Switching air recirculation on and off manually
Switching on: Press the .button repeatedly until the indicator light in the button comes on.
Switching off: Press the .button repeatedly until the indicator light in the button goes out.
Switching air recirculation on and off automatically
x Press the CLIMATE Infotainment button.
x Tap the Extras function key.
x Switch automatic air recirculation on or off by tapping the Automatic air recirculation function key.
If the check box in the function key is checked =,automatic air recirculation is switched on.
What automatic air recirculation does
In automatic air recirculation mode, fresh air will enter the passenger compartment. If the system
detects an increased concentration of pollutants in the outside air, it automatically switches to air
recirculation. As soon as the pollutant level is back in the normal range, air recirculation is switched
off.
Unpleasant odors cannot be detected by the system.
To keep the windows from fogging up, automatic air recirculation is not switched on automatically in
certain circumstances.
.WARNING
Stale air causes driver fatigue and reduces driver alertness, which can cause accidents,
collisions and serious personal injury.
x Never use air recirculation mode over an extended period of time, since no fresh air will
enter the passenger compartment.
x When the air conditioner is off and recirculation mode is on, condensation can quickly
form on the windows and greatly reduce visibility.
x Always switch off recirculation mode when it is not needed.
.NOTICE
Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation system
can leave residue on the evaporator and on the dust and pollen active CARbon filter, resulting
in permanent odors whenever the air conditioner is switched on.
.When backing up and while the automatic wiper/washer is operating, air recirculation is briefly
activated to avoid unpleasant odors in the passenger compartment. This feature only works if
automatic air recirculation is enabled

.WARNING
Driving with a fuel tank that is almost empty can lead to stalling in traffic, a collision, and
serious personal injuries.
x When the fuel tank is almost empty, fuel supply to the engine can be interrupted,
especially when driving up an down hills. The interruption in fuel flow could stall the engine
during a maneuver in difficult terrain and make you lose control of the vehicle.
x Steering and braking assistance as well as ESC and related systems will not work if the
engine “sputters” or stalls due to lack of fuel.
x Always refuel when the tank is 1/4 full to reduce the risk of running out of fuel and stalling
in traffic.
.NOTICE
x Failure to heed warning lights or text WARNINGS can result in vehicle damage.
x Never drive until the fuel tank is completely empty. The irregular fuel supply can cause the
engine to misfire. This allows unburned fuel to get into the exhaust system and damage the
catalytic converter or the diesel particulate filter.
.NOTICE
If the fuel tank venting system malfunctions and the fuel tank cannot be properly vented before
refueling:
x Gasoline fumes can escape from the fuel filler neck, resulting in temporary odors.
x The fuel nozzle may shut off during refueling and it will take longer to refuel the vehicle.
Only in this situation can you continue to CARefully refuel your vehicle after the fuel nozzle
shuts off.
x See your Authorized Volkswagen dealer or authorized Volkswagen Service Facility to have
your vehicle checked.
.The small arrow next to the gas pump symbol in the fuel gauge shows the side of the vehicle
with the fuel filler flap.
Misfueling guard for diesel vehicles

Fig. 278 With open fuel cap: Misfueling guard in the fuel filler neck
.

The fuel filler neck of diesel vehicles is equipped with a misfueling guard ⇒ fig. 278. The misfueling
guard helps prevent filling the fuel tank of a diesel vehicle with gasoline, because the guard makes it
difficult to insert any type of filler nozzle other than the type commonly used for diesel fuel.
Damaged, worn out, or incorrect nozzles, as well as other means of refueling (portable fuel
containers, for example) will generally not open the misfueling guard and fuel from these sources
cannot easily flow into the tank. Using these incorrect or non-standard nozzles to refuel your diesel
vehicle can cause fuel spills, which can cause fires, explosions, burns, and other severe injuries.
The misfueling guard can generally only be properly opened with a correct nozzle from a standard
diesel fuel pump. Under certain circumstances it may be necessary to turn the nozzle back and forth
slightly with light pressure to open the misfueling guard. If the misfueling guard cannot be opened this
way, see the nearest authorized Volkswagen dealer or authorized Volkswagen Service Facility and
have the fuel system checked.
.WARNING
Spilled fuel can cause fires, explosions, burns, and other severe injuries.
x Do not refuel from devices other than correct, undamaged standard diesel fuel pump
nozzles.
x Always stop refueling once the pump nozzle switches off so that the tank does not
overflow.
.NOTICE
x It is your responsibility to put the right fuel in your vehicle and any damage that results is
not covered under the Emissions warranties or any other Volkswagen Limited Warranty.
x If you put any amount of the incorrect fuel in the fuel tank, do not start the engine under any
circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized
Volkswagen Service Facility for assistance.
x If diesel fuel should get on any rubber hose, it must be wiped off immediately. The same
applies if diesel fuel gets onto other parts of the vehicle, especially paint, tires, or a plastic
part. Wash the contaminated vehicle parts right away with soap and warm water to help
prevent leaks and serious damage.
x Never force a fuel nozzle in the misfueling guard. If you have problems inserting a fuel
nozzle, first check to make sure you are using the correct diesel fuel. If you are, go to a pump
with the standard diesel nozzle. Forcing a fuel nozzle in the misfueling guard can damage it so
that it can no longer help prevent misfueling.
Fuel capacities
.

Cold diesel engines normally produce louder noises during winter conditions than during warmer
periods. In addition, the exhaust gases may be light blue in color until the engine has warmed up. The
exhaust gas volume varies depending on the outside temperature.
Do not let your diesel engine idle unnecessarily after a cold start. Driving off slowly will shorten the
warm-up period.
.WARNING
Starting fluids can explode and cause a run-away vehicle condition.
x Never use starting assist fluids.
.NOTICE
x The vehicle's diesel engine was designed solely for use with ULSD fuel. For this reason,
never use gasoline, heating oil, or other fuels that have not been expressly approved for use
with the diesel engine. These fuels contain substances that will severely damage the fuel
system and the engine. Such damage will not be covered by any Volkswagen Limited
Warranty.
x If you put any amount of the incorrect fuel in the fuel tank, do not start the engine under any
circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized
Volkswagen Service Facility for assistance.
x If diesel fuel should get on any rubber hose, it must be wiped off immediately. The same
applies if diesel fuel gets onto other parts of the vehicle, especially paint, tires, or a plastic
part. Wash the contaminated vehicle parts right away with soap and warm water to help
prevent leaks and serious damage.
x The vehicle is designed to run on diesel fuel containing methyl ester bio diesel in
concentrations of 5% or less. Never use methyl ester bio diesel in blend levels higher than 5%
(5% methyl ester blends are sometimes designated or labeled as B5). The properties of methyl
ester bio diesel blends in levels greater than 5% may cause serious damage to the fuel
injection system and to the engine. This could lead to expensive repairs that will not be
covered by any Volkswagen Limited Warranty.
x Damage to the engine and fuel system and performance problems caused by using fuels
that are different from those specified above or by using “starting assist fluids” are not the
responsibility of Volkswagen and are not covered under the Emission warranties or any other
Volkswagen Limited Warranty.

Lights up Possible cause or meaning ⇒  Proper response
b No engine restart possible! AdBlue fill
level too low.
Stop the vehicle at a safe and appropriate
place with level pavement and refuel
AdBlue
b
No engine restart possible! AdBlue-
system malfunction.
Have the system checked by an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility.
together
with
>
b AdBlue level is low.
Refill the AdBlue tank within the indicated
number of miles or kilometers Volkswagen
recommends going to an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility.
b
AdBlue system malfunctioning or not
filled standard AdBlue.
Have the system checked by an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility.
together
with
>
b AdBlue level is low.
Refill the AdBlue tank within the indicated
number of miles or kilometers Volkswagen
recommends taking the vehicle to an
authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
b
AdBlue system malfunctioning or not
filled standard AdBlue.
Have the system checked by an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility.
together
with
>

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
.WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
.NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
AdBlue information
.

In vehicles with selective catalytic reduction, a special urea solution (AdBlue) is injected into the
exhaust system ahead of the catalytic converter in order to reduce nitrogen oxide emissions.
AdBlue is stored in a separate tank of the vehicle and should be refilled under normal driving
conditions during service according to the maintenance schedule. The AdBlue tank holds slightly less
than 5 gallons (20 liters).
AdBlue consumption depends on the individual driving style, system operating temperature, and
outside air temperature. Therefore in rare cases AdBlue may have to be refilled between service
events.
Starting with a remaining range of about 1500 miles (2400 km), a reminder to refill AdBlue is displayed
in the instrument cluster. If you ignore the last refill reminder, it is impossible to start the engine again
after it is switched off
Volkswagen recommends that you have the AdBlue tank refilled by an authorized Volkswagen dealer
or an authorized Volkswagen Service Facility. If no authorized Volkswagen dealer or authorized
Volkswagen Service Facility or other qualified workshop is available, you should refill at least 1.5
gallons (5.7 liters) of AdBlue (3 AdBlue bottles). Refill only the type of AdBlue that Volkswagen has
explicitly approved for your vehicle.
If warning lights ~ and d both come on together, there is a malfunction. Volkswagen recommends that
you take the vehicle to the closest qualified workshop.
AdBlue® is a registered trademark of the German Association of the Automotive Industry (VDA) in the
United States, Germany, the European Union and in other countries.
Refilling AdBlue

Fig. 279 Luggage compartment with collapsible spare tire and AdBlue tank.

Fig. 280 AdBlue tank with filler neck cap and refill container.

.WARNING
Off-road driving can be dangerous, can lead to accidents, vehicle damage, stranding in
remote areas, and serious personal injury.
x Never drive too fast or for terrain and weather conditions.
x Always adjust your speed and driving style to road, terrain, traffic, and weather
conditions.
x Always avoid sudden, sharp maneuvers that increase the risk of loss of vehicle control or
getting stuck.
x When driving off-road look and think ahead, expect the unexpected.
x To reduce the risk of loss of control and serious personal injury, never use the cruise
control when driving off-road. Cruise control is designed for highway use. It is completely
unsuitable for off-road situations and can even be dangerous when used off-road.
.NOTICE
Always make sure the vehicle has enough ground clearance. Severe damage to the underbody
can occur if the vehicle bottoms out. The damage could disable the vehicle and leave you
stranded.
.“Tread lightly” is an educational program designed to increase public awareness of land use
regulations and responsibilities in our nation's wilderness areas. Volkswagen supports the U.S. Forest
Service and the Bureau of Land Management in encouraging you to preserve our national forests and
other public and private lands by “treading lightly”.
Technical terms explained

Fig. 281 Illustration of grade (gradient angle) A and lateral angle B.
.

Checklist
Checklist: Useful off-road driving equipment ⇒ :
d Water, compass, maps, flashlight and spare batteries.
d Cable winch, tow rod or tow rope strong enough for your vehicle.
d Cell phone, shovel, blankets, and rubber boots, tape measure, and yardstick.
d Vehicles without tire mobility set: Electric air compressor to connect to the 12 Volt outlet in the
vehicle for inflating the tires.
d A wooden plank about 2 inches thick and 3 feet long or similar aluminum frame as traction aid for a
stuck vehicle or as a base for the vehicle jack.
d Snow chains for all 4 tires, additional spare tires, and tire mobility set.
.WARNING
Accidents and severe personal injury can result from the improper use of tools or equipment
as well as from the use of tools or equipment that are damaged or not right for the job to be
done.
Safety and off-road driving
.
