2015 INFINITI QX60 HYBRID Owner's Manual

●When no seat position is stored in the
memory switch.
● When the shift lever is moved from P (Park)
to any other position.
● When the driver’s door remains open more
than 45 seconds and the ignition switch is
not in the ON position.
● The seat synchronization function is auto-
matically disabled if the outside mirrors or
steering wheel reaches its maximum adjust-
ment.
● The seat synchronization function will not
operate if the seat is adjusted over one of the
following maximum thresholds:
– Seat sliding: 3.0 in (76 mm)
– Seatback reclining: 9.1 degrees
– Seat lifter (rear side): 0.8 in (20 mm)
The entry/exit function can be adjusted or can-
celed through the Vehicle Settings in the vehicle
information display by performing the following: ● Switch the Exit Seat Slide from ON to OFF.
● Switch the Exit Steering UP from ON to
OFF.
Pre-driving checks and adjustments3-37

MEMO
3-38Pre-driving checks and adjustments

4 Monitor, climate, audio, phone and voice
recognition systems
Control panel buttons — color screen without
Navigation System (if so equipped)..................4-4
How to use the INFINITI controller ................4-5
How to select menus on the screen ..............4-6
How to use the STATUS button ..................4-6
How to use the INFO button .....................4-6
How to use the SETTING button .................4-8
OFF button..............................4-9
ECON (fuel economy) button ..............4-9
Control panel buttons — color screen with
Navigation System (if so equipped) .................4-10
How to use the INFINITI controller ...............4-11
How to use the touch-screen . . .................4-11
Menu options ................................. 4-13
How to select menus on the screen .............4-14
How to use the STATUS button .................4-14
How to use the INFO button ....................4-14
How to use the SETTING button ................4-16
OFF button............................. 4-18
Image viewer (if so equipped) ......................4-18
Using the image viewer ........................ 4-18
RearView Monitor (if so equipped) ..................4-20
How to read the displayed lines .................4-21How to park with predicted course lines
..........4-21
Difference between predicted and actual
distances ..................................... 4-22
Predicted course line settings ...................4-25
How to adjust the screen .......................4-25
Operating tips ................................. 4-25
Around View® Monitor (if so equipped) .............4-26
Available views ................................ 4-27
Difference between predictive and actual
distances ..................................... 4-31
How to switch the display ......................4-34
Parking Sensor (if so equipped) Rear Center
Sonar (if so equipped) ......................... 4-34
Moving Object Detection (MOD) ................4-36
How to adjust the screen view ..................4-39
View malfunction .............................. 4-40
Operating tips ................................. 4-40
Vents ........................................... 4-41
Heater and air conditioner (automatic) ..............4-42
Automatic operation ........................... 4-43
Manual operation .............................. 4-43
CLIMATE setting screen ........................ 4-44
Operating tips ................................. 4-48
Servicing air conditioner ........................... 4-49

Audio system.................................... 4-49
Radio ........................................ 4-49
FM radio reception ............................ 4-50
AM radio reception ............................ 4-50
Satellite radio reception ........................ 4-50
Audio operation precautions ....................4-51
FM/AM/SAT radio with compact disc (CD)
player ........................................ 4-65
Digital Versatile Disc (DVD) Player
Operation (models with Navigation System) ......4-73
USB (Universal Serial Bus) Connection Port
(models without Navigation System)
(if so equipped) ............................... 4-77
USB (Universal Serial Bus) Connection Port
(models with Navigation System)
(if so equipped) ............................... 4-79
iPod®* player operation without Navigation
System (if so equipped) ........................ 4-82
iPod®* player operation with Navigation
System (if so equipped) ........................ 4-85
Bluetooth® streaming audio (if so equipped) .....4-88
CD care and cleaning .......................... 4-92
Steering wheel switch for audio control ..........4-92
Antenna ...................................... 4-94Dual head restraint/headrest DVD system
(if so equipped)
.................................. 4-94
System components ........................... 4-95
Before operating dual head restraint/
headrest DVD system ......................... 4-100
Playing a DVD (Digital Versatile Disc) ...........4-101
Operating tips ................................ 4-105
Care and maintenance ........................ 4-106
Car phone or CB radio ........................... 4-106
Bluetooth® Hands-Free Phone System without
Navigation System (if so equipped) ................4-107
Regulatory Information ........................ 4-109
Using the system ............................. 4-109
Control buttons .............................. 4-111
Getting started ............................... 4-112
List of voice commands ....................... 4-113
Voice Adaptation (VA) mode ...................4-118
Manual control . . ............................. 4-119
T roubleshooting guide........................ 4-120
Bluetooth®

Hands-Free Phone System with
Navigation System (if so equipped) ................4-121
Regulatory Information ........................ 4-123
Voice commands ............................. 4-123
Connecting procedure ........................ 4-124

Vehicle Phonebook........................... 4-125
Handset phonebook .......................... 4-127
Making a call ................................. 4-128
Receiving a call .............................. 4-129
During a call ................................. 4-130
Ending a call ................................. 4-130
Phone settings ............................... 4-131
Bluetooth settings ............................ 4-132
Call volume . . ................................ 4-133
INFINITI Voice Recognition System ................4-134 INFINITI Voice Recognition Standard Mode
......4-134
Using the system ............................. 4-137
Before starting . . ............................. 4-137
Giving voice commands ....................... 4-137
INFINITI Voice Recognition Alternate
Command Mode ............................. 4-142
Using the system ............................. 4-147
Speaker Adaptation function ...................4-149
Troubleshooting guide ........................ 4-150

WARNING
●Positioning of the heating or air condi-
tioning controls and display controls
should not be done while driving in or-
der that full attention may be given to
the driving operation.
● Do not disassemble or modify this sys-
tem. If you do, it may result in accidents,
fire, or electrical shock.
● Do not use this system if you notice any
abnormality, such as a frozen screen or
lack of sound. Continued use of the
system may result in accident, fire or
electric shock.
● In case you notice any foreign object in
the system hardware, spill liquid on it,
or notice smoke or smell coming from it,
stop using the system immediately and
contact your nearest INFINITI retailer.
Ignoring such conditions may lead to
accidents, fire or electrical shock.
1. INFO button (P. 4-6)
2. STATUS button (P. 4-6)
3. INFINITI controller (P. 4-5)
4. DISP (display) button (P. 4-9) 5. + (brightness control) button (P. 4-9)
6. – (brightness control) button (P. 4-9)
7.
OFF brightness control button
(P. 4-9)
8.
BACK (previous) button (P. 4-5)
LHA2110
CONTROL PANEL BUTTONS — COLOR
SCREEN WITHOUT NAVIGATION
SYSTEM (if so equipped)
4-4Monitor, climate, audio, phone and voice recognition systems

9. ENTER button (P. 4-5)
10. SETTING button (P. 4-8)
11.
ECON (fuel economy) button (P. 4-9)
CAUTION
● The glass display screen may break if it
is hit with a hard or sharp object. If the
glass screen breaks, do not touch it.
Doing so could result in an injury.
● To clean the display, never use a rough
cloth, alcohol, benzine, thinner or any
kind of solvent or paper towel with a
chemical cleaning agent. They will
scratch or deteriorate the panel.
● Do not splash any liquid such as water
or car fragrance on the display. Contact
with liquid will cause the system to
malfunction.
When you use this system, make sure the engine
is running.
If you use the system with the engine not
running (ignition ON or ACC) for a long
time, it will discharge the battery, and the
engine will not start. Reference symbols:
ENTER button — This is a button on the control
panel.
“Example” — Words marked in quotes refer to a
key shown on the display. These keys can only be
selected using the INFINITI controller.
HOW TO USE THE INFINITI
CONTROLLER
Choose an item on the display by rotating or
pushing the center dial
2upward or downward.
Press the ENTER button
1to select an item.
If you press either of the
BACK buttons3
before the operation is completed, the operation
will be canceled and/or the display will return to
the previous screen.
After the operation is complete, press either of
the
BACK buttons3to return to the
previous screen.
SAA2956
Monitor, climate, audio, phone and voice recognition systems4-5

HOW TO SELECT MENUS ON THE
SCREEN
Vehicle functions are viewed on the center dis-
play screen in menus. Whenever a menu selec-
tion is made or menu item is highlighted, different
areas on the screen provide you with important
information. See the following for details:1. Header: Shows the path used to get to the current
screen (for example, press the SETTING
button > then select the “Clock” key, then
select the “Time Zone” key) . 2. Menu Selections:
Shows the options to choose within that
menu screen (for example, Pacific time zone,
Mountain time zone, etc.) .
3. UP/DOWN Movement Indicator: Shows that the INFINITI controller may be
used to move UP/DOWN on the screen and
select more options.
4. Screen Count: Shows the number of menu selections avail-
able for that screen (for example, 1/9) .
5. Footer/Information Line: Provides more information (if available)
about the menu selection currently high-
lighted (for example, manually set the time
zone) .HOW TO USE THE STATUS
BUTTON
To display the status of the audio, climate control
system and fuel consumption, press the STATUS
button.
The following information will appear when the
STATUS button is pressed multiple times:
Audio →Audio and climate control system →
Audio and fuel consumption →Audio
HOW TO USE THE INFO BUTTON
Press the INFO button. This screen sets or dis-
plays various information that is helpful for using
the vehicle. Available items include fuel economy
and maintenance information.
LHA1300WHA1149
4-6Monitor, climate, audio, phone and voice recognition systems
