2016 NISSAN NOTE key

WT-38
< SYMPTOM DIAGNOSIS >
LOW TIRE PRESSURE WARNING LAMP DOES NOT TURN OFF
LOW TIRE PRESSURE WARNING LAMP DOES NOT TURN OFF
Diagnosis ProcedureINFOID:0000000012432459
1.INSPECT BCM CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect BCM connectors.
3. Check terminals for damage or loose connections.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.BCM POWER SUPPLY AND GROUND CIRCUITS
Check BCM power supply and ground circuits. Refer to BCS-67, "
Diagnosis Procedure" (with Intelligent Key
system) or BCS-129, "
Diagnosis Procedure" (without Intelligent Key system).
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation" (with Intelligent Key system) or BCS-
137, "Removal and Installation" (without Intelligent Key system).
NO >> Repair BCM circuits.
Revision: August 2015 2016 Versa Note

cardiagn.com

LOW TIRE PRESSURE WARNING LAMP BLINKSWT-39
< SYMPTOM DIAGNOSIS >
C
DF
G H
I
J
K L
M A
B
WT
N
O P
LOW TIRE PRESSURE WA RNING LAMP BLINKS
Diagnosis ProcedureINFOID:0000000012432460
NOTE:
If low tire pressure warning lamp repeats blinking ON for 2 seconds and OFF for 0.2 seconds, ID registration
for all transmitters is not complete.
Carry out ID registration. Refer to WT-22, "
Work Procedure".
1.CHECK BCM CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect BCM connectors.
3. Check terminals for damage or loose connections.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation" (with Intelligent Key system) or BCS-
137, "Removal and Installation" (Intelligent Key system).
NO >> Repair or replace damaged parts.
Revision: August 2015 2016 Versa Note

cardiagn.com

WT-40
< SYMPTOM DIAGNOSIS >
EASY FILL TIRE ALERT DOES NOT ACTIVATE
EASY FILL TIRE ALERT DOES NOT ACTIVATE
DescriptionINFOID:0000000012432461
The easy fill tire alert does not function while inflating a tire when the select lever position is in P-range with the
ignition switch ON.
NOTE:
• After starting to inflate the tire, it takes a few seconds for the easy fill tire alert to function.
• If there is no response for approximately 15 seconds or mo re after inflating the tires, cancel the use of the
easy fill tire alert function or move the vehicle approximately 1 m (3.2 ft) backward or forward to try again.
The air filler pressure may be weak or out of service area.
• For easy fill tire alert, Refer to WT-8, "
TIRE PRESSURE MONITORING SYST EM : Easy Fill Tire Alert Func-
tion".
Diagnosis ProcedureINFOID:0000000012432462
1. LOCATION CHANGE
Move the vehicle to other area and repeat the procedure of the easy fill tire alert function. Refer to WT-8,
"TIRE PRESSURE MONITORING SYSTEM : Easy Fill Tire Alert Function".
Is the function normal?
YES >> Normal (the easy fill tire alert may not operate, depending on reception condition.)
NO >> GO TO 2.
2.PERFORM BCM SELF-DIAGNOSIS
With CONSULT
Perform self-diagnosis for “AIR PRESSURE MONITOR”.
Is any DTC detected?
YES >> Perform trouble diagnosis for detected DTC. Refer to BCS-50, "DTCIndex" (with Intelligent Key
system) or BCS-115, "
DTCIndex" (without Intelligent Key system).
NO >> GO TO 3.
3.CHECK HAZARD WARNING LAMP OPERATION
Check hazard warning lamp operation with hazard switch.
Does the hazard warning lamp blink?
YES >> GO TO 4.
NO >> Perform trouble diagnosis for the hazard warning lamp. Refer to EXL-85, "
Diagnosis Procedure" .
4.PERFORM TCM SELF-DIAGNOSIS
With CONSULT
Perform self-diagnosis for “TRANSMISSION”.
Is any DTC detected?
YES >> Check malfunctioning circuit. Refer to TM-110, "DTC Index".
NO >> GO TO 5.
5.CHECK HORN OPERATION
Check horn operation. Refer to HRN-3, "
Wiring Diagram".
Is the operation normal?
YES >> GO TO 6.
NO >> Repair or replace error-detected parts.
6.PERFORM BCM SELF-DIAGNOSIS
With CONSULT
1. Drive for 10 minutes at a speed of 40 km/h (25 MPH) or more.
CAUTION:
Total time driving at a speed of 40 km/h (25 MPH) or more must be 10 minutes.
2. Stop the vehicle.
3. Perform self-diagnosis for “AIR PRESSURE MONITOR”.
Revision: August 2015 2016 Versa Note

cardiagn.com

EASY FILL TIRE ALERT DOES NOT ACTIVATEWT-41
< SYMPTOM DIAGNOSIS >
C
DF
G H
I
J
K L
M A
B
WT
N
O P
Is any DTC detected?
YES >> Check malfunctioning circuit. Refer to BCS-50, "DTCIndex" (with Intelligent Key system) or BCS-
115, "DTCIndex" (without Intelligent Key system).
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation" (with Intelligent Key system) or BCS-
137, "Removal and Installation" (without Intelligent Key system).
Revision: August 2015 2016 Versa Note

cardiagn.com

WT-42
< SYMPTOM DIAGNOSIS >
ID REGISTRATION CANNOT BE COMPLETED
ID REGISTRATION CANNOT BE COMPLETED
Diagnosis ProcedureINFOID:0000000012432463
NOTE:
The Signal Tech II Tool [- (J-50190)] can be used to perform the following functions. Refer to the Signal Tech II
User Guide for additional information.
• Activate and display TPMS transmitter IDs
• Display tire pressure reported by the TPMS transmitter
• Read TPMS DTCs
• Register TPMS transmitter IDs
1.PERFORM ID REGISTRATION OF ALL TRANSMITTERS
Carry out ID registration of all transmitters. Refer to WT-22, "
Work Procedure".
Can ID registration of all transmitters be completed?
YES >> Inspection End.
NO >> Refer to WT-11, "
WITH INTELLIGENT KEY : CONSULT F unction (BCM - AIR PRESSURE MON-
ITOR)" (with Intelligent Key system) or WT-12, "WITHOUT INTELLIGENT KEY : CONSULT Func-
tion (BCM - AIR PRESSURE MONITOR)" (without Intelligent Key system).
Revision: August 2015 2016 Versa Note

cardiagn.com

TIRE PRESSURE RECEIVERWT-53
< REMOVAL AND INSTALLATION >
C
DF
G H
I
J
K L
M A
B
WT
N
O P
TIRE PRESSURE RECEIVER
Removal and InstallationINFOID:0000000012432472
The tire pressure receiver is integral to the remote keyless entry receiver. Refer to SEC-116, "Removal and
Installation".
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-1
BODY EXTERIOR, DOORS, ROOF & VEHICLE SECURITY
C
DE
F
G H
I
J
L
M
SECTION SEC
A
B
SEC
N
O P
CONTENTS
SECURITY CONTROL SYSTEM
WITH INTELLIGENT KEY SYSTEM
PRECAUTION ....... ........................................
5
PRECAUTIONS .............................................. .....5
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
5
Precaution for Work ..................................................5
PREPARATION ............................................6
PREPARATION .............................................. .....6
Special Service Tool ........................................... ......6
SYSTEM DESCRIPTION ..............................7
COMPONENT PARTS ................................... .....7
Component Parts Location .................................. ......7
CVT Shift Selector (Park Position Switch) ................9
BCM ..........................................................................9
ECM ..........................................................................9
IPDM E/R ................................................................10
NATS Antenna Amp. ...............................................10
Combination Meter ..................................................10
Door Switch .............................................................10
Outside Key Antenna ..............................................10
Inside Key Antenna .................................................10
Remote Keyless Entry Receiver .............................10
Intelligent Key ..........................................................10
Push-button Ignition Switch .....................................10
Security Indicator Lamp ...................................... ....10
Starter Relay ...........................................................10
Stop Lamp Switch ...................................................11
Transmission Range Switch ....................................11
SYSTEM .............................................................12
INTELLIGENT KEY SYSTEM/ENGINE START
FUNCTION ............................................................. ....
12
INTELLIGENT KEY SYSTEM/ENGINE START
FUNCTION : System Description ............................
12
NISSAN ANTI-THEFT SYSTEM ................................14
NISSAN ANTI-THEFT SYST EM : System De-
scription ............................................................... ....
15
DIAGNOSIS SYSTEM (BCM) ...........................18
COMMON ITEM ..................................................... ....18
COMMON ITEM : CONSULT Function (BCM -
COMMON ITEM) .....................................................
18
INTELLIGENT KEY ................................................ ....19
INTELLIGENT KEY : CONSULT Function (BCM -
INTELLIGENT KEY) ................................................
19
THEFT ALM ........................................................... ....21
THEFT ALM : CONSULT Function (BCM -
THEFT) ....................................................................
21
IMMU ...................................................................... ....21
IMMU : CONSULT Function (BCM - IMMU) ............21
ECU DIAGNOSIS INFORMATION ..............23
ECM, IPDM E/R, BCM .......................................23
List of ECU Reference ......................................... ....23
WIRING DIAGRAM ......................................24
INTELLIGENT KEY SYSTEM/ENGINE
START FUNCTION ...........................................
24
Wiring Diagram .................................................... ....24
NVIS - WITH INTELLIGENT KEY SYSTEM .....37
Wiring Diagram ........................................................37
BASIC INSPECTION ...................................46
DIAGNOSIS AND REPAIR WORK FLOW .......46
Work Flow ............................................................ ....46
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT ................................................
49
ECM ........................................................................ ....49
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-3
C
DE
F
G H
I
J
L
M A
B
SEC
N
O P
B26FC KEY REGISTRATION ........................ ....98
DTC Logic ........................................................... ....98
Diagnosis Procedure ...............................................98
B210B STARTER CONTROL RELAY ...............99
DTC Logic ........................................................... ....99
Diagnosis Procedure ...............................................99
B210C STARTER CONTROL RELAY .............100
DTC Logic ........................................................... ..100
Diagnosis Procedure .............................................100
B210D STARTER RELAY ................................102
DTC Logic .............................................................102
Diagnosis Procedure .............................................102
B210E STARTER RELAY ................................104
DTC Logic .............................................................104
Diagnosis Procedure .............................................104
B210F SHIFT POSITION/CLUTCH INTER-
LOCK SWITCH .................................................
106
DTC Logic ........................................................... ..106
Diagnosis Procedure .............................................106
B2110 SHIFT POSITION/CLUTCH INTER-
LOCK SWITCH .................................................
108
DTC Logic ........................................................... ..108
Diagnosis Procedure .............................................108
VEHICLE SECURITY INDICATOR ..................110
Description .......................................................... ..110
Component Function Check ................................110
Diagnosis Procedure .............................................110
SYMPTOM DIAGNOSIS ............................112
ENGINE DOES NOT START WHEN INTELLI-
GENT KEY IS INSIDE OF VEHICLE .............. ..
112
Description .......................................................... ..112
Diagnosis Procedure .............................................112
SECURITY INDICATOR LAMP DOES NOT
TURN ON OR BLINK .......................................
113
Description .......................................................... ..113
Diagnosis Procedure .............................................113
REMOVAL AND INSTALLATION .............114
NATS ANTENNA AMP. .................................. ..114
Removal and Installation .......................................114
PUSH-BUTTON IGNITION SWITCH .............. ..115
Removal and Installation .......................................115
REMOTE KEYLESS ENTRY RECEIVER ...... ..116
Removal and Installation .......................................116
WITHOUT INTELLIGE NT KEY SYSTEM
PRECAUTION ....... .....................................
117
PRECAUTIONS .............................................. ..117
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ..
117
Precaution for Work ...............................................117
PREPARATION .........................................118
PREPARATION ...............................................118
Special Service Tool ............................................ ..118
SYSTEM DESCRIPTION ...........................119
COMPONENT PARTS ....................................119
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS ..119
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Component Parts Location .......................
119
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : CVT Shift Selector (Park Position Switch) ..
121
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : BCM ..........................................................
121
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : ECM ..........................................................
121
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : IPDM E/R ..................................................
121
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Combination Meter ....................................
121
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Door Switch ...............................................
122
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Remote Keyless Entry Receiver ...............
122
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Security Indicator Lamp .......................... ..
122
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Starter Relay .............................................
122
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Stop Lamp Switch .....................................
122
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Transmission Range Switch .....................
122
SYSTEM ..........................................................123
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS ..123
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : System Diagram .......................................
123
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : System Description ...................................
123
DIAGNOSIS SYSTEM (BCM) .........................125
COMMON ITEM ..................................................... ..125
COMMON ITEM : CONSULT Function (BCM -
COMMON ITEM) ...................................................
125
IMMU ...................................................................... ..126
IMMU : CONSULT Function (BCM - IMMU) ..........126
DIAGNOSIS SYSTEM (IPDM E/R) .................127
Diagnosis Description ............................................127
CONSULT Function (IPDM E/R) ...........................128
ECU DIAGNOSIS INFORMATION ............131
Revision: August 2015 2016 Versa Note

cardiagn.com
