2014 NISSAN TEANA sensor

DAS-270
< DTC/CIRCUIT DIAGNOSIS >[MOD]
U1232 STEERING ANGLE SENSOR
U1232 STEERING ANGLE SENSOR
DTC LogicINFOID:0000000009464930
Diagnosis ProcedureINFOID:0000000009464931
1.REGISTER THE NEUTRAL POSITION
OF THE STEERING ANGLE SENSOR
1. Turn the ignition switch ON.
2. Perform registration of the neutral positi on of the steering angle sensor. Refer to DAS-233, "CONSULT
Function (AVM)".
3. Check “Self Diagnostic Result” of “AVM” with CONSULT. Refer to DAS-233, "CONSULT Function (AVM)"
.
Is
“ST ANGLE SEN CALIB” detected?
YES >> GO TO 2.
NO >> Inspection End.
2.CHECK STEERING ANGLE SENSOR
Check steering angle sensor.
Is the inspection result normal?
YES >> Replace ITS control unit. Refer to DAS-68, "Removal and Installation".
NO >> Repair or replace malfunctioning parts.
DTC Display contents of
CONSULT DTC detection condition Possible malfunction factor
U1232 ST ANGLE SEN CALIB The neutral position registration of the steering angle sen-
sor cannot finish. • Steering angle sensor
•ITS control unit
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
