2015 LEXUS RX450h Owners Manual

7765-2. Steps to take in an emergency
NOTICE■
Do not drive the vehicle with a flat tire
Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the wheel
beyond repair.■
Be careful when driving over bumps with the compact spare tire installed on the
vehicle.
The vehicle becomes lower when driving with the compact spare tire compared to
when driving with standard tires. Be careful when driving over uneven road sur-
faces.■
Driving with tire chains and the compact spare tire
Do not fit tire chains to the compact spare tire.
Tire chains may damage the vehicle body and adversely affect driving performance.■
When replacing the tires
When removing or fitting the wheels, tire s or the tire pressure warning valve and
transmitter, contact your Lexus dealer as the tire pressure warning valve and trans-
mitter may be damaged if not handled correctly.■
To avoid damage to the tire pressure warning valves and transmitters
When a tire is repaired with liquid seal ants, the tire pressure warning valve and
transmitter may not operate properly. If a liquid sealant is used, contact your Lexus
dealer or other qualified service shop as so on as possible. Make sure to replace the
tire pressure warning valve and transmitter when replacing the tire. (  P. 6 7 1 )

5
When trouble arises
7775-2. Steps to take in an emergency
If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation.
Check the following and perform the appropriate procedure:
■ The hybrid system will not start even though the correct starting
procedure is being followed. (  P. 1 7 7 )
One of the following may be the cause of the problem:
● The electronic key may not be functioning properly. (  P. 7 8 2 )
● There may be a malfunction in the immobilizer system. (  P. 1 2 4 )
● There may be a malfunction in the steering lock system.
● The hybrid system may be malfunc tioning due to an electrical
problem such as an open circ uit or a blown fuse. However,
depending on the type of malfunc tion, an interim measure is avail-
able to start the hybrid system. (  P. 7 7 8 )
■ The interior lights and headlights are dim, or the horn does not
sound or sounds at a low volume.
One of the following may be the cause of the problem:
● The 12-volt battery may be discharged. (  P. 7 8 4 )
● The 12-volt battery terminal co nnections may be loose or cor-
roded.
■ The interior lights and headlights do not turn on, or the horn does
not sound.
One of the following may be the cause of the problem:
● One or both of the 12-volt battery terminals may be discon-
nected.
● The 12-volt battery may be discharged. (  P. 7 8 4 )
Contact your Lexus dealer if the problem cannot be repaired, or if
repair procedures are unknown.

7785-2. Steps to take in an emergency
Emergency start function
When the hybrid system does not start, the following steps can be used as
an interim measure to start the hybr id system if the “POWER” switch is
functioning normally:
Set the parking brake.
Shift the shift lever to P.
Turn the “POWER” switch to ACCESSORY mode.
Press and hold the “POWER” swit ch for about 15 seconds while
depressing the brake pedal firmly.
Even if the hybrid system can be star ted using the above steps, the system
may be malfunctioning. Have the vehi cle inspected by your Lexus dealer.STEP 1
STEP 2
STEP 3
STEP 4

5
When trouble arises
7795-2. Steps to take in an emergency
If the shift lever cannot be shifted from P If the shift lever cannot be shifted with your foot on the brake pedal, there
may be a problem with the shift lock system (a system to prevent accidental
operation of the shift lever). Have the vehicle inspected by your Lexus
dealer immediately.
The following steps may be used as an emergency measure to ensure that
the shift lever can be shifted:
Set the parking brake.
Turn the “POWER” switch to ACCESSORY mode.
Depress the brake pedal.
Pry the cover up with a flathead
screwdriver or equivalent.
Press the shift lock override but-
ton. The shift lever can be shifted
while the button is pressed.STEP 1
STEP 2
STEP 3
STEP 4
STEP 5

7805-2. Steps to take in an emergency
If you lose your keys New genuine Lexus keys can be made by your Lexus dealer using the other
keys and the key number stamped on your key number plate.

5
When trouble arises
7815-2. Steps to take in an emergency
If the electronic key do es not operate properly
Locking and unlocking the side doors and key linked functions
Use the mechanical key (  P. 5 2 )
in order to perform the following
operations (driver’s door only):
Locks all the doors
Closes the windows and moon
roof (turn and hold)
Unlocks the door Turning the key rearward unlocks
the driver's door. Turning the key
once again unlocks the other
doors.
Opens the windows and moon
roof (turn and hold)If communication between the electron ic key and vehicle is interrupted
(  P. 62) or the electronic key cannot be used because the battery is
depleted, the smart access system with push-button start and wireless
remote control cannot be used. In such cases, the doors can be opened and
the hybrid system can be started by following the procedure below.

7825-2. Steps to take in an emergency
Starting the hybrid system
Ensure that the shift lever is in P and depress the brake pedal.
Touch the Lexus emblem side of
the electronic key to the
“POWER” switch. If any of the doors is opened or
closed while the key is being
touched to the switch, an alarm will
sound to indicate that the start
function cannot detect the elec-
tronic key.
Press the “POWER” switch within 10 seconds of the buzzer
sounding, keeping the brake pedal depressed.
In the event that the hybrid system still cannot be operated, contact your
Lexus dealer. STEP 1
STEP 2
STEP 3

5
When trouble arises
7835-2. Steps to take in an emergency
■
Stopping the hybrid system
Shift the shift lever to P and press the “POWER” switch as you normally do when
stopping the hybrid system.■
Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the elec-
tronic key battery be replaced immediately when the battery is depleted.
(  P. 6 8 7 )■
Changing “POWER” switch modes
Within 10 seconds of the buzzer sounding, release the brake pedal and press the
“POWER” switch.
The hybrid system does not start and modes will be changed each time the switch is
pressed. (  P. 1 7 8 )
