2019 LEXUS LX570 Owners Manual

497
LX570_OM_OM60R07U_(U) 6-3. Do-it-yourself maintenance
6
Maintenance and care
Tire inflation pressure The recommended cold tire inflation
pressure and tire size are displayed on
the tire and loading information label.
(  P. 569)Tire inflation pressure

498
LX570_OM_OM60R07U_(U) 6-3. Do-it-yourself maintenance
Tire valve
Tire pressure gauge
Remove the tire valve cap.
Press the tip of the tire pressure gauge onto the tire valve.
Read the pressure using the gauge gradations.
If the tire inflation pressure is not at the recommended level, adjust the pres-
sure.
If you add too much air, press the center of the valve to deflate.
After completing the tire inflation pressure measuremen t and adjustment,
apply soapy water to the valve and check for leakage.
Put the tire valve cap back on.Inspection and adjustment procedure 1
2
1
2
3
4
5
6

LX570_OM_OM60R07U_(U) 4996-3. Do-it-yourself maintenance
6
Maintenance and care ■
Tire inflation pressure check interval
You should check tire inflation pressure ever y two weeks, or at least once a month. Do
not forget to check the spare. ■
Effects of incorrect tire inflation pressure
Driving with incorrect tire inflation pressure may result in the following:●
Reduced fuel economy ●
Reduced driving comfort and poor handling ●
Reduced tire life due to wear ●
Reduced safety ●
Damage to the drive train
If a tire needs frequent inflating, ha ve it checked by your Lexus dealer.■
Instructions for checking tire inflation pressure
When checking tire in flation pressure, ob serve the following:●
Check only when the tires are cold.
If your vehicle has been parked for at le ast 3 hours and has not been driven for more
than 1 mile or 1.5 km, you will get an accu rate cold tire inflat ion pressure reading.●
Always use a tire pressure gauge.
It is difficult to judge if a tire is properly inflated based only on its appearance. ●
It is normal for the tire inflat ion pressure to be higher after driving as heat is generated
in the tire. Do not reduce tire inflation pressure after driving.●
Never exceed the vehicle capacity weight.
Passengers and luggage weight should be placed so that the vehicle is balanced.

500
LX570_OM_OM60R07U_(U) 6-3. Do-it-yourself maintenance
WARNING ■
Proper inflation is critical to save tire performance
Keep your tires properly inflated.
If the tires are not properly inflated, the following conditions may occur which could
lead to an accident resultin g in death or serious injury: ●
Excessive wear ●
Uneven wear ●
Poor handling ●
Possibility of blowouts resu lting from overheated tires●
Air leaking from between tire and wheel ●
Wheel deformation and/ or tire damage ●
Greater possibility of tire damage while driving (due to road hazards, expansion
joints, sharp edges in the road, etc.)
NOTICE ■
When inspecting and adjust ing tire inflation pressure
Be sure to put the tire valve caps back on.
If a valve cap is not installed, dirt or moisture may get into the valve and cause an air
leak, resulting in decreased tire inflation pressure.

501
LX570_OM_OM60R07U_(U) 6-3. Do-it-yourself maintenance
6
Maintenance and care
Wheels When replacing wheels, care should be ta ken to ensure that they are equivalent
to those removed in load capacity, diameter, rim width, and inset
* .
Replacement wheels are available at your Lexus dealer.
* : Conventionally referred to as “offset”.
Lexus does not recommend using the following:●
Wheels of different sizes or types ●
Used wheels ●
Bent wheels that have been straightened ●
Use only Lexus wheel nuts and wrenches designed for use with your alumi-
num wheels. ●
When rotating, repairing or changing your tires, check that the wheel nuts are
still tight after driving 1000 miles (1600 km). ●
Be careful not to damage the aluminum wheels when using tire chains. ●
Use only Lexus genuine balance weights or equivalent and a plastic or rubber
hammer when balancing your wheels. ■
When replacing wheels
The wheels of your vehicle are equipped with tire pressure warning valves and transmit-
ters that allow the tire pressure warning system to provide advance warning in the event
of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning
valves and transmitters must be installed. (  P. 489)If a wheel is bent, cracked or heavil y corroded, it should be replaced.
Otherwise, the tire may separate from the wheel or cause loss of handling
control.
Wheel selection
Aluminum wheel precautions

502
LX570_OM_OM60R07U_(U) 6-3. Do-it-yourself maintenance
WARNING ■
When replacing wheels ●
Do not use wheels that are a different size from those recommended in the Owner’s
Manual, as this may result in a loss of handling control. ●
Never use an inner tube in a leaking wheel which is designed for a tubeless tire. Doing
so may result in an accident, causing death or serious injury. ■
Use of defective wheels prohibited
Do not use cracked or deformed wheels.
Doing so could cause the tire to leak air du ring driving, possibly causing an accident.
NOTICE ■
Replacing tire pressure warn ing valves and transmitters●
Because tire repair or replacement may affe ct the tire pressure warning valves and
transmitters, make sure to have tires serviced by your Lexus dealer or other qualified
service shop. In addition, ma ke sure to purchase your tire pressure warning valves
and transmitters at your Lexus dealer. ●
Ensure that only genuine Lexus wh eels are used on your vehicle.
Tire pressure warning valves and transmitte rs may not work properly with non-genu-
ine wheels.

503
LX570_OM_OM60R07U_(U) 6-3. Do-it-yourself maintenance
6
Maintenance and care
Air conditioning filter Turn the engine switch IGNITION ON mode and switch to recirculated air
mode, then turn the engine switch off.
Open the glove box and remove the separate tray. (  P. 427)
Remove the filter cover.
Remove the filter case.The air conditioning filter must be cl eaned or changed re gularly to maintain
air conditioning efficiency.
Removal method 1
2
3
4

504
LX570_OM_OM60R07U_(U) 6-3. Do-it-yourself maintenance
If the filter is dirty, clean by blowing
compressed air through the filter from
the downward side. Hold the air gun 2 in. (5 cm) from the fil-
ter and blow for approximately 2 min-
utes at 72 psi (500 kPa, 5.0 kgf/cm 2
or
bar).
If it is not availa ble, have the filter
cleaned by your Lexus dealer.
Remove the air conditioning filter and
replace it with a new one. The “  UP” marks shown on the filter
should be pointing up.
■
Checking interval
Inspect, clean and replace the air conditio ning filter accordin g to the maintenance
schedule. In dusty areas or area s with heavy traffic flow, more frequent cleaning or early
replacement may be required.
(For scheduled maintenance information, please refer to the “Owner’s Manual
Supplement” or “Scheduled Maintenance”.) ■
If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.Cleaning method
Replacement method
NOTICE ■
To prevent damage to the system●
When using the air conditioning system, make sure that a filter is always installed.●
When cleaning the filter, do no t clean the filter with water.
