2019 LEXUS LX570 Owners Manual

LX570_OM_OM60R07U_(U) 5938-2. Customization
8
Vehicle specifications ■
Seat heaters and ventilators
* (  P. 419)
* : If equipped ■
Heated steering wheel
* (  P. 419)
* : If equipped Function Default setting Customized
setting
Adjustment of the front seat
heater temperature or the
ventilator fan speed during
automatic operation (indi-
vidual seat adjustment
available) Level 3 (standard) Level 1 (low) to
level 5 (high) O — O
Adjustment of the second
seat heater temperature or
the ventilator fan speed
during automatic operation
(individual seat adjustment
available) Level 3 (standard) Level 1 (low) to
level 5 (high) O — O 1 2 3
Function Default setting Customized
setting
Automatic steering wheel
heating On Off O — O
Time until automatic steer-
ing wheel heating turns off Level 3 (standard) Level 1 (short) to
level 5 (long) O — O 1 2 3

594
LX570_OM_OM60R07U_(U) 8-2. Customization■
Drive mode customization (  P. 290)
■
Turn signal lever (  P. 223)Function Default setting Customized
setting
Powertrain Normal Eco
O — —
Power
Chassis Normal Sport
O — —
Comfort
Automatic air conditioning
system Normal Eco O — — 1 2 3
Function Default setting Customized
setting
The number of times the
turn signal lights flash auto-
matically when the turn sig-
nal lever is moved to the
first position during a lane
change 3 4
— — O5
6
7
Off 1 2 3

LX570_OM_OM60R07U_(U) 5958-2. Customization
8
Vehicle specifications ■
Multi-information display (  P. 96)
* 1
: The default setting varies according to countries.
* 2
: Some status screens cannot be registered (i ndicated on the multi-information display)
* 3
: 2 of the following items: current fuel cons umption, average fuel economy (after reset),
average fuel economy (after refuel), average fuel economy (after start), average vehi-
cle speed (after reset), average vehicle spee d (after start), distance (driving range),
distance (after start), elapsed time (after reset), elapsed time (after start), blankFunction Default
setting Customized
setting
Language English French
O O –
Spanish
Units
* 1
miles (MPG US) miles
(MPG Imperial)
O O –
km (L/100 km)
km (km/ L)
Eco Driving Indicator Light On Off – O –
switch settings Drive
information 1 Desired status
screen
* 2
– O –
Drive information screen dis-
played on the first screen of

(Drive information 1) Current fuel
consumption
* 3
– O –
Average fuel
economy
(after reset)
Drive information screen dis-
played on the second screen
of
(Drive information 2) Distance (range)
* 3
– O –
Average speed
(after reset)
Clock 12-hour display 24-hour display – O –
Pop-up display On Off – O –
Accent color Color 1 Color 2 O O – 1 2 3

596
LX570_OM_OM60R07U_(U) 8-2. Customization■
LDA (Lane Departure Alert)
* (  P. 267)
* : If equipped ■
BSM (Blind Spot Monitor) (  P. 369)Function Default
setting Customized
setting
Alert method
(Steering
vibration) (Buzzer) — O —
Alert sensitivity Standard High — O —
Vehicle sway warning On Off — O —
Vehicle sway warning sensi-
tivity Standard Low
— O —
High 1 2 3
Function Default setting Customized set-
ting
BSM (Blind Spot Monitor) On Off — O —
RCTA (Rear Cross Traffic
Alert function) On Off — O —
Outside rear view mirror indi-
cator brightness Bright Dim O — O
Alert timing for presence of
approaching vehicle (BSM
function only) Intermediate Early
O — OLate
Only when in
blind spot
RCTA buzzer volume Level 2 Level 1
O — O
Level 3 1 2
3

LX570_OM_OM60R07U_(U) 5978-2. Customization
8
Vehicle specifications ■
HUD (Head-up Display)
* (  P. 105)
* : If equipped ■
Vehicle customization ●
When smart access system with push-button start is turned off, unlock door cannot be
selected. ●
When doors are not opened after unlocking and are then automatically re-locked, a
signal will be given if Operation signal (Emergency flashers) or Operation signal
(Buzzer) are set to on. ■
When setting using the multi-information display
When using the vehicle switches to set an item that can also be set using the touch
screen, the item displayed on the Remote Touch will not change immediately.
If the engine switch is first turned to off, the screen display will change once the engine
switch is turned to IGNITION ON mode again. ■
When customizing usin g the Remote Touch
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P. Also,
to prevent battery discharge, leave the engine running while customizing the features. Function Default
setting Customized
setting
Driving support display
(Navigation system
* ) On Off — O —
Driving support display
(Driving assist
* ) On Off — O —
Driving support display
(compass
* ) On Off — O —
Driving support display
(audio
* ) On Off — O —
WARNING ■
During customization
As the engine needs to be running during customization, ensure that the vehicle is
parked in a place with adequate ventilation. In a closed area such as a garage, exhaust
gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This
may lead to death or a serious health hazard.
NOTICE ■
During customization
To prevent battery discharge, ensure that the engine is running while customizing fea-
tures. 1 2 3

598
LX570_OM_OM60R07U_(U) 8-3. Initialization
Items to initialize
* : If equippedThe following item must be initialized for normal system operation such cases
as the battery being reconnected, or maintenance being performed on the
vehicle: Item When to initialize Reference
Message indicating mainte-
nance is required (U.S.A. only) After the maintenance is per-
formed P. 467
Power back door • After reconnecting or changing
the battery with power back door
opened
• After changing a fuse with power
back door opened P. 128
Tire pressure warning system • When the set tire pressure has
been changed before towing.
• When rotating the tires in above
situation. P. 488
Multi-terrain Monitor After reconnecting or changing the
battery P. 367
Engine oil maintenance data
* After the maintenance is per-
formed P. 477

599
LX570_OM_OM60R07U_(U) 9 For owners Reporting safety defects
for U.S. owners.................................... 600
Seat belt instructions
for Canadian owners
(in French) ............................................... 601
SRS airbag instructions
for Canadian owners
(in French) ..............................................603

600
LX570_OM_OM60R07U_(U)Reporting safety defects for U.S. owners If you believe that your vehicle has a defect which could cause a crash or could
cause injury or death, you should immediately inform the National Highway
Traffic Safety Administration (NHTSA) in addition to notifying the Lexus
Division of Toyota Motor Sales, U.S. A., Inc. (Toll-free: 1-800-25-LEXUS).
If NHTSA receives similar complaints, it may open an investigation, and if it
finds that a safety defect exists in a group of vehicles, it may order a recall and
remedy campaign. However, NHTSA cann ot become involved in individual
problems between you, your dealer, or Lexus Division of Toyota Motor Sales,
U.S.A., Inc.
To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at
1-888-327-4236 (TTY: 1-800-424-9153); go to http://www.safercar.gov ; or
write to: Administrator, NHTSA, 1200 New Jersey Ave, S.E., Washington, DC
20590. You can also obtain other info rmation about motor vehicle safety from
http://www.safercar.gov .
