2014 VOLKSWAGEN PASSAT CC Owners Manual

Back
– Mirror down (on/off)
– Mirror adjust
Individually
Both mirrors
Back
– Factory setting
– Back
▪ Lights & Vision
– Coming Home
– Leaving Home
– Footwell light
– Conv. turn sig. (convenience turn signal)
– Factory setting
– Back
▪ Time
– Hours
– Minutes
– 24 hr. mode
– Daylight save
– Back
▪ Snow tires (winter tires)
– On
– + 10 km/h
– - 10 km/h
– Back
▪ Compass (vehicles without navigation system)
– Zone
– Calibrate
– Back
▪ Units
– Temperature
– Consump./dist.
– Air pressure
– Back
▪ Tire pressure
▪ Alt. speed dis. (alternative speed display On/Off)
▪ Service
– Info
– Back
▪ Factory setting

Using the instrument cluster menus

Fig. 13 Right side of the multi-function steering wheel: Controls for menus in the instrument cluster.

Applicable only in the United States
Driver assistance systems button

Fig. 14 In the turn signal and high beam lever: Driver assistance systems button.

Menu Function See
Assistants Turn the Adaptive Front Lighting System (AFS) on and off (if applicable).
Vehicle status Current warning and information messages. This menu item is only displayed when warning or infor-mation messages are available. The number of available messages is shown in the display. Example: 1/1 or 2/2.

Settings Includes the Convenience and Lights & Vision submenus, as well as many settings such as time, speed warning for winter tires, language, and units.


MFI menu (Multi-Function Indicator)

Display Function
Av. consumption --.- mpg Average fuel consumption in miles per gallon (l/100 km) on trips per trip memories 1 and 2 (toggle) is displayed once the vehicle has been driven about 330 feet (100 m). Until then, dashes appear instead of a number. The value displayed is updated every 5 seconds. Av. consumption --.- l/100 km
Range

Applicable only in the United States
Settings menu

Settings menu Function
Compass Calibrate the compass on vehicles without a factory-installed navigation sys-tem. To calibrate, follow the instructions in the instrument cluster display.
Units Set the units in which temperature, fuel consumption, and distances should be displayed (for example, whether to show distance driven in miles or kilome-ters).
Tire pressure Reset the tire pressure, for example after replacing tires.
Alt. speed dis. Activate/deactivate the alternative speed display (mph or km/h).
Service View the service reminder display.
Factory setting Reset the functions in the Settings menu back to the factory settings.

Applicable only in the United States
Convenience submenu

Convenience menu Function
Unlock doors
Doors are unlocked as follows depending on the option selected: – All doors: Pushing the unlock button 0 on the remote control vehicle key unlocks all doors and the luggage com-partment lid. – Single door: Pushing the unlock button 0 on the remote control vehicle key unlocks only the driver door. To unlock all doors and the luggage compartment, push the unlock button 0 on the key a second time within about 5 seconds. On vehicles with Keyless Access, touching the sensor sur-face of the door handle on the side where the valid vehicle key is located unlocks the respective door. – Vehicle side: Pushing the unlock button 0 on the remote control vehicle key unlocks the doors on the driver side of the vehicle. On vehicles with Keyless Access, touching the sensor sur-face of a door handle on the side where the valid vehicle key is located unlocks the doors on that side of the vehicle.
Window op.
Off Power window settings when unlocking/locking the driver door. All
Driver
Back The display switches back to the Convenience menu.
Mirror down Tilts passenger mirror down when backing up so you can see the curb. Feature only available on vehicles equipped with memory seats.
Mirror adjust IndividuallyBoth outside mirrors are adjusted separately.
Both mirrorsThe front passenger outside mirror is adjusted at the same time as the driver outside mirror.
Back The display returns to the Convenience menu.
Factory setting Resets the features in the Convenience submenu back to the factory set-tings.
Back The display returns to the Settings menu.
Applicable only in Canada
Convenience submenu
