2014 VOLKSWAGEN PASSAT CC Owners Manual

NOTICE
If the vehicle's battery fails or the power windows won't work, the door windows are not lowered when the door is opened or closed. Always close and open the door carefully to help prevent damage to the window, the paint, or the rubber seal.
NOTICE
To help prevent vehicle damage, carefully remove and properly reinstall parts after emergency locking or unlocking.
Manually unlocking and locking the driver door

Fig. 171 Door handle on driver door: Concealed lock cylinder.

The driver door can be unlocked separately from the inside the vehicle by pulling the door handle to open the door, Unlocking or locking the vehicle from the inside.
The anti-theft alarm system, when installed, is not activated when the vehicle is locked manually with the emergency key, Power locking and closing system.
Manually locking the passenger doors

Fig. 172 On the edge of the right rear door: Emergency lock, covered by a rubber seal.

Fig. 173 Locking the vehicle using the emergency key.

x Make sure that the door is locked.
x Repeat the procedure for other doors if necessary.
x Have the vehicle checked immediately by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
The vehicle doors can be unlocked and opened separately from inside the vehicle by pulling the door handle to open the door, Power locking and closing system.
Opening the luggage compartment lid from inside the luggage
compartment

Fig. 174 Inside the luggage compartment: Unlocking luggage compartment lid.

Emergency closing of the power sunroof

Fig. 175 In headliner: Removing cover.

Fig. 176 Hexagonal head screw for closing the power sunroof.

4. Install the cover again.
5. Have the power sunroof checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Emergency closing may cause the power sunroof and its pinch protection to malfunction.
Emergency release for the selector lever lock

Fig. 177 Removing the selector gate cover.

Fig. 178 Releasing the selector lever lock (Versions A and B).

Removing the selector gate cover
x Pull upward on the cover around the selector lever sleeve ⇒ fig. 177.
x Slip the cover up and over the selector lever ⇒ .
Emergency release for the selector lever (Version A)
x With the screwdriver from the vehicle tool kit, carefully push the release lever ⇒ fig. 178 A in the direction of the arrow and hold it in this position.
x Press the release button in the selector lever handle and shift the selector lever to Neutral (N).
x Carefully press the selector gate cover back in place, making sure that the electrical wiring stays in the correct position and is not pinched or damaged.
Emergency release for the selector lever (Version B)
x Push the release lever B in the direction of the arrow and hold it in this position.
x Press the release button in the selector lever handle and shift the selector lever to Neutral (N).
x Carefully press the selector gate cover back in place, making sure that the electrical wiring stays in the correct position and is not pinched or damaged.
WARNING
Never shift the transmission out of Park (P) without first setting the electronic parking brake. Otherwise, the vehicle can start to roll unexpectedly, especially on hills or inclines, and cause an accident and serious injuries.
NOTICE
Even with the selector lever is in Neutral (N), the automatic transmission will be damaged if the vehicle is towed (or you let it coast) for an extended period or at high speed with the engine shut off.

Vehicle tool kit

Storage

Fig. 179 In the luggage compartment underneath the floor panel 1: Spare tire and cover 3 for vehicle tool kit.
