PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012430150
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the
battery and wait at least three mi nutes before performing any service.
Procedure without Cowl Top CoverINFOID:0000000012430151
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc. to prevent damage to
the windshield.
Precaution for Servicing Doors and LocksINFOID:0000000012430152
WARNING:
Radio waves could adversely affect electric medical equipment. Those who use a pacemaker should
contact the electric medical equipment manufacturer for the possible influences before use,
• After removing and installing the opening/closing parts, be sure to carry out fitting adjustments to check their operation.
• Check the lubrication level, damage, and wear of each part. If necessary, grease or replace it.
• When removing or disassembling each component, be ca reful not to damage or deform it. If a component
may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component
with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a shop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusabl e part, always replace it with a new one.
PIIB3706J
Revision: August 2015 2016 Versa Note

cardiagn.com

PREPARATIONDLK-191
< PREPARATION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012430153
The actual shape of the tools may di ffer from those illustrated here.
Tool number
(TechMate No.)
Tool name Description
—
(J-39570)
Chassis Ear Locating the noise
—
(J-50397)
NISSAN Squeak and Rattle Kit Repairing the cause of noise
—
(J-43241)
Remote Keyless Entry Tester Used to test keyfobs
—
(J-50190)
Signal Tech II • Activate and display TPMS transmitter
IDs
• Display tire pressure reported by the TPMS transmitter
• Read TPMS DTCs
• Register TPMS transmitter IDs
• Test remote keyless entry keyfob rela- tive signal strength
• Compatible with future sensors
• Equipped with a display
• Check Intelligent Key relative signal strength
• Confirm vehicle Intelligent Key anten- na signal strength
SIIA0993E
ALJIA1232ZZ
LEL946A
ALEIA0131ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-192
< PREPARATION >[WITHOUT INTELLIGENT KEY SYSTEM]
PREPARATION
Commercial Service Tools
INFOID:0000000012430154
KV48105501
(J-45295-A)
Transmitter Activation Tool • Activate TPMS transmitter IDs
• Compatible with future sensors
• Equipped with a display (KV48105501
only)
—
(J-46534)
Trim Tool Set Removing trim components
Tool number
(TechMate No.)
Tool name
Description
ALEIA0183ZZ
AWJIA0483ZZ
(TechMate No.)
Tool name
Description
(J-39565)
Engine Ear Locating the noise
(—)
Power Tool Loosening nuts, screws and bolts
SIIA0995E
PIIB1407E
Revision: August 2015
2016 Versa Note

cardiagn.com

DLK-194
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
REMOTE KEYLESS ENTRY SYSTEM : Fron t Door Lock Assembly (Driver Side)
INFOID:0000000012430156
• Door lock actuator and unlock sensor are Integrated in front door
lock assembly LH.
• Door lock actuator receives lock/unlock signal from BCM, and then locks/unlocks driver door.
• Only front door lock assembly LH integrates unlock sensor. Unlock sensor transmits lock/unlock status of driver door to BCM.
3. BCM Then, when the ignition switch is turned ON, BCM
performs ID verification between BCM and ECM. If
the ID verification result is OK, ECM can start en-
gine.
Refer to BCS-77, "
BODY CONTROL SYSTEM :
Component Parts Location" for detailed installation
location.
4. Main power window and door lock/unlock switch Door lock and unlock switch is integrated into the
main power window and door lock/unlock switch.
Door lock and unlock switch transmits door lock/un-
lock operation signal to BCM.
Refer to PWC-7, "
Main Power Window And Door
Lock/Unlock Switch".
5. Front door lock assembly LH Door key cylinder switch is integrated into front door
lock assembly (driver side).
Door key cylinder switch detects door LOCK/UN-
LOCK operation using mechanical key, and then
transmits the operation signal to BCM.
Refer to DLK-194, "
REMOTE KEYLESS ENTRY
SYSTEM : Front Door Lock Assembly (Driver
Side)".
6. Rear door lock actuator LH Rear door lock actuator locks/unlocks the rear door
latch assembly.
7. Back door lock actuator Back door lock actuator locks/unlocks the back door
latch assembly. Refer to
DLK-195, "
REMOTE KEY-
LESS ENTRY SYSTEM : Back Door Lock Assem-
bly".
8. Remote keyless entry receiver Remote keyless entry receiver receives button op-
eration signal and key ID signal of Intelligent Key,
and them transmits them to the BCM.
Refer to DLK-195, "
REMOTE KEYLESS ENTRY
SYSTEM : Remote Keyless Entry Receiver".
9. Door switch Door switch detects door open/close condition and
then transmits ON/OFF signal to BCM. Refer to
DLK-195, "
REMOTE KEYLESS ENTRY SYSTEM :
Door Switch".
No.
Component Function
JMKIA8649ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

RADIATOR CORE SUPPORTDLK-273
< REMOVAL AND INSTALLATION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
3. Remove washer tube inlet clip (A).
4. Remove radiator cap adapter bracket bolt (A) and radiator reser- voir tank bolt (B).
5. Remove horn. Refer to HRN-6, "
Removal and Installation".
6. Remove crash zone sensor. Refer to SR-24, "
Removal and Installation".
7. Remove hood lock assembly. Refer to DLK-292, "
HOOD LOCK : Removal and Installation".
8. Release hood lock release cable clips from radi ator core support upper using a suitable tool.
9. Remove upper air guide. Refer to DLK-272, "
Exploded View".
10. Remove air guide (LH/RH). Refer to DLK-272, "
Exploded View".
11. Release all harness connector clips from radiator core support upper using a suitable tool.
12. Remove bolts (A) and radiator core support upper.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation, perform hood assembl y adjustment procedure. Refer to DLK-269, "
HOOD ASSEM-
BLY : Adjustment".
RADIATOR CORE SUPPORT LOWER
RADIATOR CORE SUPPORT LOWE R : Removal and InstallationINFOID:0000000012430238
REMOVAL
1. Remove radiator core support upper. Refer to DLK-272, "RADIATOR CORE SUPPORT UPPER :
Removal and Installation".
2. Reposition the radiator and condenser.
AWKIA2567ZZ
JMKIA8027ZZ
AWKIA2568ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-312
< REMOVAL AND INSTALLATION >[WITHOUT INTELLIGENT KEY SYSTEM]
STEERING LOCK UNIT
6. Disconnect the harness connector from the key switch.
7. For models with CVT but without intelligent key system,
perform the following steps to separate key inter-
lock cable from steering lock unit:
a. Lift lock plate (A) in the direction of the arrow ( C) and remove in the direction of the arrow ( D).
b. Disconnect the key interlock cable from the steering lock unit.
8. Using suitable tool, remove tamper resistant self-shear type screw. CAUTION:
Do not reuse screw. Replace with new tamper resistant self-shear type screw.
9. Remove steering lock bracket and steering lock unit.
10. Remove NATS antenna amp. (if necessary). Refer to SEC-159, "
Removal and Installation".
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse screw. Replace with new tamper resistant self-shear type screw.
• Tighten tamper resistant self-shear type screw until head breaks off.
• Adjust the neutral position of the steering angle sensor. Refer to BRC-55, "
ADJUSTMENT OF STEERING
ANGLE SENSOR NEUTRAL POSITION : Description".
• For initialization and registration of mechanical keys, refer to CONSULT Immobilizer mode and follow the on-
screen instructions.
Removal and Installation - Ignition switchINFOID:0000000012828152
REMOVAL
1. Remove steering column cover. Refer to IP-17, "Removal and Installation".
2. Disconnect ignition switch harness connector.
3. Remove ignition switch screws and ignition switch.
INSTALLATION
Installation is in the reverse order of removal.
Adjust the neutral position of t he steering angle sensor. Refer to BRC-55, "
ADJUSTMENT OF STEERING
ANGLE SENSOR NEUTRAL POSITION : Description".
(1) :Key interlock cable
(B) :Steering lock unit
JSDIA1798ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

PRECAUTIONSEM-3
< PRECAUTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012431679
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the
battery and wait at least three mi nutes before performing any service.
Precaution for Procedure without Cowl Top CoverINFOID:0000000012431680
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
Draining Engine CoolantINFOID:0000000012431681
Drain engine coolant and engine oil when the engine is cooled.
Disconnecting Fuel PipingINFOID:0000000012431682
• Before starting work, check no fire or spark producing items are in the work area.
• Release fuel pressure before disconnecting and disassembly.
• After disconnecting pipes, plug openings to stop fuel leakage.
Removal and DisassemblyINFOID:0000000012431683
• When instructed to use SST, use specified tools. Alwa ys be careful to work safely, avoid forceful or unin-
structed operations.
• Use care to avoid damage to mating or sliding surfaces.
PIIB3706J
Revision: August 2015 2016 Versa Note

cardiagn.com

EM-6
< PREPARATION >[HR16DE]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012431688
The actual shape of the tools may differ from those illustrated here.
Tool number
(TechMate No.)
Tool nameDescription
K V 1 0 1111 0 0
(J-37228)
Seal cutter Removing oil pan (lower and upper) etc.
KV10116200
(J-26336-B)
Valve spring compressor
1. KV10115900
(J-26336-20)
Attachment
2. KV10109220
( — )
Adapter Disassembling and assembling valve mecha-
nism
Part (1) is a component of KV10116200, but
Part (2) is not so.
KV10112100
(BT-8653-A)
Angle wrench Tightening bolts for main bearing cap, cylinder
head, etc.
KV10117100
( — )
Heated oxygen sensor wrench Loosening or tightening heated oxygen sen-
sor 1
For 22 mm (0.87 in) width hexagon nut
KV10107902
(J-38959)
Valve oil seal puller Removing valve oil seal
KV10115600
(J-38958)
Valve oil seal drift Installing valve oil seal
Use side A.
a: 20 (0.79) dia. d: 8 (0.31) dia.
b: 13 (0.51) dia. e: 10.7 (0.421)
c: 10.3 (0.406) dia. f: 5 (0.20)
Unit: mm (in)
S-NT046
PBIC1650E
S-NT014
NT379
NT011
S-NT603
Revision: August 2015
2016 Versa Note

cardiagn.com
