658What to do if... (Troubleshooting)
RAV4-HV_OM_OM42B03U_(U)
What to do if... (Troubleshooting)
●If you lose your mechanical keys, new mechanical keys can be made by
your Toyota dealer. ( →P. 109)
●If you lose your electronic keys, the risk of vehicle theft increases signifi-
cantly. Contact your Toyota dealer immediately. ( →P. 112)
●Is the electronic key battery weak or depleted? (→P. 518)
●Is the power switch in ON mode?
When locking the doors, turn the power switch off. ( →P. 199)
●Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. (→P. 138)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (→P. 1 1 6 )
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

659What to do if... (Troubleshooting)
RAV4-HV_OM_OM42B03U_(U)
●Did you press the power switch while firmly depressing the brake pedal?
(→P. 198)
●Is the shift lever in P? ( →P. 198)
●Is the electronic key anywhere detectable inside the vehicle? ( →P. 136)
●Is the steering wheel unlocked? (→P. 201)
●Is the electronic key battery weak or depleted?
In this case, the hybrid system can be started in a temporary way.
(→P. 591)
●Is the 12-volt battery discharged? ( →P. 592)
●Is the power switch in ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
power switch in ON mode: →P. 209
●It is locked automatically to prevent theft of the vehicle. ( →P. 201)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( →P. 161)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or ON mode (the hybrid system is not operating) for a period of
time. ( →P. 200)
If you think something is wrong
The hybrid system does not start
The shift lever cannot be shifted from P even if you depress
the brake pedal
The steering wheel cannot be tu rned after the hybrid system
is stopped
The windows do not open or close by operating the power
window switches
The power switch is turned off automatically

660What to do if... (Troubleshooting)
RAV4-HV_OM_OM42B03U_(U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (→P. 549)
●The brake system warning light is on
Is the parking brake released? (→P. 212)
Depending on the situation, other types of warning buzzer may also sound.
( →P. 547, 556)
●Is the message displayed on the multi-information display?
Check the message on the multi-information display. ( →P. 556)
●When a warning light turns on or a warning message is displayed, refer to
P. 547, 556.
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
(→P. 576)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. ( →P. 602)
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

661Alphabetical index
RAV4-HV_OM_OM42B03U_(U)
Alphabetical index
A/C ............................................ 426Air conditioning filter ............. 516
Automatic air conditioning
system ......... ....................... 426
Micro dust and pollen filter .... 428
ABS (Anti-lock Brake System) .................................. 308 Function ................................ 308
Warning light ......................... 548
Air conditioning filter .............. 516
Air conditioning system.......... 426 Air conditioning filter ............. 516
Automatic air conditioning system ......... ....................... 426
Micro dust and pollen filter .... 428
Airbags ....................................... 38 Airbag operating conditions .... 46
Airbag precautions for
your child .............................. 41
Airbag warning light .............. 547
Correct driving posture ........... 28
Curtain shield airbag operating conditions ............. 46
Curtain shield airbag precautions ........................... 43
Front passenger occupant classification syst em............. 51
General airbag precautions .... 41
Locations of airbags................ 38
Modification and disposal of airbags.............................. 45
Side airbag operating conditions ............................. 46
Side airbag precautions .......... 43
Side and curtain shield airbags operating
conditions ............................. 46
Side and curtain shield airbags precautions .............. 43 SRS airbag instructions for
Canadian owners ............... 647
SRS airbags ........................... 38
All-wheel drive system............ 309
Anchor brackets ........................ 64
Antenna Radio .................................... 350
Smart key system ................. 136
Anti-lock brake system (ABS) ...................................... 308 Function ................................ 308
Warning light......................... 548
Approach warning Dynamic radar cruise
control ................................ 271
Armrest..................................... 455
Assist grips .............................. 456
Audio input ...................... 334, 368
Audio system ........................... 329 Audio input.................... 334, 368
AUX port/USB port ....... 334, 368
Bluetooth
® audio .................. 381
CD player.............................. 351
iPod ...................................... 358
MP3/WMA disc ..................... 351
Optimal use .......................... 348
Portable music player ........... 334
Radio .................................... 349
Steering wheel audio switch ................................. 333
USB memory ........................ 363
Automatic air conditioning system
Air conditioning filter ............. 516
Automatic air conditioning system .......... ...................... 426
Automatic High Beam ............. 217
Automatic light control system.................................... 216
AUX port ........................... 334, 368
Auxiliary box ............................ 442
