EM-8
< PREPARATION >[HR16DE]
PREPARATION
Spark plug wrench
Removing and installing spark plug
a: 14 mm (0.55 in)
Pulley holder Crankshaft pulley removing and installing
Valve seat cutter set Finishing valve seat dimensions
Piston ring expander Removing and installing piston ring
Valve guide drift Removing and installing valve guide
Valve guide reamer (1): Reaming valve guide inner hole
(2): Reaming hole for oversize valve guide
(J-43897-18)
(J-43897-12)
Oxygen sensor thread cleaner Reconditioning the exhaust system threads
before installing a new air fuel ratio sensor
(Use with anti-seize lubricant shown below.)
A: [18 mm (0.71 in) dia.] for zirconia heated
oxygen sensor
B: [12 mm (0.47 in) dia.] for titania heated
oxygen sensor
C: Mating surface shave cylinder
D: Flutes
Tool name
Description
JPBIA0399ZZ
NT035
S-NT048
S-NT030
PBIC4012E
PBIC4013E
JPBIA0238ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

PREPARATIONEM-9
< PREPARATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Acoustic tension gauge
Checking drive belt tension
Anti-seize lubricant (Permatex 133AR
or equivalent meeting MIL specifica-
tion MIL-A-907) Lubricating oxygen sensor thread cleaning
tool when reconditioning exhaust system
threads
Manual lift table caddy Removing and installing engine
1. Compression gauge
2. Adapter Checking compression pressure
Tube presser Pressing the tube of liquid gasket
Tool name
Description
PBIC3881E
AEM489
ZZA1210D
ZZA0008D
S-NT052
Revision: August 2015 2016 Versa Note

cardiagn.com

AIR CLEANER FILTEREM-19
< PERIODIC MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
AIR CLEANER FILTER
Exploded ViewINFOID:0000000012431697
Removal and InstallationINFOID:0000000012431698
REMOVAL
1. Unhook clips (A) and pull the air cleaner cover (1) upward.
1. Air cleaner cover
2. Mass air flow sensor 3. Gasket
4. Clamp 5. Air duct 6. Clamp
7. Hose 8. Clamp 9. Grommet
10. Grommet insert 11. Grommet 12. Grommet insert
13. Air duct inlet 14. Air cleaner body 15. Air cleaner filter
A. To electric throttle contro l actuator B. To rocker cover
AWBIA2082ZZ
JSBIA1092ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

EM-26
< REMOVAL AND INSTALLATION >[HR16DE]
AIR CLEANER AND AIR DUCT
AIR CLEANER AND AIR DUCT
Exploded ViewINFOID:0000000012431703
Removal and InstallationINFOID:0000000012431704
REMOVAL
NOTE:
Mass air flow sensor is removable as an assembly with the air cleaner cover.
1. Remove air duct (inlet) from the air cleaner body.
2. Disconnect PCV hose from the air duct.
3. Remove the air duct (between air cleaner case and electric throttle control actuator).
• Add matching marks if necessary for easier installation.
4. Remove air cleaner assembly with the following steps:
a. Disconnect the mass air flow sensor harness connector.
b. Remove the air cleaner body bolts.
c. Pull up on the air cleaner assembly to disengage it from the grommet and remove the air cleaner assem- bly.
CAUTION:
• Do not shock the mass air flow sensor.
• Do not disassemble the mass air flow sensor.
• Do not touch the sensor of the mass air flow sensor.
INSPECTION AFTER REMOVAL
1. Air cleaner cover 2. Mass air flow sensor 3. Gasket
4. Clamp 5. Air duct 6. Clamp
7. Hose 8. Clamp 9. Grommet
10. Grommet insert 11. Grommet 12. Grommet insert
13. Air duct inlet 14. Air cleaner body 15. Air cleaner filter
A. To electric throttle control actuator B. To rocker cover
AWBIA2082ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

EXHAUST MANIFOLDEM-31
< REMOVAL AND INSTALLATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
EXHAUST MANIFOLD
Exploded ViewINFOID:0000000012431707
Removal and InstallationINFOID:0000000012431708
REMOVAL
1. Remove air duct (inlet), air duct and air cleaner assembly. Refer to
EM-26, "Exploded View".
2. Remove exhaust front tube. Refer to EX-5, "
Exploded View".
3. Remove harness bracket from the cylinder head on the right rear side.
4. Remove exhaust manifold upper and lower covers.
5. Disconnect air fuel ratio sensor 1 harness connector.
AWBIA1603ZZ
1. Exhaust manifold cover (upper) 2. Harness bracket 3. Air-fuel ratio sensor 1
4. Exhaust manifold stay 5. Heat insulator6. Exhaust manifold
7. Exhaust manifold cover (lower) 8. Exhaust maifold gasket Engine front
Revision: August 2015 2016 Versa Note

cardiagn.com

EM-32
< REMOVAL AND INSTALLATION >[HR16DE]
EXHAUST MANIFOLD
6. Use Tool (A) to remove the air-fuel ratio sensor 1 with exhaust
manifold installed on vehicle (if necessary).
CAUTION:
• Handle air-fuel ratio sensor 1 carefully and avoid impacts.
• Before installing a new air-fu el ratio sensor 1, clean the
exhaust tube threads using suitable tool and approved
anti-seize lubricant.
• If air-fuel ratio sensor is dropped onto a hard surface, such as a concrete floor, from a height of 0.5 m or more,
discard the sensor and use a new one.
7. Remove exhaust manifold side bolt of exhaust manifold stay.
8. Remove exhaust manifold. • Loosen nuts in reverse order as shown.
9. Remove exhaust manifold gasket.
10. Remove stud bolt using suitable tool from cylinder head (if necessary).
INSPECTION AFTER REMOVAL
Mounting Surface Distortion
• Using suitable tools (A) and (B), check the surface distortion of the exhaust manifold mating surface as shown.
• Replace exhaust manifold if it exceeds the limit.
INSTALLATION
Installation is in the reverse order of removal.
Exhaust manifold
1. Install new exhaust manifold gasket. CAUTION:Tool number (A) : KV10117100 ( — )
Oxygen sensor thread cleaner : — (J-43897-12)
: — (J-43897-18)
JPBIA4126ZZ
JPBIA4127ZZ
Limit : Refer to EM-117, "Exhaust Manifold".
PBIC3530J
Revision: August 2015 2016 Versa Note

cardiagn.com

EXHAUST MANIFOLDEM-33
< REMOVAL AND INSTALLATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Do not reuse exhaust manifold gasket.
2. Tighten nuts in numerical order as shown.
3. Tighten nuts in numerical order to the specified torque again.
Air-fuel ratio sensor 1
• Use Tool (A) to install the air-fuel ratio sensor 1 (if removed). CAUTION:
• Handle it carefully and avoid impacts.
• Before installing a new air-fu el ratio sensor 1, clean the
exhaust tube threads using suit able tool and approved anti-
seize lubricant.
• Do not over-tighten the air-fuel ratio sensor 1. Doing so may damage the air-fuel ratio senso r 1, resulting in the MIL com-
ing on.
INSPECTION AFTER INSTALLATION
Inspection
• Start engine and raise engine speed to check for exhaust leaks.
JPBIA4127ZZ
JPBIA4127ZZ
Tool number (A) : KV10117100 ( — )
Oxygen sensor thread cleaner : — (J-43897-12)
: — (J-43897-18)
JPBIA4126ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

EM-48
< REMOVAL AND INSTALLATION >[HR16DE]
ROCKER COVER
ROCKER COVER
Exploded ViewINFOID:0000000012431716
Removal and InstallationINFOID:0000000012431717
REMOVAL
1. Remove ignition coil. Refer to
EM-47, "Removal and Installation".
2. Remove fuel tube protector. Refer to EM-40, "
Exploded View".
3. Remove PCV hose from rocker cover.
4. Remove PCV valve (if necessary).
5. Remove rocker cover.
1. Exhaust camshaft position sensor 2. Clip 3. Rocker cover
4. Clamp 5. Hose6. PCV valve
7. O-ring 8. Rocker cover gasket9. Oil filler cap
10. O-ring 11. Intake camshaft position sensor 12. O-ring
A. To intake manifold
AWBIA1604ZZ
Revision: August 2015 2016 Versa Note
