2014 VOLKSWAGEN PASSAT CC Owners Manual

Replacing the daytime running light bulb and parking light bulb
In some models, the daytime running lights and parking lights use LEDs. The LEDs are a component of the headlight and cannot be replaced. See your authorized Volkswagen dealer or authorized service facility for assistance.

1. Please review and follow the checklist.
2. Open the hood

8. Install the rubber cover ⇒ fig. 195 (2).
Replacing the HID bulb
See your authorized Volkswagen dealer or authorized Volkswagen Service Facility for assistance in replacing the HID bulb (1).
The illustrations show the right headlight from behind. The left headlight is arranged as a mirror image of the right.
Failure of a single LED within a headlight is not indicated. However, the = indicator light will appear if all LEDs fail.
Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.
You cannot replace the LEDs in LED daytime running lights. Contact your authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Replacing light bulbs in the front bumper

Fig. 197 In the left front bumper: Fog light.

Fig. 198 In the removed light: Replacing the bulb.

Replacing light bulbs in the front bumper (CC R-Line)

Fig. 199 In the right front bumper: Fog light.

Fig. 200 In the removed light: Replacing the bulb.

Please carry out each step only in the order specified:
11. Check if the bulb is installed securely.
12. Connect the connector (1) on the bulb so that it clicks into place.
13. Insert the light into the bumper.
14. Install the screws ⇒ fig. 199 (2).
15. Insert the cover in the bumper opposite the direction indicated by the arrow . The cover must click into place securely.
16. Make sure the cover is installed securely.
The illustrations show the right fog light. The left fog light is arranged as a mirror image of the right.
Replacing taillight bulbs in the luggage compartment lid

Fig. 201 In the luggage compartment lid: Removing the cover.

Fig. 202 In the luggage compartment lid: Removing the bulb holder.

Please carry out each step only in the order specified:
1. Please review and follow the checklist.
2. Open the luggage compartment lid.
3. Carefully pry the cover off ⇒ fig. 201 using the flat screwdriver blade from the vehicle tool
kit ⇒ fig. 180.
4. Turn the bulb holder approximately 30° counterclockwise and remove it with the bulb.
5. Replace burned out bulbs with new bulbs that are identical to the ones being replaced.
6. Insert the bulb holder in the taillight and turn it approximately 30° clockwise. The bulb holder must click into place.
7. Insert the cover. The cover must lock into place and be secure.
LEDs in the taillights in the luggage compartment lid
LEDs cannot be replaced. Contact your authorized Volkswagen dealer or authorized Volkswagen Service Facility for assistance.
Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.
Replacing taillight bulbs in the vehicle body

Fig. 204 License plate light: Removing the bulb holder.

Jump-starting
