Side Lights/Daytime Running Lights (DRL)
These are LEDs. For the replacement, contact the your
authorized dealer.
Low/High Beam Bi-Halogen Headlights
To change the bulb, proceed as follows:
1. Turn the steering wheel completely.
2. Open the protective flap by rotating the screw.
1 — Direction Indicator Bulb Protective Flap
2 — Headlamp Bulb Protective Flap
7
MAINTAINING YOUR VEHICLE 295

3. Remove the electric connector (1) and then rotate the
bulb holder (2) clockwise and remove it.4. Extract the bulb and replace it.
5. Refit the new bulb, making sure that it is locked
correctly, and reconnect the electrical connector.
6. Close the protective flap.
Low/High Beam HID & LED Headlights
For the replacement, contact the your authorized dealer.
Direction Indicators
Front:
1. Turn the steering wheel completely.
2. Open the protective flap by rotating the screw.
1 — Electrical Connector
2 — Bulb Holder 296 MAINTAINING YOUR VEHICLE

3. Rotate the bulb holder counterclockwise and remove
it.4. Rotate the bulb assembly counter clockwise to remove
from bulb holder.
5. Install the new bulb, making sure that it is locked in
correctly, and reinstall into headlamp assembly.
6. Close the protective flap.
1 — Direction Indicator Bulb Protective Flap
2 — Headlamp Bulb Protective Flap
Bulb Holder
7
MAINTAINING YOUR VEHICLE 297

Side:
1. Adjust the lens in the point shown in to compress the
retaining clip, then pull the cluster outwards.
2. Turn the bulb holder counterclockwise, remove the
bulb and replace it.
3. Install the bulb holder in the lens and turn it clock-
wise.
4. Install the cluster making sure that the internal clip
clicks into position.
1 — Lens
2 — Bulb Holder 298 MAINTAINING YOUR VEHICLE

Front Side Marker
To change the bulb, proceed as follows:
1. Turn the front wheels to gain access and then remove
the fastener from the inner wheel liner.2. Fold back wheel liner door to access bulb housing.
Fastener Location
Bulb Housing Location
7
MAINTAINING YOUR VEHICLE 299

3. Remove bulb from bulb housing then remove and
replace bulb and reinstall.
Rear Light Clusters
These contain the bulbs for the side lights, direction
indicators and brake lights.
Direction Indicators
To change the bulb, proceed as follows:
1. Remove the protective cap (one for each side) on the
side cover of the luggage compartment.
Front Side Marker Bulb
First Protective Cap
300 MAINTAINING YOUR VEHICLE

2. Remove the second protective cap inserting a hand
inside the opening.
3. Rotate clockwise to remove the bulb holder remove
the bulb from the bulb holder.4. Install the bulb by pressing it into bulb holder then
turn install the bulb holder and turn it counterclock-
wise.
5. Install the previously removed protective caps.
Tail Lights/Brake Lights
These are LEDs. For the replacement, contact the your
local dealer.
Reversing Light
WARNING!
The reversing light are located close to the exhaust
pipes; take the utmost care not to get burnt during
the bulb replacement.
Second Protective Cap
7
MAINTAINING YOUR VEHICLE 301

To replace the reversing lights turn the bulb holder
counterclockwise, remove the bulb and replace it.
Third Brake Lights
These are LEDs. For the replacement, contact your local
dealer.1 — Reverse Light Location
2 — Reverse Light Location
Reversing Light Bulb Holder
