< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
ECU DIAGNOSIS INFORMATION
ECM
Reference ValueINFOID:0000000009462121
VALUES ON THE DIAGNOSIS TOOL
NOTE:
• The following table includes information (items) inapplicable to this vehicle. For information (items) applica- ble to this vehicle, refer to CONSULT display items.
• Numerical values in the following table are reference values.
• These values are input/output values that ECM receiv es/transmits and may differ from actual operations.
Example: The ignition timing shown by the timing light may differ from the ignition timing displayed on the
data monitor.
This occurs because the timing light shows a value calculated by ECM according to signals received from
the camshaft position sensor and other sensors related to ignition timing.
• For outlines of following items, refer to EC-77, "CONSULT Function"
.
Monitor Item Condition Values/Status
ENG SPEED • Run engine and compare CONSULT value with the tachometer indication.Almost the same speed as
the tachometer indication.
MAS A/F SE-B1 See EC-196, "Diagnosis Procedure"
.
B/FUEL SCHDL See EC-196, "Diagnosis Procedure"
.
A/F ALPHA-B1 See EC-196, "Diagnosis Procedure"
.
COOLAN TEMP/S • Engine: After warming up More than 70 °C (158 °F)
A/F SEN1 (B1) • Engine: After warming up Maintaining engine speed at 2,000 rpm Fluctuates around 2.2 V
HO2S2 (B1) • Revving engine from idle up to 3,000 rpm quickly after the following conditions
are met.
- Engine: After warming up
- After keeping engine speed between 3,500 and 4,000 rpm for 1 minute and at idle for 1 minute under no load 0 - 0.3 V
←→ Approx. 0.6 -
1.0 V
HO2S2 MNTR(B1) • Revving engine from idle up to 3,000 rpm quickly after the following conditions
are met.
- Engine: After warming up
- After keeping engine speed between 3,500 and 4,000 rpm for 1 minute and at
idle for 1 minute under no load LEAN
←→ RICH
VHCL SPEED SE • Turn drive wheels and compare CONSULT value with the speedometer indi-
cation. Almost the same speed as
speedometer indication
BATTERY VOLT • Ignition switch: ON (Engine stopped) 11 - 14 V
ACCEL SEN 1 • Ignition switch: ON
(Engine stopped) Accelerator pedal: Fully released 0.5 - 1.0 V
Accelerator pedal: Fully depressed 4.2 - 4.8 V
ACCEL SEN 2*
1• Ignition switch: ON (Engine stopped) Accelerator pedal: Fully released 0.5 - 1.0 V
Accelerator pedal: Fully depressed 4.2 - 4.8 V
TP SEN 1-B1 • Ignition switch: ON
(Engine stopped)
• Selector lever: D Accelerator pedal: Fully re
leased More than 0.36 V
Accelerator pedal: Fully depressed Less than 4.75 V
TP SEN 2-B1*
1• Ignition switch: ON (Engine stopped)
• Selector lever: D Accelerator pedal: Fully released Less than 4.75 V
Accelerator pedal: Fully depressed More than 0.36 V
FUEL T/TMP SE • Ignition switch: ON Indicates fuel tank tempera-
ture
EVAP SYS PRES • Ignition switch: ON Approx. 1.8 - 4.8 V
FUEL LEVEL SE • Ignition switch: ON Depending on fuel level of
fuel tank
START SIGNAL • Ignition switch: ON → START → ON Off → On → Off
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-92
< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
*1: Accelerator pedal position sensor 2 signal and throttle position sensor 2 signal are converted by ECM internally. Thus, the
y differ
from ECM terminals voltage signal.
*2: Before measuring the voltage, confirm that the battery is fully charged. Refer to PG-4, "How to Handle Battery"
.
TERMINAL LAYOUT
PHYSICAL VALUES
NOTE:
• ECM is located in the engine room left side near battery.
• Specification data are reference values and are measured between each terminal and ground.
• Pulse signal is measured by CONSULT.
EOP SENSOR • Engine: After warming up
• Selector lever: P or N
• Air conditioner switch: OFF
•No load Idle 1,000 - 2,000 mV
2,000 rpm 1,500 - 3,500 mV
THRTL STK CNT B1 NOTE:
The item is indicated, but not used. —
A/F SEN1 DIAG1
(B1) DTC P015A and P015B self-diagnosis is incomplete. INCMP
DTC P015A and P015B self-diagnosis is complete. CMPLT
A/F SEN1 DIAG2
(B1) DTC P014C and P014D self-diagnosis is incomplete. INCMP
DTC P014C and P014D self-diagnosis is complete. CMPLT
A/F SEN1 DIAG3
(B1) The vehicle condition is not within the diagnosis range of DTC P014C, P014D,
P015A or P015B. ABSNT
The vehicle condition is within the diagnosis range of DTC P014C, P014D,
P015A or P015B. PRSNT
HO2 S2 DIAG1 (B1) DTC P0139 self-diagnosis (delayed response) is incomplete. INCMP
DTC P0139 self-diagnosis (delayed response) is complete. CMPLT
HO2 S2 DIAG2 (B1) DTC P0139 self-diagnosis (slow
response) is incomplete. INCMP
DTC P0139 self-diagnosis (slo w response) is complete. CMPLT
SYSTEM 1 DIAG-
NOSIS A B1 DTC P117A self-diagnosis is incomplete. INCMP
DTC P117A self-diagnosis is complete. CMPLT
SYSTEM 1 DIAG-
NOSIS B B1 DTC P117A self-diagnosis
is on standby. ABSENT
DTC P117A self-diagnosis is under diagnosis. PRSENT
A/F-S ATMSPHRC
CRCT B1 Engine: After warming up, idle the engine Varies depending on vehicle
environment.
A/F-S ATMSPHRC
CRCT UP B1 Engine: Running Varies depending on the
number of updates.
Monitor Item Condition Values/Status
JSBIA0505ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ECM
EC-93
< ECU DIAGNOSIS INFORMATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Terminal No.
(Wire color) Description
ConditionVa l u e
(Approx.)
+ − Signal name Input/
Output
1
(G) 128
(GR) Throttle control motor
(Close) Output[Ignition switch: ON]
• Engine stopped
• Selector lever: D
• Accelerator pedal: Fully released 1.8 V
2
(R) 128
(GR) Throttle control motor
power supply Input [Ignition switch: ON]
Battery voltage
(11 - 14 V)
3
(BG) 128
(GR) Throttle control motor
(Open) Output[Ignition switch: ON]
• Engine stopped
• Selector lever: D
• Accelerator pedal: Fully depressed 3.2 V
4
(W) 8
(B) Knock sensor Input [Engine is running]
• Idle speed 2.5 V
5
(W) 128
(GR) Intake manifold tuning
valve motor (Close) Output[Ignition switch ON]
• Engine coolant temperature: more than -30 °C (-22 °F)
• Accelerator pedal: Depressed → ful-
ly released Battery voltage appears for about
1 second.
6
(L) 128
(GR) Intake manifold tuning
valve motor power supply Input [Ignition switch: ON]
Battery voltage
(11 - 14 V)
7
(B) 128
(GR) Intake manifold tuning
valve motor (Open) Output[Ignition switch ON]
• Engine coolant temperature: more
than -30 °C (-22 °F)
• Accelerator pedal: Fully released →
depressed Battery voltage appears for about
1 second.
8
(B) —Sensor ground
(Knock sensor) —— —
9
(Y) 10
(BR)
13
(BR) 14
(Y) 128
(GR) Fuel injector No. 4
Fuel injector No. 3
Fuel injector No. 1
Fuel injector No. 2 Output[Engine is running]
• Warm-up condition
• Idle speed NOTE:
The pulse cycle changes depending
on rpm at idle Battery voltage
(11 - 14 V)
[Engine is running]
• Warm-up condition
• Engine speed: 2,000 rpm Battery voltage
(11 - 14 V)
JMBIA0326GB
JMBIA0324GB
JMBIA0089GB
JMBIA0090GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-94
< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
12
(B) — ECM ground — — —
16
(B) — ECM ground — — —
17
(V) 128
(GR) EVAP canister purge vol-
ume control solenoid
valve Output[Engine is running]
• Idle speed
• Accelerator pedal: Not depressed even slightly, after engine starting Battery voltage
(11 - 14 V)
[Engine is running]
• Engine speed: About 2,000 rpm (More than 100 seconds after start-
ing engine.) Battery voltage
(11 - 14 V)
18
(V) 128
(GR) Fuel pump relay Output [Ignition switch: ON]
• For 1 second after turning ignition switch ON
[Engine is running] 0 - 1.0 V
[Ignition switch: ON]
• More than 1 second after turning ig- nition switch ON Battery voltage
(11 - 14 V)
21
(BR) 128
(GR) Throttle control motor re-
lay Output[Ignition switch: OFF]
Battery voltage
(11 - 14 V)
[Ignition switch: ON] 0 - 1.0 V
22
(L) 23
(B) Heated oxygen sensor 2 Input [Engine is running]
• Revving engine from idle to 3,000 rpm quickly after the following condi-
tions are met
- Engine: after warming up
- Keeping the engine speed between 3,500 and 4,000 rpm for 1 minute
and at idle for 1 minute under no
load 0 - 1.0 V
23
(B) —Sensor ground
(Heated oxygen sensor 2) —— —
25
(L) 26
(G) Engine oil temperature
sensor Input [Engine is running] 0 - 4.8 V
Output voltage varies with engine oil temperature.
26
(G) —Sensor ground
(Engine oil temperature
sensor) —— —
27
(BR) —Sensor ground
(Engine coolant tempera-
ture sensor) —— —
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ − Signal name Input/
Output
JMBIA0087GB
JMBIA0088GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ECM
EC-95
< ECU DIAGNOSIS INFORMATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O28
(SB) 27
(BR) Engine coolant tempera-
ture sensor Input [Engine is running] 0 - 4.8 V
Output voltage varies with engine coolant temperature.
30
(SB) —Sensor ground
[Camshaft position sen-
sor (PHASE)] —— —
31
(LG) 30
(SB) Camshaft position sensor
(PHASE) Input[Engine is running]
• Warm-up condition
• Idle speed
NOTE:
The pulse cycle changes depending
on rpm at idle 1.0 - 2.0
[Engine is running]
• Engine speed is 2,000 rpm 1.0 - 2.0
32
(V) —Sensor power supply
[Camshaft position sen-
sor (PHASE)] — [Ignition switch: ON] 5.0 V
33
(V) 34
(BR) Intake air temperature
sensor Input [Engine is running] 0 - 4.8 V
Output voltage varies with intake
air temperature.
34
(BR) —Sensor ground
(Mass air flow sensor, in-
take air temperature sen-
sor) —— —
35
(Y) 34
(BR) Mass air flow sensor Input [Ignition switch: ON]
• Engine stopped 1.3 V
[Engine is running]
• Warm-up condition
• Idle speed 1.3 - 1.6 V
[Engine is running]
• Warm-up condition
• Engine is revving from idle to about
4,000 rpm 1.3 - 1.6 to 2.5 V (Check for linear
voltage rise in response to en-gine being increased to about
4,000 rpm.)
36
(SB) —
Sensor power supply
(Mass air flow sensor) — [Ignition switch: ON] 5.0 V
37
(B) — Shield — — —
38
(V) —Sensor ground
(Engine oil pressure sen-
sor) —— —
Terminal No.
(Wire color) Description
ConditionVa l u e
(Approx.)
+ − Signal name Input/
Output
JPBIA4726ZZ
JPBIA4727ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-96
< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
39
(L) 38
(V) Engine oil pressure sen-
sor Input[Engine is running]
• Warm-up condition
• Idle speed 1.3 V
[Engine is running]
• Warm-up condition
• Engine speed is 2,000 rpm 2.7 V
40
(BR) 38
(V) Sensor power supply
(Engine oil pressure sen-
sor) — [Ignition switch: ON] 5.0 V
41
(W) 128
(GR) A/F sensor 1 Input [Ignition switch: ON] 2.2 V
42
(SB) —Sensor ground
[Exhaust valve timing
control position sensor] —— —
43
(LG) 42
(SB) Exhaust valve timing con-
trol position sensor Input[Engine is running]
• Warm-up condition
• Idle speed NOTE:
The pulse cycle changes depending
on rpm at idle 1.0 - 2.0
[Engine is running]
• Engine speed is 2,000 rpm 1.0 - 2.0
44
(V) —Sensor power supply
[Exhaust valve timing
control position sensor] — [Ignition switch: ON] 5 V
45
(B) 128
(GR) A/F sensor 1 Input [Engine is running]
• Engine speed is 2,000 rpm 1.8 V
Output voltage varies with air fuel ratio.
49
(W) 128
(GR) Intake manifold runner
control valve motor
(Close) Output[Ignition switch ON]
• Engine coolant temperature: Be- tween -12 °C (10 °F) and 59 °C
(138 °F)
• Accelerator pedal: Depressed → ful-
ly released Battery voltage appears for about
1 second.
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ − Signal name Input/
OutputJPBIA3359ZZ
JPBIA3360ZZ
JPBIA4730ZZ
JPBIA4731ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ECM
EC-97
< ECU DIAGNOSIS INFORMATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O50
(L) 128
(GR) Intake manifold runner
control valve motor power
supply Input [Ignition switch: ON]
Battery voltage
(11 - 14 V)
51
(B) 128
(GR) Intake manifold runner
control valve motor
(Open) Output[Ignition switch ON]
• Engine coolant temperature: Be- tween -12 °C (10 °F) and 59 °C
(138 °F)
• Accelerator pedal: Fully released →
depressed Battery voltage appears for about
1 second.
52
(B) — ECM ground — — —
53
(BR) 128
(GR) A/F sensor 1 heater Input [Engine is running]
• Warm-up condition
• Idle speed
(More than 140 seconds after start-
ing engine) 2.9 - 8.8 V
54
(Y) 128
(GR) Heated oxygen sensor 2
heater Output[Engine is running]
• Engine speed: Below 3,600 rpm af-
ter the following conditions are met
- Engine: after warming up
- Keeping the engine speed between
3,500 and 4,000 rpm for 1 minute
and at idle for 1 minute under no
load 10 V
[Ignition switch: ON]
• Engine stopped
[Engine is running]
• Engine speed: Above 3,600 rpm Battery voltage
(11 - 14 V)
56
(SB) 128
(GR) Intake valve timing inter-
mediate lock control sole-
noid valve Output[Engine is running]
• Warm-up condition
• Idle speed 0 V
[Engine is running]
• Cold condition [Engine coolant tem- perature: below 60 °C (140 °F)]
• Idle speed Battery voltage
(11 - 14 V)
58
*1
(L) —Sensor ground
[Manifold absolute pres-
sure (MAP) sensor] —— —
59
*1
(LG) 58
*1
(L)Manifold absolute pres-
sure (MAP) sensor Output[Engine is running]
• Warm-up condition
• Both A/C switch and blower fan switch: ON (Compressor operates) 4.6 V
Output voltage atmospheric pressure.
[Engine is running]
• Warm-up condition
• Idle speed 1.2 V
[Engine is running]
• Warm-up condition
• Engine speed: 2,000 rpm 1.5 V
60
*1
(V) —Sensor power supply
[Manifold absolute pres-
sure (MAP) sensor] — [Ignition switch: ON] 5.0 V
Terminal No.
(Wire color) Description
ConditionVa l u e
(Approx.)
+ − Signal name Input/
Output
JPBIA4732ZZ
JMBIA0325GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-98
< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
61
(W) 62
(R) Battery temperature sen-
sor Input[Engine is running]
• Battery temperature: 25 °C ( °F)
• Idle speed 3.3 V
62
(R) —Sensor ground
(Battery curre nt sensor,
battery temperature sen-
sor) —— —
63
(G) 62
(R) Battery current sensor Input [Engine is running]
• Battery: Fully charged
*2
• Idle speed 2.6 - 3.5 V
64
(O) —Sensor power supply
(Battery curre nt sensor) — [Ignition switch: ON] 5.0 V
70
(SB) —Sensor ground
[Crankshaft position sen-
sor (POS)] —— —
71
(LG) 70
(SB) Crankshaft position sen-
sor (POS) Input[Engine is running]
• Warm-up condition
• Idle speed NOTE:
The pulse cycle changes depending
on rpm at idle 4.0 V
[Engine is running]
• Engine speed: 2,000 rpm 4.0 V
72
(V) —Sensor power supply
[Crankshaft position sen-
sor (POS)] — [Ignition switch: ON] 5.0 V
73
(B) —Shield — — —
77
(R) 78
(B) Throttle position sensor 2 Input [Ignition switch: ON]
• Engine stopped
• Selector lever: D
• Accelerator pedal: Fully released Less than 4.75 V
[Ignition switch: ON]
• Engine stopped
• Selector lever: D
• Accelerator pedal: Fully depressed More than 0.36 V
78
(B) —Sensor ground
(Throttle position sensor
1, 2) —— —
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ − Signal name Input/
Output
JPBIA4728ZZ
JPBIA4729ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
