency Towing Towing Description ............ 486
Tiedown Hooks .................. 487
6-7. Warning/Indicator Lights and Warning Sounds
If a Warning Light Turns On or Flashes .................. 489
Message Indicated on Display............................. 500
Warning Sound is Activated.......................... 502
6-8. When Trunk Lid Cannot be Opened
When Liftgate/Trunk Lid Cannot be Opened .......... 506
5Maintenance and Care6If Trouble Arises

24
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-1. Seats
The front seats are electrically heated. The ignition must be switched
ON.
Press the seat warmer switch to
illuminate the indicator light while
the ignition is switched ON. The
mode changes as follows each
time the seat warmer switch is
pressed.
OFF
High
Mid
Low
●If the ignition is switched off while the seat warmer is operating (High, Mid or
Low) and then switched ON again, the seat warmer will automatic ally oper-
ate at the temperature set before switching off the ignition.
● Use the seat warmer when the engine is running. Leaving the seat warmer
on for long periods with the engine not running could cause the battery
power to be depleted.
● The temperature of the seat warmer cannot be adjusted beyond Hi gh, Mid
and Low because the seat warmer is controlled by a thermostat.
Seat Warmer (if equipped)
1
2
3
4
WARNING
■ Be careful when using the seat warmer
The heat from the seat warmer may be too hot for some people, a s indi-
cated below, and could cause a low-temperature burn.
● Infants, small babies, elderly people, and physically challenge d people
● People with delicate skin
● People who are excessively fatigued
● People who are intoxicated
● People who have taken sleep-inducing medicine such as sleeping pills or
cold medicine
■ Do not use the seat warmer with anything having high moisture-r eten-
tion ability such as a blanket or cushion on the seat
The seat may be heated excessively and cause a low-temperature burn.

38
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-2. Seat Belt Systems
Depress the button on the seat
belt buckle. If the belt does not
fully retract, pull it out and check
for kinks or twists. Then make
sure it remains untwisted as it
retracts.
If a belt does not fully retract, inspect it for kinks and twists. If it is still not
retracting properly, have it inspected at your Toyota dealer.
To r a i s e
To l o w e r
Make sure the adjuster is locked.
If it detects that the occupant seat belt is unfastened, the wa rning light
or beep alerts the occupant.
Refer to Taking Action on P. 496.
Refer to Seat Belt Warning Beep on P. 503.
Unfastening the Seat Belt
Button
Front Shoulder Belt Adjuster
1
2
Seat Belt Warning Systems

39
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-2. Seat Belt Systems
1
Essential Safety Equipment
Seat Belt Pretensioner and Load Limiting
Systems
◆Pretensioners
When a collision is detected, the pretensioners deploy simultan e-
ously with the air bags.
The pretensioners deploy simult aneously with the air bags when a
roll-over is also detected.
For deployment details, refer to the SRS Air Bag Deployment Cri te-
ria ( P. 78).
The front seat belt retractors remove slack quickly as the air bags
are expanding. Any time the air bags and seat belt pretensioners
have fired they must be replaced.
A system malfunction or operation conditions are indicated by a
warning.
Refer to Warning/Indi cator Lights on P. 173.
Refer to Air Bag/Front Seat Belt Pretensioner System Warning
Beep on P. 503.
In addition, the pretensioner system for the front passenger, l ike the
front and side passenger air bag, is designed to only deploy wh en
the front passenger occupant class ification sensor detects a pas-
senger sitting on the front passenger’s seat.
For details, refer to the front passenger occupant classificati on sen-
sor ( P. 8 2 ) .
For optimum protection, the d river and front passenger seat
belts are equipped with pretensi oner and load limiting systems.
For both these systems to work properly you must wear the seat
belt properly.

42
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-2. Seat Belt Systems
Seat Belt Extender
This extender will be only for you and for the particular vehicle and
seat. Even if it plugs into other seat belts, it may not hold in the critical
moment of a crash.
When ordering an extender, only order one that provides the nec es-
sary additional length to fast en the seat belt properly.
Please contact your Toyota d ealer for more information.
When not in use, remove the seat belt extender and store it in the vehicle. If
the seat belt extender is left connected, the seat belt extender might get dam-
aged as it will not retract with the rest of the seat belt and can easily fall out of
the door when not in use and be damaged. In addition, the seat belt warning
light will not illuminate and function properly.
If your seat belt is not long enough, even when fully extended, a
seat belt extender may be available to you at no charge from
your Toyota dealer.
WARNING
■ Do not use a seat belt extender unless it is necessary
Using a seat belt extender when not necessary is dangerous. The seat belt
will be too long and not fit properly. In an accident, the seat belt will not pro-
vide adequate protection and you could be seriously injured. On ly use the
extender when it is required to fasten the seat belt properly.
■ Do not use an improper extender
Using a seat belt extender that is for another person or a diff erent vehicle or
seat is dangerous. The seat belt will not provide adequate protection and
the user could be seriously injured in an accident. Only use the extender
provided for you and for the particular vehicle and seat. NEVER use the
extender in a different vehicle or seat. If you sell your Toyot a, do not leave
your seat belt extender in the vehicle. It could be used accide ntally by the
new owner of the vehicle. After removing the seat belt extender, discard it.
Never use the seat belt extender in any other vehicle you may o wn in the
future.

46
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-3. Child Restraint
WARNING
■Never use a rear-facing child-restraint system in the front sea t with an
air bag that could deploy
■ Do not install a front-facing c hild-restraint system on the fro nt passen-
ger seat unless it is unavoidable
Rear-facing child-restraint systems on
the front seat are particularly dangerous
even though you may feel assured that a
front passenger air bag will not deploy
based on the fact that the front passen-
ger air bag deactivation indicator light
illuminates. The child-restraint system
can be hit by a deploying air bag and
moved violently backward resulting in
serious injury or death to the child.
Vehicles with a front passenger air bag
have a warning label attached as shown
below.
The warning label reminds you not to put
a rear-facing child-restraint system on
the front passenger seat at any time.
In a collision, the force of a deploying air
bag could cause serious injury or death
to the child. If installing a front-facing
child-restraint system on the front pas-
senger seat is unavoidable, move the
front passenger seat as far back as pos-
sible.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
471-3. Child Restraint
1
Essential Safety Equipment
WARNING
■Seating a child in a child-restraint system on the front passen ger seat
is dangerous under certain conditions
Your vehicle is equipped with front passenger occupant classifi cation sen-
sor. Even with the front passenger occupant classification sensor, if you
must use the front passenger seat to seat a child, using a chil d-restraint
system on the front passenger seat under the following conditio ns
increases the danger of the front passenger air bag deploying a nd could
result in serious injury or death to the child.
● The front passenger air bag deactivation indicator light does not illuminate
when seating a child in the child-restraint system.
● Luggage or other items are placed on the seat with the child in the child-
restraint system.
● A rear passenger or luggage pushing or pulling down on the front passen-
ger seatback.
● Luggage or other items are placed on the seatback or hung on the head
restraint.
● The seat is washed.
● Liquids are spilled on the seat.
● The front passenger seat is moved backward, pushing into luggag e or
other items placed behind it.
● The front passenger seatback contacts the rear seat.
● Luggage or other items are placed between the front passenger s eat and
driver seat.
● An electric device is put on the front passenger’s seat.
● An additional electrical device, such as a seat warmer is installed to the
surface of the front passenger seat.
The designated positions with seat belts on the rear seats are the safest
places for children. Always use seat belts and child restraints .
