< ECU DIAGNOSIS INFORMATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
79
(W) 78
(B) Throttle position sensor 1 Input [Ignition switch: ON]
• Engine stopped
• Selector lever: D
• Accelerator pedal: Fully released More than 0.36 V
[Ignition switch: ON]
• Engine stopped
• Selector lever: D
• Accelerator pedal: Fully depressed Less than 4.75 V
80
(G) —
Sensor power supply
(Throttle position sensor) — [Ignition switch: ON] 5.0 V
81
(SB) 128
(GR) Power supply for ECM
(Backup) Input [Ignition switch: OFF] Battery voltage
(11 - 14 V)
83
(L) 92
(LG) Intake manifold runner
control valve position sen-
sor Input[Ignition switch ON]
• Engine coolant temperature: Be- tween -12 °C (10 °F) and 59 °C
(138 °F)
• Accelerator pedal: Fully released Less than 1.4 V
[Ignition switch ON]
• Engine coolant temperature: Be- tween -12 °C (10 °F) and 59 °C
(138 °F)
• Accelerator pedal: Slightly de- pressed More than 2.8 V
84
(BR) —Sensor power supply
(Intake manifold runner
control valve position sen-
sor) — [Ignition switch: ON] 5.0 V
86
(BR)
128
(GR) Ignition signal No. 1
Output[Engine is running]
• Warm-up condition
• Idle speed NOTE:
The pulse cycle changes depending
on rpm at idle 0 - 0.1 V
87
(Y) Ignition signal No. 2
90
(LG) Ignition signal No. 3
[Engine is running]
• Warm-up condition
• Engine speed: 2,000 rpm 0 - 0.2 V
91
(V) Ignition signal No. 4
89
(V) 128
(GR) ECM relay
(Self shut-off) Output[Engine is running]
[Ignition switch: OFF]
• A few seconds after turning ignition
switch OFF 0 - 1.0 V
[Ignition switch: OFF]
• More than a few seconds after turn- ing ignition switch OFF Battery voltage
(11 - 14 V)
92
(LG) —Sensor ground
(Intake manifold runner
control valve position sen-
sor) —— —
Terminal No.
(Wire color) Description
ConditionVa l u e
(Approx.)
+ − Signal name Input/
Output
JMBIA0085GB
JMBIA0086GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-100
< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
93
(Y) 128
(GR) Intake valve timing control
solenoid valve Output[Engine is running]
• Warm-up condition
• Idle speed 0 V
[Engine is running]
• Warm-up condition
• When revving engine up to 2,000rpm Quickly Battery voltage
(11 - 14 V)
94
(BR) 128
(GR) Exhaust valve timing con-
trol solenoid valve Output[Engine is running]
• Warm-up condition
• Idle speed 0 V
[Engine is running]
• Warm-up condition
• Engine speed: 2,000 rpm Battery voltage
(11 - 14 V)
97
(Y) 128
(GR) EVAP canister vent con-
trol valve Output [Ignition switch: ON] Battery voltage
(11 - 14 V)
99
(P) —CAN communication line
(CAN-L) Input/
Output ——
100 (L) —
CAN communication line
(CAN-H) Input/
Output ——
103 (V) 124
(SB) Refrigerant pressure sen-
sor Input[Engine is running]
• Warm-up condition
• Both A/C switch and blower fan mo- tor switch: ON (Compressor oper-
ates) 1.0 - 4.0 V
104 (O) —Sensor power supply
(Refrigerant pressure
sensor) — [Ignition switch: ON] 5.0 V
109 (L) 128
(GR) Ignition switch Input [Ignition switch: OFF] 0 V
[Ignition switch: ON] Battery voltage
(11 - 14 V)
11 0 (O) 111
(R) ASCD steering switch Input [Ignition switch: ON]
• ASCD steering switch: OFF 4 V
[Ignition switch: ON]
• MAIN switch: Pressed 0 V
[Ignition switch: ON]
• CANCEL switch: Pressed 1 V
[Ignition switch: ON] • ACCEL/RES switch: Pressed 3 V
[Ignition switch: ON]
• COAST/SET switch: Pressed 2 V
111 (R) —Sensor ground
(ASCD steering switch) —— —
11 3 (P) —Sensor power supply
(EVAP control system
pressure sensor) — [Ignition switch: ON] 5.0 V
11 4 (O) 124
(SB) EVAP control system
pressure sensor Input [Ignition switch: ON] 0.5 - 4.6 V
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ − Signal name Input/
Output
JMBIA1638GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ECM
EC-101
< ECU DIAGNOSIS INFORMATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)
