x The rear seat backrest is unlocked when the red mark on the button ⇒ fig. 95 (2) is visible.
x If the rear backrest is folded down, no one, including children, may ride on the rear seat.
Folding the rear seat backrest back into place
x Fold the rear seat backrest back until it engages securely ⇒ .
x The red mark on the release button (2) should no longer be visible.
x The rear seat backrest must be securely latched into place in order for the safety belts on the rear seats to provide optimal protection.
WARNING
Improper folding and improper latching of the rear seat backrest can cause serious personal injury.
x Always make sure there are no people or animals in the area around the rear seat backrest when folding it forward.
x Never fold the rear seat backrest forward or back while the vehicle is moving.
x When folding the rear seat backrest back up, make sure that the safety belt does not get caught or damaged.
x Keep hands, fingers, feet and other body parts out of the way when folding the rear seat backrest forward or back.
x Each rear seat backrest must be securely latched in the upright position so that the safety belts on the rear seats can provide protection. This is particularly the case for the middle seat on the rear seat bench.
x If a seat is used with an unsecured backrest, the passenger will move forward together with the rear seat backrest during sudden braking, driving maneuvers, or in a collision.
x If the red marking on the button (2) is visible, this indicates that the backrest is not latched into place. Always check to make sure that the red marking is not visible whenever the rear seat backrest is in the upright position.
x No one, including children, may ride on the rear seats if the rear seat backrest is folded down or not correctly latched.
NOTICE
Before folding the rear seat backrest forward, adjust the front seats so that the rear seat's head restraint or backrest cushion will not touch the front seats.

Luggage compartment pass-through

Fig. 97 In the rear seat backrest: Opening the luggage compartment pass-through.

Fig. 98 In luggage compartment: Release lever with marking 1.

Closing the pass-through
x Fold the pass-through cover back until it engages securely. The red marking on the luggage
compartment side ⇒ fig. 98 (1) should not be visible.
x Close the luggage compartment lid.
x If the pass-through is equipped with a lock, use the emergency key, Vehicle key set to lock the luggage compartment pass-through.
x If necessary, fold the center armrest up.
The pass-through can also be opened from the luggage compartment. Press the release lever (1) down and push the cover forward.
Tie-downs

Fig. 99 In the luggage compartment: Tie-downs.

WARNING
Unsuitable, worn, or damaged tie-down straps (elastic or non-elastic) can snap or come loose during braking or other maneuvers or in a collision. Objects secured with these straps can then come loose and fly through the passenger compartment, causing severe personal injuries or death.
x To help prevent baggage or other items from coming loose and flying around, always use suitable undamaged tie-down straps.
x Securely fasten the tie-down straps to the tie-downs.
x Loose or improperly secured objects in the luggage compartment can slide about suddenly and change the vehicle's handling.
x Secure even small and light objects. Loose objects in the luggage or passenger compartment can fly about during sudden braking maneuvers or in the event of an accident and injure occupants.
x Never exceed the maximum allowable load on the tie-downs when securing objects.
x Never secure a child seat to the tie-downs.
WARNING
Elastic straps have to be stretched when being attached to the tie-downs in the luggage compartment. Hooks on these straps can cause serious personal injury if not handled properly and attached securely.
x Always protect eyes and face from injury from the hooks when attaching them to the tie-downs in the luggage compartment.
x Always hold the hooks on elastic straps firmly when attaching to the vehicle and do not let them snap back and hit you.
x First attach the hooks on the straps to the tie-downs at the rear seat backrest in the luggage compartment and then to the tie-downs near the loading edge of the luggage compartment. This way, if one of the hooks on the elastic straps snaps back, it will move away from you, decreasing the risk of personal injury.
The maximum load for the tie-downs is about 785 lbs. (356 kg).
For suitable straps and luggage stowage systems, please see an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

Shopping bag hooks

Fig. 100 In the luggage compartment: Shopping bag hooks.

Luggage net

Fig. 101 In the luggage compartment: Luggage net hung horizontally.

Roof rack

If a roof rack is installed, fuel consumption increases due to increased air resistance.
Attaching the roof rack base carrier and roof rack

Fig. 102 Under the rubber seal above the front and rear doors: Attachment points for the base carrier.
