2017 JEEP COMPASS Owners Manual

GETTING TO KNOW YOUR VEHICLE
CONTENTS
KEYS .................................19
▫ A Word About Your Keys .................19
▫ Locking Doors With A Key ................19
▫ To Unlock The Doors And Liftgate ...........19
▫ Key Fob Unlock, Driver Door/All First Press ....19
▫ Programming Additional Key Fobs ...........20
▫ Key Fob Battery Replacement ..............20
▫ General Information .....................21
 IGNITION SWITCH .......................21
▫ Ignition Key Removal ....................21
▫ Key Fob-In-Ignition Reminder ..............23
 SENTRY KEY ...........................23
▫ Replacement Key Fobs ...................24
▫ Customer Key Programming ...............24▫
General Information .....................25
 VEHICLE SECURITY ALARM — IF EQUIPPED . . .25
▫ To Arm The System .....................26
▫ Rearming The System ....................26
▫ To Disarm The System ....................26
▫ Vehicle Security Alarm Manual Override .......26
 REMOTE STARTING SYSTEM — IF EQUIPPED . . .27
▫ How To Use Remote Start ..................27
▫ Remote Start Abort Message Display ..........28
▫ To Enter Remote Start ....................28
▫ To Exit Remote Start Mode Without Driving The
Vehicle ...............................29
▫ To Exit Remote Start Mode And Drive The
Vehicle ...............................29
 DOOR LOCKS ..........................293

▫Manual Door Locks ......................29
▫ Power Door Locks ......................30
▫ Child-Protection Door Lock System — Rear
Doors ...............................32
 SEATS ................................34
▫ Manual Front Seat Adjustment ..............34
▫ Manual Seat Height Adjustment — If
Equipped .............................35
▫ Manual Lumbar — If Equipped .............35
▫ Driver’s Seatback Recline ..................35
▫ Power Seats — If Equipped ................36
▫ Heated Seats — If Equipped ...............37
▫ Folding Rear Seat .......................38
▫ Reclining Rear Seat — If Equipped ...........39
 HEAD RESTRAINTS .......................40
▫ Supplemental Active Head Restraints — Front
Seats ................................40
▫ Rear Head Restraints .....................43
STEERING WHEEL .......................43
▫ Tilt Steering Column .....................43
 MIRRORS ..............................44
▫ Inside Day/Night Mirror ..................44
▫ Automatic Dimming Mirror — If Equipped .....44
▫ Outside Mirror — Driver Side ..............45
▫ Outside Mirror — Passenger Side ............45
▫ Folding Outside Mirrors ..................45
▫ Power Mirrors .........................46
▫ Heated Mirrors — If Equipped .............46
▫ Vanity Mirrors — If Equipped ..............46
▫ Sun Visor “Slide-On-Rod” Feature — If
Equipped .............................47
 EXTERIOR LIGHTS .......................47
▫ Headlights And Parking Lights .............47
▫ Daytime Running Lights — If Equipped .......47
▫ High/Low Beam Switch ..................47
16 GETTING TO KNOW YOUR VEHICLE

▫Flash-To-Pass ..........................47
▫ Automatic Headlights — If Equipped .........48
▫ Fog Lights — If Equipped .................48
▫ Turn Signals ...........................49
▫ Lights-On Reminder .....................49
▫ Headlights On With Wipers (Available With
Automatic Headlights Only) ...............49
 INTERIOR LIGHTS .......................50
▫ Instrument Panel Dimming .................50
▫ Map/Reading Lights .....................50
 WINDSHIELD WIPERS AND WASHERS ........51
▫ Windshield Wiper Operation ................52
▫ Intermittent Wiper System .................52
▫ Windshield Washers .....................53
▫ Headlights On With Wipers (Available With
Automatic Headlights Only) ...............53
▫ Mist Feature ...........................53
▫ Rear Window Wiper/Washer ...............54
CLIMATE CONTROLS .....................55
▫ Manual Climate Controls ..................55
▫ Automatic Climate Controls ................59
▫ Automatic Temperature Control (ATC) — If
Equipped .............................64
▫ Operating Tips .........................65
 POWER WINDOWS — IF EQUIPPED ..........68
▫ Power Window Switches ..................68
▫ Auto-Down ............................69
▫ Window Lockout Switch ...................69
 POWER SUNROOF — IF EQUIPPED ..........70
▫ Opening Sunroof .......................70
▫ Closing ..............................71
▫ Wind Buffeting .........................71
▫ Sunshade Operation ......................71
▫ Pinch Protect Feature .....................72
▫ Sunroof Maintenance .....................72
3
GETTING TO KNOW YOUR VEHICLE 17

▫Ignition Off Operation ....................72
 TO OPEN AND CLOSE THE HOOD ...........72
 LIFTGATE .............................74
▫ Cargo Area Features .....................75
 GARAGE DOOR OPENER — IF EQUIPPED .....78
▫ Before You Begin Programming HomeLink .....79
▫ Programming A Rolling Code ...............79
▫ Programming A Non-Rolling Code ...........81
▫ Canadian/Gate Operator Programming ........82
▫ Using HomeLink .......................83
▫ Security ..............................83 ▫
Troubleshooting Tips .....................84
▫ General Information ......................84
 CONSOLE FEATURES .....................85
 INTERNAL EQUIPMENT ...................87
▫ Glove Compartment And Storage Bin .........87
▫ Door Storage ...........................88
▫ Electrical Power Outlets ..................89
▫ Power Inverter — If Equipped ..............90
▫ Cupholders ............................92
 ROOF LUGGAGE RACK — IF EQUIPPED ......92
18 GETTING TO KNOW YOUR VEHICLE

KEYS
Your vehicle uses keyless ignition system. The ignition
system consists of a key fob with a Remote Keyless Entry
(RKE) and an ignition switch. The keyless ignition system
consists of a key fob and Keyless Enter-N-Go button.
A Word About Your Keys
The authorized dealer that sold you your new vehicle has
the key code numbers for your vehicle locks. These num-
bers can be used to order duplicate Remote Keyless Entry
(RKE) key fobs. Ask your authorized dealer for these
numbers and keep them in a safe place.
Locking Doors With A Key
You can insert the key with either side up. To lock the door,
turn the key to the right. To unlock the door, turn the key
to the left. Refer to ”Body Lubrication” in Dealer Service”
in “Servicing And Maintenance” for further information.
To Unlock The Doors And Liftgate
Push and release the unlockbutton on the key fob
once to unlock the driver ’s door or twice within five
seconds to unlock all doors and liftgate. The turn signal
lights will flash to acknowledge the unlock signal. The
illuminated entry system will also turn on.
Key Fob Unlock, Driver Door/All First Press
This feature lets you program the system to unlock either
the driver ’s door or all doors on the first push of the unlock
button on the key fob. To change the current setting,
proceed as follows:
• For vehicles equipped with the instrument cluster dis-
play, refer to “Instrument Cluster Display/Personal Set-
tings (Customer-Programmable Features)” in “Getting
To Know Your Instrument Panel” for further informa-
tion.
Key Fob
3
GETTING TO KNOW YOUR VEHICLE 19

•For vehicles not equipped with the instrument cluster
display, perform the following steps:
1. Push and hold the lock
button on a programmed
key fob for at least 4 seconds but no longer than 10
seconds. Then, push and hold the unlock
but-
ton while still holding the lock
button.
2. Release both buttons at the same time.
3. Test the feature while outside of the vehicle by pushing the lock/unlock buttons on the key fob with
the ignition in the lock position and the Key re-
moved.
4. Repeat these steps if you want to return this feature to its previous setting.
NOTE: Pushing the lock button on the key fob while you
are inside the vehicle will activate the Vehicle Security
Alarm. Opening a door with the Vehicle Security Alarm
activated will cause the alarm to sound. Push the unlock
button to deactivate the Vehicle Security Alarm.
Programming Additional Key Fobs
Refer to “Sentry Key” in this section for further informa-
tion.
If you do not have a programmed key fob, contact your
authorized dealer for details.
Key Fob Battery Replacement
NOTE: Perchlorate Material – special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
The recommended replacement battery is CR2032.
1. If the key fob is equipped with a screw, remove the screw. With the key fob buttons facing down, use a flat
blade screwdriver to pry the two halves of the key fob
apart. Make sure not to damage the elastomer seal
during removal.
20 GETTING TO KNOW YOUR VEHICLE

2. Remove and replace the battery. Avoid touching the newbattery with your fingers. Skin oils may cause battery
deterioration. If you touch a battery, clean it with
rubbing alcohol.
3. To reassemble the key fob case, snap the two halves together.
NOTE: If the key fob is equipped with a screw, reinstall
and tighten the screw until snug.
General Information
The following regulatory statement applies to all Radio
Frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, in- cluding interference that may cause undesired opera-
tion.
NOTE: Changes or modifications not expressly approved
by the party responsible for compliance could void the
user ’s authority to operate the equipment.
IGNITION SWITCH
Ignition Key Removal
1. Place the gear selector in PARK (if equipped with an automatic transmission).
2. Place the ignition in the ACC (Accessory) position.
Separating Case Halves
3
GETTING TO KNOW YOUR VEHICLE 21

3. Push the key and cylinder inward and rotate the key tothe LOCK position.
4. Remove the key from the ignition. NOTE:
If you try to remove the key before you place the
gear selector in PARK, the key may become trapped
temporarily in the ignition. If this occurs, place the gear
selector in PARK, rotate the key clockwise slightly, and
then remove the key as described above. If a malfunction
occurs, the system will trap the key in the ignition to warn
you that this safety feature is inoperable. The engine can be
started and stopped but the key cannot be removed until
you obtain service.
WARNING!
• Before exiting a vehicle, always shift the automatic
transmission into PARK or the manual transmission
into FIRST gear or REVERSE, apply the parking
brake, turn the engine OFF, remove the key fob from
the ignition and lock your vehicle.
• Never leave children alone in a vehicle, or with
access to an unlocked vehicle.
• Allowing children to be in a vehicle unattended is
dangerous for a number of reasons. A child or others
could be seriously or fatally injured. Children
should be warned not to touch the parking brake,
brake pedal or the gear selector.
(Continued)
Ignition Positions
1 — LOCK
2 — ACC (ACCESSORY)
3 — ON/RUN
4 — START 22 GETTING TO KNOW YOUR VEHICLE
