.WARNING
When powered by the electric motor, the vehicle makes much less noise, both when idling
and driving, than when it is running on the internal combustion engine. It is much harder or
even impossible for the drivers of other vehicles and above all for cyclists, pedestrians, and
children to hear the vehicle when it is running on electrical power.
x Pedestrians and others can be struck and seriously injured because they cannot hear the
vehicle and tell that it is getting close to them, for instance when you are parking, backing
up, or driving in a low-speed zone where there is likely to be pedestrian traffic.
x Always watch out for pedestrians, especially small children, cyclists, and others who may
not hear the vehicle or realize that it is about to move or will cross their path of travel.
x Always be especially CAReful in residential areas, school zones, and other places where
the speed of motor vehicles is restricted and pedestrians may be at greater risk,
x Make sure the ignition and the hybrid drive system have both been turned off before
leaving the vehicle.
.WARNING
Never leave the vehicle when hybrid drive system indicator lights are still lit. The vehicle can
move if the accelerator is depressed even though the combustion engine has been stopped.
This can cause accidents and severe or lethal injuries.
x Make sure the transmission is in Park (P) before you get out of the vehicle.
.WARNING
Never support the vehicle with cinder blocks, bricks, or other objects to inspect it. The
vehicle could slip or move suddenly and cause an accident with serious personal injury.
.WARNING
Never let the hybrid battery get wet. Liquids and other fluids can cause short circuits,
electrical shock, burns, and explosions.
x Never CARry large amounts of liquids or other fluids in the luggage compartment.
x Always make sure that any containers with liquids and other fluids are properly secured
and tightly closed to prevent leakage during normal driving as well as hard cornering,
braking, and other vehicle maneuvers. Leaking liquids can get into the cover of the high-
voltage battery and the high-voltage cable connections. This can damage the electrical
system and the high-voltage battery.
.Never drive until the fuel tank is completely empty. There may not always be enough charge in
the high-voltage battery to get to the next gas station.
Warning and indicator lights

Warning lights and text messages are shown in the instrument cluster display. Acoustic warnings may
also sound at the same time.

Lights up Warnings in the instrument
cluster display Proper response
∋ Fault in the hybrid system: stop
the vehicle at a safe location!
Stop the vehicle in a safe place as soon as it is safe
to do so.
∋
Fault Hybrid system: Workshop! See an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
High-voltage battery is being
charged.
While this message appears, do not stop the engine.
2%!$9 READY.
Never leave the vehicle parked in the ready position.
Remove the remote control vehicle key out of the
ignition or for vehicle with Keyless Access press the
starter button When leaving the vehicle always take
the remote control vehicle key with you.
%

.WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
.NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Overview of special driving tips
.

The high-voltage battery is under the luggage compartment floor ⇒ fig. 255.
Cooling the high-voltage battery
There are ventilation slots under the rear seat bench that provide the high-voltage battery with cool
air. The ventilation area under the rear seat bench ⇒ fig. 256 must not be blocked or covered ⇒ .
Maintenance of the high-voltage battery
Other than taking the vehicle in for scheduled maintenance to an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility that is qualified to do work on hybrid vehicles, there is nothing
that the vehicle driver has to do to maintain the high-voltage battery.
The maintenance connection for the high-voltage battery is under the luggage compartment floor
under an orange cover. This connection is only for scheduled maintenance, which must be performed
only by specially trained service technicians. There is no need to remove the connector at any time
when the vehicle is being used ⇒  .
.WARNING
The high-voltage hybrid electrical system is dangerous and can cause burns, other serious
personal injuries, electrocution and death.
x Never open, service, repair, or disconnect the high-voltage hybrid battery.
x Never touch or let jewelry or other metal objects contact high-voltage cables or the high-
voltage battery and battery poles, especially if the cables, battery, or battery poles have been
damaged in a crash or in some other way.
x Always have work on the hybrid electrical system and on systems that could be indirectly
affected by it done by qualified, trained technicians, who have the know-how, experience,
documentation, and tools to do the work safely.
.WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
.NOTICE
x Failure to heed warning lights or text WARNINGS can result in vehicle damage.
x If the 12 Volt battery is disconnected or dead or has been replaced, there is a possibility
that the combustion engine will not automatically switch off when the vehicle is powered by
the electric motor. If this situation persists for several days, take the vehicle to an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility that is qualified to do work on
hybrid vehicles.
x Never transport water or other liquids or fluids in open containers, such as an aquarium. If
liquid is spilled in the luggage compartment, this can cause short circuits or damage the high-
voltage battery.
.NOTICE
Never block or cover the cooling air vents for the high-voltage hybrid battery under the rear
seat. Blocking or covering these vents can damage the high-voltage battery.

Explanation of fig. 259:
(1) Center cover.
(2) Right cover.
(3) Left cover.
(4) Retainers.
(5) Opening for jump starting.
(6) Warning label for high-voltage hybrid components.
(7) Engine compartment seal.
Engine compartment covers (1) and (3) must be removed in the following situations:
x Changing light bulbs in the left headlight assembly.
Engine compartment covers (1) and (2) must be removed in the following situations:
x Changing light bulbs in the right headlight assembly.
x Adding engine coolant to the low temperature coolant circuit .
Removing engine compartment cover
When removing any part of the engine compartment cover, always pull CARefully on the relevant
attachment points ⇒ .
x Open the engine hood

Lights up Possible cause Proper response
h È BRAKE Hill Hold malfunction.
Take the vehicle to an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility and have the
system checked.
k Hill Descent Assist switched on. .


Flashes Possible cause Proper response
k Hill Descent assist is regulating the
speed. .

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
.WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
.NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Hill Hold
.

Switching Park Distance Control on and off manually
x Push the  or ∗ .button once when the ignition is switched on to switch Park Distance Control
on.
x Push the  or ∗ .button again when the ignition is switched on to switch Park Distance Control
off.
The indicator light in the button comes on and stays on as long as the feature is active. The indicator
light in the button comes on and stays on as long as the feature is active.
Switching Park Distance Control on and off automatically
x Automatic activation: Shift into reverse.
x OR: Drive forward slowly (less than about 6 - 9 mph /10 - 15 km/h) and approach to within about
38 inches (95 cm) of an obstacle.
x OR: If the vehicle rolls backwards.
x Automatic deactivation: Drive faster than about 6-9 mph (10 - 15 km/h).
A chime sounds to tell you that the system is on. If the chime does not sound, PDC is not working.
Have the system inspected by an authorized Volkswagen dealer or an authorized Volkswagen Service
Facility.
Special considerations when using Park Distance Control
x In some cases, the Park Distance Control system interprets water and ice on the sensors as an
obstacle. To prevent automatic PDC activation in these cases, you can turn Park Distance Control off
permanently in the Infotainment System .
x If the distance remains the same, the warning tone volume decreases after a few seconds. If a
continuous tone sounds, its volume remains the same.
x If the vehicle moves away from the obstacle, the beeping sound stops automatically. The beep
turns on once more automatically if the vehicle approaches the obstacle again.
x There is no beeping when the transmission is in Park (P) or the electronic parking brake is
engaged.
x The volume of the audible signals can be adjusted by an authorized Volkswagen dealership or an
authorized Volkswagen Service Facility.
.WARNING
Never rely completely on the PDC for information about people and objects that might be in
the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may
not always be able to detect them.
.If you hear a long beep lasting about 3 seconds when you first turn PDC on or the indicator light
in the button starts blinking, this means there is a malfunction in the Park Distance Control system.
Switch off the Park Distance Control system with the button and have it immediately checked by an
authorized Volkswagen dealer or an authorized Volkswagen Service Facility.

Button/Knob More information. Front Climatronic controls .
OF F Switch off: Press OFF .button or adjust manually to 0. This switches Climatronic off
entirely. /&& lights up in the front Climatronic display.

.WARNING
Stale air causes driver fatigue and reduces alertness, which can cause accidents, collisions
and serious personal injury.
x Never switch off the fan for a long time and never use air recirculation a long period of
time because no fresh air will enter the passenger compartment.
Operation via the Infotainment System

Fig. 273 Infotainment System: Front climate control settings.
.
