BRC-64
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1105, C1106, C1107, C1108 WHEEL SENSOR
NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
5. Start the engine.
NOTE:
Wait at least 10 seconds after starting the engine.
6. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1105”, “C1106”, “C1107” or “C1108” detected?
YES-1 >> “C1105”, “C1106”, “C1107” or “C1108” is displayed as “CRNT”: Proceed to BRC-64, "Diagnosis
Procedure".
YES-2 >> “C1105”, “C1106”, “C1107” or “C1108” is disp layed as “PAST”: Inspection End (Erase “Self Diag-
nostic Result” of “ABS”).
NO-1 >> To check malfunction symptom before repair: Refer to GI-42, "
Intermittent Incident".
NO-2 >> Confirmation after repair: Inspection End.
Diagnosis ProcedureINFOID:0000000012430857
CAUTION:
Never check between wheel senso r harness connector terminals.
1.CHECK WHEEL HUB ASSEMBLY
Check that there is no excessive looseness in wheel hub assembly.
• Front: Refer to FA X - 7 , "
Inspection".
• Rear: Refer to RAX-5, "
Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the wheel hub assembly, and GO TO 2. • Front: Refer to FA X - 9 , "
Removal and Installation".
• Rear: Refer to RAX-6, "
Removal and Installation".
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY AND GROUND CIR-
CUIT
Check the ABS actuator and electric unit (contro l unit) power supply and ground circuits. Refer to BRC-121,
"Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair / replace harness, connector, fuse, or fusible link.
3.CHECK TIRE
1. Turn the ignition switch OFF.
2. Check the tire air pressure, wear and size. Refer to WT-54, "
Tire Air Pressure".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Adjust air pressure or replace tire, and GO TO 4.
4.CHECK DATA MONITOR (1)
With CONSULT
1. Erase “Self Diagnostic Result” of “ABS”.
2. Turn the ignition switch OFF → ON → OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF or ON.
3. Start the engine.
4. Select “DATA MONITOR” of “ABS”, check “FR LH SENSOR”, “FR RH SENSOR”, “RR LH SENSOR” and
“RR RH SENSOR”.
NOTE:
Set the “DATA MONITOR” recording speed to “10 msec”.
5. Read the values (wheel speed) of both the norma l wheel sensors and malfunctioning wheel sensor.
NOTE:
Vehicle must be driven after repair or replacement to erase the previous DTCs.
Revision: August 2015 2016 Versa Note

cardiagn.com

C1105, C1106, C1107, C1108 WHEEL SENSOR
BRC-65
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Note the difference at 50 km/h (31 MPH) between t he wheel speed detected by the malfunctioning wheel sen-
sor and the maximum/minimum wheel speed detected by the normal wheel sensors, is the difference within
5%, respectively?
YES >> GO TO 5.
NO >> GO TO 6.
5.PERFORM SELF-DIAGNOSIS (1)
With CONSULT
1. Stop the vehicle.
2. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
3. Start the engine. NOTE:
Wait at least 10 seconds after start the engine.
4. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1105”, “C1106”, “C1107” or “C1108” detected?
YES >> GO TO 6.
NO >> Inspection End.
6.CHECK WHEEL SENSOR AND SENSOR ROTOR
1. Turn the ignition switch OFF.
2. Disconnect wheel sensor harness connector.
3. Remove dust and foreign matter adhered to the wheel sensor and sensor rotor with a vacuum dust collec- tor through the wheel sensor mounting hole.
CAUTION:
Install wheel sensor with no backl ash and float, and tighten the mounting bolt to the specified
torque.
• Front: Refer to BRC-140, "
FRONT WHEEL SENSOR : Exploded View".
• Rear: Refer to BRC-141, "
REAR WHEEL SENSOR : Exploded View".
>> GO TO 7.
7.CHECK WHEEL SENSOR
Check the wheel sensor for damage.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 9.
8.CHECK WHEEL SENSOR OUTPUT SIGNAL
1. Disconnect ABS actuator and electric unit (control unit) harness connector.
2. Connect ABS active wheel sensor tester (SST: J-45741-A) to wheel sensor using appropriate adapter.
3. Turn the ABS active wheel sensor tester power switch ON. NOTE:
The green POWER indicator should illuminate. If the POWER indicator does not illuminate, replace the
battery in the ABS active wheel sensor tester before proceeding.
4. Spin the wheel of the vehicle by hand and observe the red SENSOR indicator on the ABS active wheel
sensor tester. The red SENSOR indicator should flash ON and OFF to indicate an output signal.
NOTE:
If the red SENSOR indicator illuminates but does not flash, reverse the polarity of the tester leads and
retest.
Does the ABS active wheel s ensor tester detect a signal?
YES >> GO TO 12.
NO >> GO TO 9.
9.REPLACE WHEEL SENSOR (1)
With CONSULT
1. Replace the wheel sensor.
- Front: Refer to BRC-140, "
FRONT WHEEL SENSOR : Removal and Installation".
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-66
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1105, C1106, C1107, C1108 WHEEL SENSOR
- Rear: Refer to
BRC-141, "REAR WHEEL SENSOR : Removal and Installation".
2. Connect ABS actuator and electric unit (control unit) harness connector.
3. Erase “Self Diagnostic Result” of “ABS”.
4. Turn the ignition switch OFF → ON → OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF or ON.
5. Start the engine.
6. Select “DATA MONITOR” of “ABS”, check “FR LH SENSOR”, “FR RH SENSOR”, “RR LH SENSOR” and
“RR RH SENSOR”.
NOTE:
Set the “DATA MONITOR” recording speed to “10 msec”.
7. Read the values (wheel speed) of both the norma l wheel sensors and malfunctioning wheel sensor.
NOTE:
Vehicle must be driven after repair or replacement to erase the previous DTCs.
Note the difference at 50 km/h (31 MPH) between the wheel speed detected by the malfunctioning wheel sen-
sor and the maximum/minimum wheel speed detected by t he normal wheel sensors, is the difference within
5%, respectively?
YES >> GO TO 10.
NO >> GO TO 20.
10.PERFORM SELF-DIAGNOSIS (2)
With CONSULT
1. Stop the vehicle.
2. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
3. Start the engine.
NOTE:
Wait at least 10 seconds after start the engine.
4. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1105”, “C1106”, “C1107” or “C1108” detected?
YES >> GO TO 11.
NO >> Inspection End.
11 .CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Check the ABS actuator and electric unit (contro l unit) harness connector for disconnection or looseness.
3. Check the wheel sensor harness connector for disconnection or looseness.
Is the inspection result normal?
YES >> GO TO 14.
NO >> Repair / replace harness or connector, securely lock the connector, and GO TO 12.
12.CHECK DATA MONITOR (2)
With CONSULT
1. Erase “Self Diagnostic Result” of “ABS”.
2. Turn the ignition switch OFF → ON → OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF or ON.
3. Start the engine.
4. Select “DATA MONITOR” of “ABS”, check “FR LH SENSOR”, “FR RH SENSOR”, “RR LH SENSOR” and
“RR RH SENSOR”.
NOTE:
Set the “DATA MONITOR” recording speed to “10 msec”.
5. Read the values (wheel speed) of both the norma l wheel sensors and malfunctioning wheel sensor.
NOTE:
Vehicle must be driven after repair or replacement to erase the previous DTCs.
Note the difference at 50 km/h (31 MPH) between the wheel speed detected by the malfunctioning wheel sen-
sor and the maximum/minimum wheel speed detected by t he normal wheel sensors, is the difference within
5%, respectively?
Revision: August 2015 2016 Versa Note

cardiagn.com

C1105, C1106, C1107, C1108 WHEEL SENSOR
BRC-67
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
YES >> GO TO 13.
NO >> GO TO 14.
13.PERFORM SELF-DIAGNOSIS (3)
With CONSULT
1. Stop the vehicle.
2. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
3. Start the engine. NOTE:
Wait at least 10 seconds after start the engine.
4. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1105”, “C1106”, “C1107” or “C1108” detected?
YES >> GO TO 14.
NO >> Inspection End.
14.CHECK TERMINAL
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) harness connector and then check the ABS actu- ator and electric unit (control unit) pin terminals for damage or loose connection with harness connector.
3. Disconnect wheel sensor harness connector and chec k each wheel sensor pin terminals for damage or
loose connection with harness connector.
Is the inspection result normal?
YES >> GO TO 17.
NO >> Repair / replace harness, connector, or terminal, and GO TO 15.
15.CHECK DATA MONITOR (3)
With CONSULT
1. Connect ABS actuator and electric unit (control unit) harness connector.
2. Connect wheel sensor harness connector.
3. Erase “Self Diagnostic Result” of “ABS”.
4. Turn the ignition switch OFF → ON → OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF or ON.
5. Start the engine.
6. Select “DATA MONITOR” of “ABS”, check “FR LH SENSOR”, “FR RH SENSOR”, “RR LH SENSOR” and “RR RH SENSOR”.
NOTE:
Set the “DATA MONITOR” recording speed to “10 msec”.
7. Read the values (wheel speed) of both the norma l wheel sensors and malfunctioning wheel sensor.
NOTE:
Vehicle must be driven after repair or replacement to erase the previous DTCs.
Note the difference at 50 km/h (31 MPH) between t he wheel speed detected by the malfunctioning wheel sen-
sor and the maximum/minimum wheel speed detected by the normal wheel sensors, is the difference within
5%, respectively?
YES >> GO TO 16.
NO >> GO TO 17.
16.PERFORM SELF-DIAGNOSIS (4)
With CONSULT
1. Stop the vehicle.
2. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
3. Start the engine.
NOTE:
Wait at least 10 seconds after start the engine.
4. Perform “Self Diagnostic Result” of “ABS”.
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-68
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1105, C1106, C1107, C1108 WHEEL SENSOR
Is DTC “C1105”, “C1106”, “C1107” or “C1108” detected?
YES >> GO TO 17.
NO >> Inspection End.
17.CHECK WHEEL SENSOR HARNESS
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Disconnect wheel sensor harness connector.
4. Check the continuity between ABS actuator and electric unit (control unit) harness connector and ground.
Power Supply Circuit
Is the inspection result normal?
YES >> GO TO 18.
NO >> Repair / replace harness or connector, and GO TO 18.
18.CHECK DATA MONITOR (4)
With CONSULT
1. Connect ABS actuator and electric unit (control unit) harness connector.
2. Connect wheel sensor harness connector.
3. Erase “Self Diagnostic Result” of “ABS”.
4. Turn the ignition switch OFF → ON → OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF or ON.
5. Start the engine.
6. Select “DATA MONITOR” of “ABS”, check “FR LH SENSOR”, “FR RH SENSOR”, “RR LH SENSOR” and
“RR RH SENSOR”.
NOTE:
Set the “DATA MONITOR” recording speed to “10 msec”.
7. Read the values (wheel speed) of both the norma l wheel sensors and malfunctioning wheel sensor.
NOTE:
Vehicle must be driven after repair or replacement to erase the previous DTCs.
Note the difference at 50 km/h (31 MPH) between the wheel speed detected by the malfunctioning wheel sen-
sor and the maximum/minimum wheel speed detected by t he normal wheel sensors, is the difference within
5%, respectively?
YES >> GO TO 19.
NO >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-144, "
Removal and Instal-
lation".
19.PERFORM SELF-DIAGNOSIS (5)
With CONSULT
1. Stop the vehicle.
2. Turn the ignition switch OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
3. Start the engine. NOTE:
Wait at least 10 seconds after start the engine.
4. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1105”, “C1106”, “C1107” or “C1108” detected?
YES >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-144, "Removal and Instal-
lation".
ABS actuator and electric unit (control unit)
—Continuity
Connector Terminal
E33 36
Ground No
27
29
34
Revision: August 2015
2016 Versa Note

cardiagn.com

BRC-70
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1109 POWER AND GROUND SYSTEM
C1109 POWER AND GROUND SYSTEM
DTC DescriptionINFOID:0000000012430858
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if DTC is PAST or CRNT. If DTC is CRNT, proceed with Diagnosis Procedure. If DTC is PAST, clear
the DTC. Do not replace the
ABS actuator and electric unit (control unit) for a PAST DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn the ignition switch OFF
and wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
2. Start the engine. NOTE:
Wait at least 10 seconds after starting the engine.
3. Drive the vehicle at 20 km/h (12 MPH) or more for approx. 2 minutes.
4. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1109” detected?
YES-1 >> “C1109” is displayed as “CRNT”: Proceed to BRC-70, "Diagnosis Procedure".
YES-2 >> “C1109” is displayed as “PAST”: Inspection End (Erase “Self Diagnostic Result” of “ABS”).
NO-1 >> To check malfunction symptom before repair: Refer to GI-42, "
Intermittent Incident".
NO-2 >> Confirmation after repair: Inspection End.
Diagnosis ProcedureINFOID:0000000012430859
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Check the ABS actuator and electric unit (contro l unit) harness connector for disconnection or looseness.
Is the inspection result normal?
YES >> GO TO 3.
DTC Display Item
(Trouble diagnosis content) Malfunction detected condition
C1109 BATTERY VOLTAGE [ABNORMAL]
(Battery voltage [abnormal]) When ignition power supply voltage is in following state:
• Ignition power supply voltage: 10 V
≥ ignition power supply voltage.
• Ignition power supply voltage: 16 V ≤ ignition power supply voltage.
PAST DTC CRNT DTC
• Harness or connector
• ABS actuator and electric unit (control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery
• Charge system • Harness or connector
• ABS actuator and electric unit (control unit)
• IPDM E/R
• ABS actuator and electric unit
(control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery
• Charge system
Revision: August 2015 2016 Versa Note

cardiagn.com

C1109 POWER AND GROUND SYSTEMBRC-71
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
NO >> Repair / replace harness or connector, securely lock the connector, and GO TO 2.
2.PERFORM SELF-DIAGNOSIS
1. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
2. Start the engine.
NOTE:
Wait at least 10 seconds after starting the engine.
3. Drive the vehicle at 20 km/h (12 MPH) or more for approx. 2 minutes.
4. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1109” detected?
YES >> GO TO 3.
NO >> Inspection End.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY AND GROUND CIR-
CUIT
Check the ABS actuator and electr ic unit (control unit) power supply and ground circuits. Refer to BRC-121,
"Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair / replace harness, connector, fuse, or fusible link.
4.CHECK TERMINAL
1. Check the ABS actuator and electric unit (control unit) pin terminals for damage or loose connection with harness connector.
2. Check the IPDM E/R pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-144, "Removal and Instal-
lation".
NO >> Repair / replace harness, connector, or terminal.
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-72
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1110, C1153 ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
C1110, C1153 ABS ACTUATOR AND EL
ECTRIC UNIT (CONTROL UNIT)
DTC DescriptionINFOID:0000000012430860
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if DTC is PAST or CRNT. If DTC is CRNT, proceed with Diagnosis Procedure. If DTC is PAST, clear
the DTC. Do not replace the ABS actuator and electric unit (control unit) for a PAST DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn the ignition switch OFF
and wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Turn the ignition switch OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
2. Start the engine.
NOTE:
Wait at least 10 seconds after starting the engine.
3. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1110” or “C1153” detected?
YES-1 >> “C1110” or “C1153” is displayed as “CRNT”: Proceed to BRC-73, "Diagnosis Procedure".
YES-2 >> “C1110” or “C1153” is displayed as “PAST”: Inspection End (Erase “Self Diagnostic Result” of
“ABS”).
NO-1 >> To check malfunction symptom before repair: Refer to GI-42, "
Intermittent Incident".
NO-2 >> Confirmation after repair: Inspection End.
DTC Display Item
(Trouble diagnosis content) Malfunction detected condition
C 111 0 CONTROLLER FAILURE
(Controller failure) When there is an internal malfunction in the ABS ac
tuator and electric unit (control unit).
C1153 EMERGENCY BRAKE
(Emergency brake) When ABS actuator and electric
unit (control unit) is malfunctioning (Pressure increase
is too much or too little).
DTC PAST DTC CRNT DTC
C 111 0 • The vehicle travels near high-voltage electrical power
lines.
• Motor built-in the ABS actuator and electric unit (control
unit) operates temporarily without a break.
• Harness or connector
• ABS actuator and electric unit (control unit) power supply system
•Fuse
• Fusible link
• Battery • Incomplete neutral position adjustment of steering angle-
sensor
• ABS actuator and electric unit (control unit)
• Harness or connector
• ABS actuator and electric unit (control unit) power supply
system
•Fuse
• Fusible link
•Battery
C1153 • The vehicle travels near high-voltage electrical power
lines.
• ABS operates for a long time (e.g. travel under a tire hy- droplaning condition). ABS actuator and electric unit (control unit)
Revision: August 2015
2016 Versa Note

cardiagn.com
