2020 MITSUBISHI ECLIPSE CROSS Owner's Manual (in English)

Multi-information display 5-144 Features and controls
5
N00555001480
The multi-information display displays warn- ings, the odometer, trip odometer, service reminder, engine coolant temperature, fuelremaining, outside temperature, selector lever position, average and instant fuel consump- tion, driving range, average speed, etc. It is also possible to change elements such as the language and units used on the multi- information display.
[With ignition switch or operation mode in OFF]
 The brightness level of the instruments is stored when the ignition switch is turned to the “OFF” position or the operation mode is put in OFF.  If you press and hold the button for longer than approximately 2 second when the front side-marker lights are illuminated, thebrightness level changes to the maximum level. Pressing and holding the button for longer than approximately 2 second againreturns the brightness level to the previous level. On vehicles equipped with Smartphone LinkDisplay Audio, the map screen color may not be switched to nighttime setting when the meter illumination brightness level is at themaximum.
Multi-information display
NOTE
1-
Warning display screen
 P.5-149
2- Information screen
 P.5-146
Interrupt display screen
 P.5-149
3- Door ajar warning display screen
 P.5-150
4- Odometer
 P.5-151
5-
“ ” mark indicator
 P.5-149
BK0277700US.book
144 ページ ２０１９年３月８日　金曜日　午前９時２３分

Multi-information display
Features and controls 5-145
5
[With ignition switch or operation mode in ON]
N00555101234
Each time the multi-information display switches are operated, the buzzer sounds and the multi-information display changesbetween information such as warnings, trip odometer, average and instant fuel consump- tion, distance range.It is also possible to change elements such as the language and units used on the multi- information display by operating the multi-information display switches.
1- S-AWC drive mode display screen (if
so equipped)
 P.5-71
2-
Warning display screen
 P.5-149
3- ECO mode indicator display screen
 P.5-201
4- Information screen
 P.5-146
5- Selector lever position display
 P.5-65
6- Engine coolant temperature display
 P.5-150
7- Odometer
 P.5-151
8- Cruise control display screen
 P.5-87
9- Adaptive Cruise Control System (ACC)
display screen (if so equipped)  P.5-92
10- ECO indicator
 P.5-154
11-
“ ” mark indicator
 P.5-149
12- Fuel remaining display screen
 P.5-150
13- Outside temperature display screen
 P.5-151NOTE
The fuel units, outside temperature units, display language, and other settings can be changed. Refer to “Changing the function settings” onpage 5-155.
Multi-information display switches
BK0277700US.book
145 ページ ２０１９年３月８日　金曜日　午前９時２３分

Multi-information display 5-146 Features and controls
5
N00555301207
Press the switch to display the information screen. Then, press th
e switch or switch to switch the display screen in the fol
lowing order.
Information screen (With the ignition switch in “OFF” position or the operation mode in OFF) *: When there is a warning display 1-
Trip odometer
 P.5-151
BK0277700US.book
146 ページ ２０１９年３月８日　金曜日　午前９時２３分

Multi-information display
Features and controls 5-147
5
N00555801260
When the ignition switch is turned to the
“ON” position or the operation mode is put
in ON, the display screen switches in the
following order.
2-
Trip odometer
 P.5-151
3- ECO score display
 P.5-155
4- Service reminder
 P.5-151
5- Redisplay of a warning display screen
 P.5-149
Information screen (With the ignition switch is turned from the “OFF” position to the “ON” position or the operation mode is changed from OFF to ON) * : When the inspection time has arrived 1- Screen when the ignition switch or the operation mode is OFF 2- System check screen
 P.5-153
3- Screen when the ignition switch or the operation mode is ON4- Service reminder
 P.5-151
BK0277700US.book
147 ページ ２０１９年３月８日　金曜日　午前９時２３分

Multi-information display 5-148 Features and controls
5
N00556201317
Press the switch or switch to switch the display screen in the following order.Information screen (With the ignition switch or the operation mode in ON) * : When there is a warning display 1-
Trip odometer
 P.5-151
2-
Trip odometer
 P.5-151
3- Driving range display
 P.5-153
ECO drive assist display
 P.5-154
4- Average fuel consumption display
 P.5-153 ECO drive assist display
 P.5-154
5- Average speed display
 P.5-154
Instant fuel consumption display

P.5-154
6- ECO score display
 P.5-155
7- AYC (Active Yaw Control) operation
display (if so equipped)
 P.5-81
8- S-AWC operation display (if so
equipped)
 P.5-72
9- Service reminder
 P.5-151
10- Function setting screen
 P.5-155
11- Redisplay of a warning display screen
 P.5-149NOTE
While driving, the service reminder are not displayed even if you operate the multi-information display switches. Always stop the vehicle in a safe place before operating.
BK0277700US.book
148 ページ ２０１９年３月８日　金曜日　午前９時２３分

Multi-information display
Features and controls 5-149
5
N00556301246
When there is information to be announced, such as a system fault, the tone sounds and the information screen is switched to thewarning display screen. Refer to the warning list and take the neces- sary measures. Refer to “Warning display list” on page 5-165. When the cause of the warning display iseliminated, the warning display goes out automatically.
Even if the cause of the warning display is not eliminated, you can return to the screen that was displayed before the warning dis-play. If you press the switch, the display screen switches to the screen display from before the warning and the warning (A) is also dis- played. Warning display screens with the “ ” mark displayed in the upper right of the screen can be switched. If you want to switch the dis- play, press the switch for approximately 2 seconds or more.
N00579600034
When the warning is displayed, if you press the switch or switch a few times, the warning display screen you switched from is redisplayed.
N00579700022
The operation status of each system is dis- played on the information screen. For further details, refer to the appropriatepage in the warning display list. Refer to “Other interrupt displays” on page 5-180.
N00555201248
This is displayed when you press the switch and return from the warning display screen to the previous screen.This mark is also displayed if there is another warning other than the one displayed. When the cause of the warning display is eliminated, the warning goes out automat- ically.
 While driving, the function setting screen is not displayed even if you operate the multi- information display switches. Always park the vehicle in a safe place, firmly apply the parking brake and put theselector lever into the “P” (PARK) position before operating the function setting screen. Refer to “Changing the function settings” onpage 5-155.  When there is information to be announced, such as a system fault, the tone sounds and the screen display is switched. Refer to “Interrupt display screen” on page5-149.
Interrupt display screen Warning display
NOTE
Returning to the display screen from before the warning display If you want to switch the display
Redisplay of a warning display screen Other interrupt displays warning display screen
BK0277700US.book
149 ページ ２０１９年３月８日　金曜日　午前９時２３分

Multi-information display 5-150 Features and controls
5
N00529700043
If any of the doors or the liftgate is not com- pletely closed, this displays the open door orliftgate. If the speed increases to approximately 5 mph (8 km/h) or higher with a door ajar, a tonewill sound four times to inform you that a door is ajar.
N00578200020
Shows the engine coolant temperature. If the coolant becomes hot, “ ” will blink. Pay careful attention to the engine coolant temperature display while you are driving.
N00556601210
Shows the amount of fuel remaining.
NOTE
 When the warning is displayed, the warn- ing display screen can be redisplayed on the information screen. Refer to “Information screen (with the igni-tion switch in “OFF” position or the opera- tion mode in OFF)” on page 5-146. Refer to “Information screen (with the igni-tion switch or the operation mode in ON)” on page 5-148.
Door ajar warning display screen
CAUTION Always make sure that the warning display goes out before beginning to drive.
Engine coolant temperature display
CAUTION If the engine is overheating, “ ” will blink. In this case, the bar graph is on the red zone. Immediately park the vehicle in a safe placeand take the required measures. Refer to “Engine overheating” on page 8-4.
Fuel remaining display screen
F- Full E- Empty
CAUTION Running out of gas could damage the cata- lytic converter. If the warning display appears, refuel as soon as possible.NOTE
 It may take several seconds to stabilize the display after refilling the tank.  If fuel is added with the ignition switch or the operation mode in ON, the remaining fuel display may incorrectly indicate the fuel level.  The arrow (A) indicates that the fuel tank filler door is located on the left side of thevehicle. (Refer to “Filling the fuel tank” on page 3-3.)
BK0277700US.book
150 ページ ２０１９年３月８日　金曜日　午前９時２３分

Multi-information display
Features and controls 5-151
5
N00578300063
When the fuel level runs low, the information screen switches to the interrupt display of thefuel remaining warning display and the mark (B) on the fuel remaining display flashes. If the warning display appears, refuel as soon aspossible.
N00556501118
Shows the temperature outside the vehicle.
N00574901026
Shows the total distance traveled.
N00575001053
Shows the distance traveled between twopoints. Usage examples for trip odometer , tripodometer It is possible to measure two currently trav- eled distances, from home using trip odome- ter and from a particular point on the wayusing trip odometer . To return the display to “0”, hold down the
switch for approximately 2 seconds or
more. Only the currently displayed value will be reset. Example If trip odometer is displayed, only tripodometer will be reset.  Both trip odometers and can count up to 9999.9 miles/kilometers.When a trip odometer goes past 9999.9 miles/kilometers, it returns to 0.0 miles/kilometers. When disconnecting the battery terminal, the memories of trip odometer displays
and are cleared, and their displays
return to “0.0 miles/kilometers”.
N00556701338
Displays the approximate time until the nextrecommended periodic inspection. “---” isdisplayed when the inspection time has arrived.
Fuel remaining warning display
NOTE
 On hills or curves, the display may be incor- rect due to the movement of fuel in the tank.
Outside temperature display screen
NOTE
 The display setting can be changed to the preferred units (°F or °C). Refer to “Changing the function settings” on page 5-155.  Depending on factors such as the driving conditions, the displayed temperature may vary from the actual outside temperature.
Odometer Trip odometer To reset the trip odometer
Service reminder
BK0277700US.book
151 ページ ２０１９年３月８日　金曜日　午前９時２３分
