2019 LEXUS LX570 Owners Manual

161
LX570_OM_OM60R07U_(U) 3-3. Adjusting the seats
3
Operation of each component
Head restraints Vertical adjustment
Up Pull the head restraints up.
Down Push the head restraint down while
pushing the lock release button.
Angle adjustment (if equipped)
Up Pull the head restraints up.
Down Push the head restraint down while
pushing the lock release button.Head restraints are provided for all seats.
Front seats
Lock release button1
2
Second seats
Lock release button1
2

162
LX570_OM_OM60R07U_(U) 3-3. Adjusting the seats
To fold the head restraints, pull the head
restraint angle lever ■
Adjusting the height of the head restraints
■
Removing the head restraints 
Front seats
While pressing in the fl athead screwdriver, pull up the head restraint.
Second seatsThird outboard seats (if equipped)
Make sure that the head restraints are adjusted
so that the center of the head restraint is closest
to the top of your ears.
Push a flathead screwdriver into the slot. The
slot is located on the right side of the right
head restraint anchor.
Pull the head restraint up while pressing the lock
release button. 1
2
Lock release button

LX570_OM_OM60R07U_(U) 1633-3. Adjusting the seats
3
Operation of each component 
Third center seat (if equipped) 
Third outboard seats (if equipped)
The head restraint cannot be removed. ■
Installing the head restraints (e xcept for the third outboard seats)
Align the head restraint wi th the installation holes.
Push down the head restraint to the lock position.
Press and hold the lock release button when lowering the head restraint.■
When not using the third center seat head restraint (if equipped)Pull the head restraint up while pressing the lock
release button.
Open the zipper on the back of the third seat
and stow the head restraint inside.
WARNING ■
Head restraint precautions
Observe the following precautions regarding th e head restraints. Failure to do so may
result in death or serious injury. ●
Use the head restraints design ed for each respective seat.●
Adjust the head restraints to th e correct position at all times.●
After adjusting the head restraints, push down on them and make sure they are
locked in position. ●
Do not drive with the head restraints removed. Lock
release
button1
2

164 3-4. Adjusting the steering wheel and mirrors
LX570_OM_OM60R07U_(U)Steering wheel Operating the switch moves the steer-
ing wheel in the following directions:
Up
Down
Toward the driver
Away from the driver
To sound the horn, press on or close to
the mark.Adjustment procedure 1
2
3
4
Horn

1653-4. Adjusting the steering wheel and mirrors
3
Operation of each component
LX570_OM_OM60R07U_(U) ■
The steering wheel can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode
* .
* : If the driver’s seat belt is fastened, the steering wheel can be adjusted regardless of
engine switch mode. ■
Automatic adjustment of the steering position
A desired steering position ca n be entered to memory and recalled automatically by the
driving position memory system. (  P. 157)■
Power easy access system
The steering wheel and driver’s seat move in accordance with engine switch mode and
the driver’s seat belt condition. (  P. 157)
WARNING
Do not adjust the steeri ng wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an accident, result-
ing in death or serious injury.

166 3-4. Adjusting the steering wheel and mirrors
LX570_OM_OM60R07U_(U)Inside rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Adjust the height of the rear view mir-
ror by moving it up and down.
Responding to the level of brightness of the headlights of vehicles behind, the
reflected light is automatically reduced.
Changing automatic anti-glare func-
tion mode
ON/OFF When the automatic anti-glare function
is in ON mode, the indicator illuminates.
The function will set to ON mode each
time the engine switch is turned to
IGNITION ON mode.
Pressing the button turns the function to
OFF mode. (The indicator also turns
off.) ■
To prevent sensor errorThe rear view mirror’s position can be adjusted to enable sufficient confirma-
tion of the rear view.
Adjusting the height of rear view mirror
Anti-glare function
Indicator
To ensure that the sensors operate properly, do
not touch or cover them.

1673-4. Adjusting the steering wheel and mirrors
3
Operation of each component
LX570_OM_OM60R07U_(U) WARNING
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and an accident, resulting in death or
serious injury.

168 3-4. Adjusting the steering wheel and mirrors
LX570_OM_OM60R07U_(U)Outside rear view mirrors To select a mirror to adjust, press the
switch.
Left
Right Pressing the same switch again will
put the switch in neutral.
To adjust the mirror, press the switch.
Up
Right
Down
Left
■
Using the switch
Press the switch to fold the mirrors. Press it again to extend them to the
original position.Adjustment procedure 1
1
2
2
1
2
3
4
Automatically folding and extending the mirrors
