INSTRUMENT PANEL OVERVIEW
OJD012004R
25
Your vehicle at a glance
❈ The actual shape may differ from the illustration. 1. Instrument cluster .....................4-46, 4-59
2. Horn ...................................................4-39
3. Steering wheel audio control............4-173
4. Cruise control switch ..........................5-51
Speed limiter control switch ...............5-56
Cluster display mode conversion
switch .................................................4-61
5. Driver’s air bag ...................................3-50
6. Ignition switch or ENGINE START/STOP button ......5-5, 5-9
7. Hazard warning switch .....................4-110
8. Audio ................................................4-172
9. Seat warmer .......................................3-12
10. Central door lock switch ...................4-19
11. ESC OFF button...............................5-44
12. Climate control system .......4-128, 4-137
13. Cigar lighter ....................................4-155
14. Aux, USB and iPod port .................4-160
15. Power outlet ...................................4-159
16. Front passenger’s air bag ................3-50
17. Glove box .......................................4-153
JD RHD 2.QXP 2/17/2015 12:00 PM Page 5

Your vehicle at a glance
6
2
ENGINE COMPARTMENT
OJD072001R/OJD072002R
❈
The actual engine room in the vehicle may differ from the illustration. 1. Engine oil filler cap ............................7-38
2. Brake/clutch fluid reservoir ................7-43
3. Positive battery terminal ....................7-53
4. Negative battery terminal ..................7-53
5. Fuse box ............................................7-68
6. Air cleaner ........................................7-46
7. Radiator cap ......................................7-42
8. Engine coolant reservoir....................7-41
9. Engine oil dipstick..............................7-38
10. Windscreen washer fluid reservoir ..7-44
■■
Petrol engine (GDI)
■■Petrol engine (MPI)
JD RHD 2.QXP 2/17/2015 12:01 PM Page 6

27
Your vehicle at a glance
1. Engine oil filler cap ............................7-38
2. Brake/clutch fluid reservoir ................7-43
3. Positive battery terminal ....................7-53
4. Negative battery terminal ..................7-53
5. Fuse box ............................................7-68
6. Air cleaner ........................................7-46
7. Radiator cap ......................................7-42
8. Engine coolant reservoir....................7-41
9. Engine oil dipstick..............................7-38
10. Windscreen washer fluid reservoir ..7-44
OJD073077R❈The actual engine room in the vehicle may differ from the illustration.
■
■
Petrol engine (T-GDI)
JD RHD 2.QXP 2/17/2015 12:01 PM Page 7

OJD072003R
❈
The actual engine room in the vehicle may differ from the illustration. 1. Engine oil filler cap ............................7-38
2. Brake/clutch fluid reservoir ................7-43
3. Positive battery terminal ....................7-53
4. Negative battery terminal ..................7-53
5. Fuse box ............................................7-68
6. Air cleaner ........................................7-46
7. Radiator cap ......................................7-42
8. Engine coolant reservoir....................7-41
9. Engine oil dipstick..............................7-38
10. Windscreen washer fluid reservoir ..7-44
11. Fuel filter ........................................7-45
■■
Diesel engine
28
Your vehicle at a glance
JD RHD 2.QXP 2/17/2015 12:01 PM Page 8

Safety features of your vehicle
Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2 Front seat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
 Driver position memory system . . . . . . . . . . . . . . . . . 3-8
 Rear seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Seat belt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-20  Seat belt warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
 Lap/shoulder belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-23
 Pre-tensioner seat belt . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
 Seat belt precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 3-27
 Care of seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-30
Child restraint system . . . . . . . . . . . . . . . . . . . . . . 3-31  Using a child restraint system . . . . . . . . . . . . . . . . . . 3-33
Airbag-supplemental restraint system . . . . . . . . . 3-42  Do not install a child restraint on a front passenger’s seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-44
 Air bag warning and indicator. . . . . . . . . . . . . . . . . . 3-45
 SRS components and functions . . . . . . . . . . . . . . . . . 3-47
 Driver’s and passenger’s front air bag . . . . . . . . . . . 3-50
 Side impact air bag . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-55
 Curtain air bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-56
 SRS Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-63
 Additional safety precautions . . . . . . . . . . . . . . . . . . . 3-64
 Air bag warning label . . . . . . . . . . . . . . . . . . . . . . . . . 3-65
 Air bag warning label . . . . . . . . . . . . . . . . . . . . . . . . . 3-65
3
JD RHD 3.QXP 4/14/2015 6:39 PM Page 1

Safety features of your vehicle
2
3
Driver’s seat
(1) Seat adjustment, forward/backward
(2) Seatback recliner
(3) Seat adjustment, height
(4) Lumbar support*
(5) Seat warmer*
(6) Headrest adjustment
(7) Walk-in seat
(for 3 door vehicle only)
Front passenger seat
(8) Seat adjustment, forward/backward
(9) Seatback recliner(10) Seat adjustment, height*
(11) Lumbar support*
(12) Seat warmer*
(13) Walk-in seat (for 3 door vehicle only)
(14) Headrest adjustment Rear seat
(15) Armrest*
(16) Headrest adjustment
(17) Split folding rear seat
* : if equipped
SEAT
OJD033001R
■ Type A
■Type B
JD RHD 3.QXP 4/14/2015 6:39 PM Page 2

33
Safety features of your vehicle
✽✽NOTICE
If you have a collision accident, the front
seat may be damaged.
In this case we recommend that you
have a seat system checked by an autho-
rised Kia dealer.
WARNING - Driver’s seat
 Never attempt to adjust seat whilst the vehicle is moving. This
could result in loss of control,and an accident causing death,
serious injury, or property dam-
age.
 Do not allow anything to interfere with the normal position of the
seatback. Storing items against a
seatback or in any other way
interfering with proper locking of
a seatback could result in serious
or fatal injury in a sudden stop orcollision.
 Always drive and ride with your seatback upright and the lap por-
tion of the seat belt snug and low
across the hips. This is the best
position to protect you in case ofan accident.
 In order to avoid unnecessary and perhaps severe air bag
injuries, always sit as far back as
possible from the steering wheel
whilst maintaining comfortable
control of the vehicle. It is recom-
mended that your chest is at least
250 mm (10 inches) away fromthe steering wheel.WARNING - Loose objects
Loose objects in the driver’s foot
area could interfere with the opera-
tion of the foot pedals, possibly
causing an accident. Do not place
anything under the front seats.WARNING - Driver respon-
sibility for front seat pas-
senger
Riding in a vehicle with a front seat-
back reclined could lead to serious
or fatal injury in an accident. If a
front seat is reclined during an
accident, the occupant’s hips may
slide under the lap portion of the
seat belt applying great force to the
unprotected abdomen. Serious orfatal internal injuries could result.
The driver must advise the front
passenger to keep the seatback in
an upright position whenever the
vehicle is in motion.
WARNING
Do not use a sitting cushion that reduces friction between the seat
and passenger. The passenger's
hips may slide under the lap por-tion of the seat belt during an acci-
dent or a sudden stop. Serious orfatal internal injuries could resultbecause the seat belt can't operate
normally.
JD RHD 3.QXP 4/14/2015 6:39 PM Page 3

Safety features of your vehicle
4
3
Front seat
Manual adjustment
Forward and backward
To move the seat forward or backward:
1. Pull the seat slide adjustment lever up
and hold it.
2. Slide the seat to the position you desire.
3. Release the lever and make sure the seat is locked in place.
Adjust the seat before driving, and make
sure the seat is locked securely by trying
to move forward and backward without
using the lever. If the seat moves, it is not
locked properly.
WARNING - Rear seatbacks
 The rear seatback must be securely latched. If not, passen-
gers and objects could be thrown
forward resulting in serious
injury or death in the event of a
sudden stop or collision.
 Luggage and other cargo should be laid flat in the cargo area. If
objects are large, heavy, or must
be piled, they must be secured.
Under no circumstances should
cargo be piled higher than the
seatbacks. Failure to follow thesewarnings could result in serious
injury or death in the event of a
sudden stop, collision or rollover.
 No passenger should ride in the cargo area or sit or lie on folded
seatbacks whilst the vehicle is
moving. All passengers must be
properly seated in seats and
restrained properly whilst riding.
 When resetting the seatback to the upright position, make sure it
is securely latched by pushing it
forward and backwards.WARNING
After adjusting the seat, always
check that it is securely locked into
place by attempting to move the
seat forward or backward without
using the lock release lever.
Sudden or unexpected movement
of the driver's seat could cause you
to lose control of the vehicle result-ing in an accident.
WARNING
 Use extreme caution so that hands or other objects are not
caught in the seat mechanisms
whilst the seat is moving.
 Do not put a cigarette lighter on the floor or seat. When you oper-
ate the seat, gas may gush out of
the lighter and cause fire.
 Use extreme caution when pick- ing small objects trapped underthe seats or between the seat and
the centre console. Your hands
might be cut or injured by the
sharp edges of the seat mecha-nism.
OJD032002/H
JD RHD 3.QXP 4/14/2015 6:39 PM Page 4
