2019 LEXUS LX570 Owners Manual

LX570_OM_OM60R07U_(U) 1453-2. Opening, closing and locking the doors
3
Operation of each component WARNING ■
Caution regarding interference with electronic devices●
People with implantable cardiac pacema kers, cardiac resynchronization therapy-
pacemakers or implantable cardioverter de fibrillators should keep away from the
smart access system antennas. (  P. 138)
The radio waves may affect the operation of such devices. If necessary, the entry
function can be disabled. Ask your Lexus dealer for details, such as the frequency of
radio waves and timing of the emitted radio waves. Then, consult your doctor to see if
you should disable the entry function. ●
Users of any electrical medical device ot her than implantable cardiac pacemakers,
cardiac resynchronization th erapy-pacemakers or implantable cardioverter defibril-
lators should consult the manufacturer of the device for information about its opera-
tion under the influence of radio waves.
Radio waves could have unexpected effects on the operation of such medical
devices.
Ask your Lexus dealer for details on disabling the entry function.

146
LX570_OM_OM60R07U_(U) 3-3. Adjusting the seats
Front seats Seat position adjustment switch
Seatback angle adjustment switch
Seat cushion (front) an gle adjustment switch
Vertical height adjustment switch
Lumber support adjustment switch
Seat cushion length adjustment switch (driver’s side only)
When the occupant’s lower back
presses against the seatback during a
rear-end collision, the head restraint
moves slightly forward and upward to
help reduce the risk of whiplash on the
seat occupant.Adjustment procedure
Active head restraints 1
2
3
4
5
6

LX570_OM_OM60R07U_(U) 1473-3. Adjusting the seats
3
Operation of each component ■
Power easy access system
The driver’s seat and steering wheel move in accordance with engine switch mode and
the driver’s seat belt condition. (  P. 157)■
Active head restraints
Even small forces applied to the seatback may cause the head restraint to move. Pushing
up a locked head restraint fo rcibly may appear the head re straint inner st ructure. These
do not indicate problems.
WARNING ■
When adjusting the seat position ●
Take care when adjusting the seat position to ensure that other passengers are not
injured by the moving seat. ●
Do not put your hands under the seat or near the moving parts to avoid injury.
Fingers or hands may become jammed in the se at mechanism.■
Seat adjustment
To reduce the risk of sliding under the lap be lt during a collision, do not recline the seat
more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces
directly to the abdomen, or your neck may contact the shou lder belt, increasing the risk
of death or serious injury in the event of an accident.
Adjustments should not be made while drivin g as the seat may unexpectedly move and
cause the driver to lose control of the vehicle. Inner
structure During rear-end collision

148
LX570_OM_OM60R07U_(U) 3-3. Adjusting the seats
Rear seats 
Second seats
Seatback angle adjustment lever
Seat position adjustment switch 
Third seats (if equipped)
Seatback angle adjustment leverAdjustment procedure 1
2
1

LX570_OM_OM60R07U_(U) 1493-3. Adjusting the seats
3
Operation of each component For easy access to the third seat (if eq uipped), perform in “Tumbling the sec-
ond seats” (  P. 150). ■
Before tumbling the second seats
Stow the seat belt buckles and
lower the head restraints to the
lowest position.
Pass the outer seat belts through
the seat belt hangers and secure
the seat belt plates. This prevents the shoulder belt from
being damaged.
Make sure that th e seat belts are
removed from the hangers before
using them.
Vehicles with rear seat entertain-
ment system: Install the display
cover for the rear seat entertain-
ment system.
Pass the cover belt under the dis-
play and slide the cover up.
Slide the cover down from the top
of the display to cover it.Tumbling the second seats and third seat entry 1
1
2
3

150
LX570_OM_OM60R07U_(U) 3-3. Adjusting the seats■
Tumbling the second seats
Fold down the seatback while
pulling the seatback angle adjust-
ment lever, and swing the whole
seat up and forward.
Hook the holding strap to the
assist grip and secure the seat by
pulling its free end. When returning the second seat to
its original position, stow the holding
strap.
Remove the seat hook covers
from the back of the seat cushion,
and install them on the seat
hooks. When returning the second seat to
its original position, remove the seat
hook covers from the floor and install
them in the back of the seat cushion.1
2
3

LX570_OM_OM60R07U_(U) 1513-3. Adjusting the seats
3
Operation of each component ■
Before folding the third seats
Stow the seat belts buckles.
Stow the center head restraint in the seatback. (  P. 163)
Pass the outer seat belts through
the seat belt hangers and secure
the seat belt plates. This prevents the shoulder belt from
being damaged.
Make sure that th e seat belts are
removed from the hangers before
using them.
Stow the center seat belt tabs in the cover set in the roof. (  P. 32)■
Folding down the third seatback
For right side
For left sideFolding the third seats (if equipped) 1
2
3
4
1
2

152
LX570_OM_OM60R07U_(U) 3-3. Adjusting the seats
The seat will automatically fold when
the switch is pressed.
