2016 NISSAN NOTE start

B26FB CLUTCH SWITCHSEC-97
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B26FB CLUTCH SWITCH
DTC LogicINFOID:0000000012430416
DTC DETECTION LOGIC
NOTE:
• If DTC B26FB is displayed with DTC U1000, firs t perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B26FB is displayed with DTC U1010, firs t perform the trouble diagnosis for DTC U1010. Refer to
BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-97, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430417
1.INSPECTION START
1. Turn ignition switch ON.
2. Select “Self Diagnostic Result” of “BCM” using CONSULT.
3. Touch “ERASE”.
4. Perform DTC CONFIRMATION PROCEDURE for DTC B26FB. Refer to SEC-97, "
DTC Logic".
Is DTC detected?
YES >> GO TO 2.
NO >> Inspection End.
2.REPLACE ECM
Replace ECM. Refer to EC-477, "
Removal and Installation"
>> Inspection End.
DTC No.CONSULT screen items
(Trouble diagnosis content) DTC detecting condition
Possible cause
B26FB CLUTCH SWITCH
(Clutch switch) BCM receives the abnormal signal of clutch
pedal position switch from ECM via CAN
communication. • Harness or connector
(CAN communication line is
open or shorted.)
•ECM
Revision: August 2015 2016 Versa Note

cardiagn.com

B210B STARTER CONTROL RELAYSEC-99
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B210B STARTER CONTROL RELAY
DTC LogicINFOID:0000000012430420
DTC DETECTION LOGIC
NOTE:
If DTC B210B is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to BCS-
63, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION
1. Turn ignition switch ON.
2. Turn ignition switch OFF and wait 1 second or more.
3. Turn ignition switch ON.
4. Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC B210B displayed?
YES >> Refer to SEC-99, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430421
1. PERFORM SELF DIAGNOSTIC RESULT
Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is display history of DTC B210B CRNT?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Refer to GI-42, "
Intermittent Incident".
CONSULT Display DTC Detection Condition Possible Cause
START CONT RLY ON
[B210B] When comparing the following items, IPDM E/R
detects that starter control relay is stuck in the
ON position for 1 second or more:
• Starter control relay signal (CAN) from BCM.
• Starter relay status signal (CAN) from BCM.
• Starter control relay an
d starter relay status
signal. (IPDM E/R input)
• Starter control relay control signal. (IPDM E/R
output)
• Transmission range switch signal input. IPDM E/R
Revision: August 2015
2016 Versa Note

cardiagn.com

SEC-100
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B210C STARTER CONTROL RELAY
B210C STARTER CONTROL RELAY
DTC LogicINFOID:0000000012430422
DTC DETECTION LOGIC
NOTE:
• If DTC B210C is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• When IPDM E/R power supply voltage is low (Approx. 7 - 8 V for about 1 second), the DTC B210C may be detected.
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION
1. Turn ignition switch ON.
2. Turn ignition switch OFF and wait 1 second or more.
3. Turn ignition switch ON.
4. Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC B210C displayed?
YES >> Refer to SEC-100, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430423
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1. PERFORM SELF DIAGNOSTIC RESULT
Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is display history of DTC B210C CRNT?
YES >> GO TO 2.
NO >> Refer to GI-42, "
Intermittent Incident".
2.CHECK STARTER CONTROL RELA Y CONTROL CIRCUITS VOLTAGE
Check voltage between IPDM E/R connectors and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO (WITH M/T)>>GO TO 3.
NO (WITH CVT)>>GO TO 4.
CONSULT Display DTC Detection Condition Possible Cause
STR CONT RLY OFF CIRC
[B210C] When comparing the following items, IPDM E/R
detects that starter control relay is stuck in the
OFF position for 1 second or more:
• Starter control relay signal (CAN) from BCM.
• Starter relay status signal (CAN) from BCM.
• Starter control relay an
d starter relay status
signal. (IPDM E/R input)
• Starter control relay co ntrol signal. (IPDM E/R
output) • IPDM E/R
•BCM
•Battery
IPDM E/R
GroundVo l ta g e
(Approx.)
Connector Terminal
E44 (WITH M/T) 13
—Battery voltage
F42 (WITH CVT) 40
Revision: August 2015 2016 Versa Note

cardiagn.com

B210C STARTER CONTROL RELAYSEC-101
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
3.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connector E44 and clutch interlock switch connector E34.
2. Check continuity between IPDM E/R connector E44 and clutch interlock switch connector E34.
3. Disconnect BCM connector M98.
4. Check continuity between IPDM E/R connector E44 and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness or connectors.
4.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connector F42 and transmission range switch connector F52.
2. Check continuity between IPDM E/R connecto r F42 and transmission range switch connector F52.
3. Disconnect BCM connector M98.
4. Check continuity between IPDM E/R connector F42 and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness or connectors.
IPDM E/R Clutch interlock switch
Continuity
Connector TerminalConnector Terminal
E44 13E34 2Yes
IPDM E/R
GroundContinuity
Connector Terminal
E44 13—No
IPDM E/R Transmission range switch
Continuity
Connector TerminalConnector Terminal
F42 40F52 10Yes
IPDM E/R
GroundContinuity
Connector Terminal
F42 40 —No
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-102
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B210D STARTER RELAY
B210D STARTER RELAY
DTC LogicINFOID:0000000012430424
DTC DETECTION LOGIC
NOTE:
If DTC B210D is displayed with DTC U1000, first
perform the trouble diagnosis for DTC U1000. Refer to BCS-
63, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION
1. Turn ignition switch ON.
2. Turn ignition switch OFF and wait 1 second or more.
3. Turn ignition switch ON.
4. Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC B210D displayed?
YES >> Refer to SEC-102, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430425
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1. PERFORM SELF DIAGNOSTIC RESULT
Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is display history of DTC B210D CRNT?
YES >> GO TO 2.
NO >> Refer to GI-42, "
Intermittent Incident".
2.CHECK STARTER CONTROL RELA Y CONTROL CIRCUITS VOLTAGE
Check voltage between IPDM E/R connectors and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO (WITH M/T)>>GO TO 3.
NO (WITH CVT)>>GO TO 4.
3.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connectors E44, BCM connecto r M98, clutch interlock switch connector E34.
CONSULT DisplayDTC Detection Condition Possible Cause
STARTER RLY ON CIRC
[B210D] When comparing the following items, IPDM E/R
detects that starter control relay is stuck in the
ON position for 5 second or more:
• Starter control relay signal (CAN) from BCM.
• Starter relay status signal (CAN) from BCM.
• Starter control relay an
d starter relay status
signal. (IPDM E/R input)
• Starter control relay co ntrol signal. (IPDM E/R
output) • Harness or connectors (starter motor relay
control circuit open or short.)
• IPDM E/R
•BCM
IPDM E/R GroundVo l ta g e
(Approx.)
Connector Terminal
E44 13
—Battery voltage
F42 40
Revision: August 2015 2016 Versa Note

cardiagn.com

B210D STARTER RELAYSEC-103
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
2. Check continuity between IPDM E/R connector E44 and ground.
Is the inspection result normal?
YES >> Refer to SEC-82, "Diagnosis Procedure".
NO >> Repair or replace harness or connectors.
4.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connectors F42, BCM connec tor M98, transmission range switch connector F52.
2. Check continuity between IPDM E/R connector F42 and ground.
Is the inspection result normal?
YES >> Refer to SEC-82, "Diagnosis Procedure".
NO >> Repair or replace harness or connectors.
IPDM E/R GroundContinuity
Connector Terminal
E44 13—No
IPDM E/R
GroundContinuity
Connector Terminal
F42 40 —No
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-104
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B210E STARTER RELAY
B210E STARTER RELAY
DTC LogicINFOID:0000000012430426
DTC DETECTION LOGIC
NOTE:
• If DTC B210E is displayed with DTC U1000, first
perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B210E is displayed with DTC B2605, first perform the trouble diagnosis for DTC B2605. Refer to
SEC-80, "
DTC Logic".
• When IPDM E/R power supply voltage is low (Approx. 7 - 8 V for about 1 second), the DTC B210F may be
detected.
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION
1. Turn ignition switch ON.
2. Turn ignition switch OFF and wait 1 second or more.
3. Turn ignition switch ON.
4. Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC B210E displayed?
YES >> Refer to SEC-104, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430427
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1. PERFORM SELF DIAGNOSTIC RESULT
Perform "Self Diagnostic Result" of "IPDM E/R" using CONSULT.
Is display history of DTC B210E CRNT?
YES >> GO TO 2.
NO >> Refer to GI-42, "
Intermittent Incident".
2.CHECK STARTER CONTROL RELA Y CONTROL CIRCUITS VOLTAGE
Check voltage between IPDM E/R connectors and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO (WITH M/T)>>GO TO 3.
CONSULT Display DTC Detection Condition Possible Cause
STARTER RELAY OFF
[B210E] When comparing the following items, IPDM E/R
detects that starter control relay is stuck in the
OFF position for 5 second or more:
• Starter control relay signal (CAN) from BCM.
• Starter relay status signal (CAN) from BCM.
• Starter control relay an
d starter relay status
signal. (IPDM E/R input)
• Starter control relay co ntrol signal. (IPDM E/R
output) • IPDM E/R
•BCM
•Battery
IPDM E/R
GroundVo l ta g e
(Approx.)
Connector Terminal
E44 13
—Battery voltage
F42 40
Revision: August 2015 2016 Versa Note

cardiagn.com

B210E STARTER RELAYSEC-105
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
NO (WITH CVT)>>GO TO 4.
3.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connector E44 and clutch interlock switch connector E34.
2. Check continuity between IPDM E/R connector E44 and clutch interlock switch connector E34.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness or connectors.
4.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connector F42 and transmission range switch connector F52.
2. Check continuity between IPDM E/R connecto r F42 and transmission range switch connector F52.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness or connectors.
IPDM E/R Clutch interlock switch
Continuity
Connector TerminalConnector Terminal
E44 13E34 2Yes
IPDM E/R Transmission range switch
Continuity
Connector TerminalConnector Terminal
F42 40F52 10Yes
Revision: August 2015 2016 Versa Note

cardiagn.com
