2017 TOYOTA RAV4 HYBRID Owners Manual

RAV4-HV_OM_OM42B03U_(U)
4336-1. Using the air conditioning system and defogger
6
Interior features
■Air conditioning filter
→P. 516
■ Customization
Settings (e.g. outside/recirculated air mode) can be changed.
(Customizable features →P. 639)
WARNING
■To prevent the windshield from fogging up
● Do not use during cool air operation in extremely humid weather.
The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.
■ To prevent burns
● Vehicles with outside rear view mirror defoggers: Do not touch the rear
view mirror surfaces when the outsi de rear view mirror defoggers are on.
● Vehicles with windshield wiper de-icer: Do not touch the glass at lower part
of the windshield or to the side of the front pillars when the windshield
wiper de-icer is on.
NOTICE
■ To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the
hybrid system is off.
● Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.

434
RAV4-HV_OM_OM42B03U_(U)
6-1. Using the air conditioning system and defogger
Heated steering wheel∗/seat heaters∗
∗: If equipped
Heated steering wheel and seat heaters heat the side grips of the
steering wheel and seats, respectively.
WARNING
● Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold remedies, etc.)
● Observe the following precautions to prevent minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat
heater.
• Do not use seat heater more than necessary.
NOTICE
● Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.
● To prevent 12-volt battery discharge, do not use the functions when the
hybrid system is not operating.

RAV4-HV_OM_OM42B03U_(U)
4356-1. Using the air conditioning system and defogger
6
Interior features
Turns the heated steering wheel
on/off
The indicator light comes on when
the heated steering wheel is oper-
ating.
The heated steering wheel can be used when the power switch is in ON
mode.
Turns seat heater on
Front left seat (high)
Front left seat (low)
Front right seat (high)
Front right seat (low)
The indicator light comes on when
the seat heater is operating.
●The seat heaters can be used when the power switch is in ON mode.
● When not in use, turn the seat heater off by returning the switch to its level
position. The indicator light turns off.
Heated steering wheel
Seat heaters
1
2
3
4

436
RAV4-HV_OM_OM42B03U_(U)
6-2. Using the interior lights
Interior lights list
Interior lights ( →P. 437)
Interior/personal lights ( →P. 437)
Instrument panel center illumination1
2
3

RAV4-HV_OM_OM42B03U_(U)
4376-2. Using the interior lights
6
Interior features
■FrontOff
Door position
The interior lights come on when
a door is opened. They turn off
when the doors are closed.
On
■RearOff
Door position
The interior light comes on when
a door is opened. It turns off
when the doors are closed.
On
Turns the light on/off
Interior lights
1
2
3
1
2
3
Personal lights

438
RAV4-HV_OM_OM42B03U_(U)
6-2. Using the interior lights
●Illuminated entry system: The lights automatically turn on/off according to
power switch mode, the presence of the electronic key, whether the doors
are locked/unlocked, and whether the doors are opened/closed.
● If the interior lights remain on when the door is not fully closed and the inte-
rior light main switch is in the door position, the interior lights will go off auto-
matically after 20 minutes.
● Setting (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: →P. 639)

439
RAV4-HV_OM_OM42B03U_(U)
6-3. Using the storage features
6
Interior features
List of storage features
Auxiliary box (→P. 442)
Glove box ( →P. 440)
Bottle holders (→ P. 442)Console box (
→P. 440)
Cup holders ( →P. 441)
Storage boxes ( →P. 444)
WARNING
● Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
• Lighters or spray cans may explode. If they come into contact with other stored items, the lighter may catch fire or the spray can may release
gas, causing a fire hazard.
● When driving or when the storage com partments are not in use, keep the
lids closed. In the event of sudden braking or sudden swerving, an acci-
dent may occur due to an occupant being struck by an open lid or the
items stored inside.
1
2
3
4
5
6

440
RAV4-HV_OM_OM42B03U_(U)
6-3. Using the storage features
Pull up the lever to open the glove
box.
Lift the lid while pulling up the
knob to release the lock.
Lower box
Upper box
Glove box
Console box
1
2
Vehicles with slide function: When using
the console box lid as an armrest, slide
the console box lid forward as needed.
Pull the lid forward by holding the front of
the lid.
