2014 VOLKSWAGEN PASSAT CC Owners Manual

The right indicator light under the button comes on: automatic air recirculation is switched on.
The air recirculation mode Û helps prevent outside air from entering the vehicle interior.
In very hot outside temperatures, temporarily switch to air recirculation in order to cool the vehicle interior faster.
For safety reasons, air recirculation is switched off if you push the button ⇒ .
Switching manual air recirculation on and off

NOTICE
Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation system can leave residue on the evaporator and on the dust and pollen active carbon filter, resulting in permanent odors whenever the air conditioner is switched on.
When backing up and while the automatic wiper/washer is operating, air recirculation is briefly activated to help keep exhaust fumes from getting into the passenger compartment.

Refueling

WARNING
Even if empty, portable fuel containers can leak and cause a fire and serious personal injuries, especially in a crash.
x For your safety, we strongly recommend that you do not travel with a portable fuel container in your vehicle.
x If, under exceptional circumstances, you must transport a portable fuel container, please observe the following:
– Never fill a portable fuel container while it is anywhere in or on the vehicle (for example, in the luggage compartment or on top of the luggage compartment lid). Static electricity can build up while filling and can ignite fuel vapors, causing a fire.
– Always place a portable fuel container on the ground before filling. Never spill fuel inside the vehicle or luggage compartment. Fuel vapors are highly flammable.
– Always keep the filler nozzle completely inside the portable container before and during filling.
– If filling a portable container made of metal, the filler nozzle must always be in contact with the container. This will help prevent static electricity from discharging and causing a fire.
– Always observe local and state or provincial laws about the use, storage, and transportation of portable fuel containers.
– Make certain that the portable fuel container meets industry standards, such as ANSI/ASTM F852-86.
NOTICE
x Remove fuel spills from the vehicle immediately to help prevent damage to the paint, tires, and wheel housings.
x Refueling with gasoline when your vehicle has a diesel engine or refueling with diesel fuel when your vehicle has a gasoline engine can cause very serious and expensive engine and fuel system damage that is not covered by any Volkswagen Limited Warranty.
x If you put any amount of incorrect fuel in the fuel tank, do not start the engine under any circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized Volkswagen Service Facility for assistance. These fuels contain substances that can severely damage the fuel system and the engine if the engine is started.
Fuels can pollute the environment. Spilled fuel must be collected and disposed of properly, following all applicable environmental regulations.
There is no emergency release for the fuel filler flap. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.

Indicator lights and fuel gauge

Fig. 155 In the instrument cluster: Fuel gauge.

NOTICE
x Failure to heed warning lights or text WARNINGS can result in vehicle damage.
x Never drive until the fuel tank is completely empty. The irregular fuel supply can cause the engine to misfire. This allows unburned fuel to get into the exhaust system and damage the catalytic converter.
The small arrow next to the gas pump symbol in the fuel gauge shows the side of the vehicle with the fuel filler flap.
Refueling

Fig. 156 In driver door: Release switch for fuel filler flap.

Fig. 157 Fuel cap placed on the open fuel filler flap.

x The fuel filler flap is on the right rear side of the vehicle.
x Open the fuel filler flap.
x Unscrew the fuel cap counterclockwise and remove. Use the slot or the upper edge of the fuel filler
flap to hold the cap while refueling ⇒ fig. 157.
Refueling
The correct fuel grade for your vehicle, Fuel is listed on a sticker on the inside of the fuel filler flap (arrow).
x The fuel tank is full when the automatic filler nozzle pump switches off the first time ⇒ .
x Do not try to add fuel after the pump stops! Topping off the tank in this way may fill the expansion space that the tank needs and cause fuel to overflow, for example, if it gets warmer outside.
Closing the fuel filler cap
x Screw the fuel cap clockwise onto the fuel filler neck until you hear it click into place.
x Close the fuel filler flap until you hear it latch shut. The fuel filler flap must be flush with the vehicle body.
WARNING
Spilled fuel can cause fires, explosions, burns, and other severe injuries.
x Always stop refueling once the pump nozzle switches off so that the tank does not overflow.
NOTICE
Remove fuel spills from all vehicle surfaces immediately to help prevent damage to the paint, tires, and wheel housings.
Fuel spills may pollute the environment.
Fuel capacities

The engine compartment of any motor vehicle is a hazardous area. Never do any work on the engine or in the engine compartment unless you
x know exactly how to carry out the job,
x have the correct technical information and the proper tools and supplies, and
x are familiar with the necessary safety precautions ⇒ page 310, Working in the engine compartment.
Checklist
If you are uncertain in any way, have the work done by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Serious personal injury may result from improperly performed work. Make sure that you check the following items regularly. The best thing is to check them every time you refuel:
d W i n d s h i e l d w a s h e r f l u i d l e v e l , Windshield wipers and washer
d E n g i n e o i l l e v e l , Engine oil
d E n g i n e c o o l a n t l e v e l , Engine coolant
d B r a k e f l u i d l e v e l , Braking and parking
dTire pressure, Tires and wheels
Vehicle lighting necessary for driving safety:
– Turn signals
– Low beams and high beams
– Taillights
– Brake lights
– License plate lights
Information on replacing light bulbs:, Replacing light bulbs.
WARNING
Disregarding the safety-related checklist may lead to accidents and injuries.
x Please note and follow the points listed in the checklist.
