Most electrical devices are shielded against RF (high-frequency) signals. In rare cases, however,
electronic devices may not be shielded against high-frequency signals emitted by the telephone
control. Interference may occur.
.Some countries may have restrictions regarding the use of Bluetooth devices. Information can
be obtained from the local authorities.
.When connecting the telephone control with a device using Bluetooth, read the device's
operating manual for detailed safety information. Use only Bluetooth-compatible devices.

via a Bluetooth connection. The cell phone logs itself out of the GSM network and logs into the
telephone control using the data from the “borrowed” SIM CARd. The telephone is then controlled
exclusively via the controls in the vehicle. The mobile phone goes into standby mode. This Bluetooth
profile allows all telephone control functions and the exterior aerial to be used to the full.
x Bluetooth Hands-Free Profile (HFP): If a cell phone is connected via HFP to the telephone
control, you can make calls wireless via the hands-free system. Many other telephone control
functions are not available. The vehicle's exterior aerial can thus not be used.
x Advanced Audio Distribution Profile (A2DP): Bluetooth profile for transferring audio signals .
.Volkswagen recommends pairing a cell phone with the telephone control via Bluetooth-rSAP in
order to use all telephone control functions.
Components of the telephone control

Fig. 222 3 button module in the roof: Controls for the telephone control.
.

x Infotainment System with touchscreen
x Multi-function steering wheel Instrument cluster display shows telephone functions x
3 button module in the roof ⇒ fig. 222
.NOTICE
To operate the telephone control, a light press of the button or light pressure on the feature
keys on the screen is sufficient.
“Bluetooth audio” wireless communication interface
.

.If the device is connected to the telephone control via A2DP, no other devices can be paired.
The Bluetooth visibility of the telephone control deactivated for the duration of the active A2DP
connection. This is not a fault in the telephone control. In order to pair further devices, deactivate the
Bluetooth audio (A2DP) feature in Telephone settings and Bluetooth settings and activate it again
after completing the pairing.
Adjusting the volume
.

.WARNING
Driving on today's roads demands the full attention of the driver at all times. Driver
distraction causes accidents, collisions and serious personal injury!
x Never pair the cell phone or configure user profiles while driving. Do this only when the
vehicle is parked in a safe place.
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System,
when using your cell phone, or when operating the cell phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your cell phone,
and the cell phone controls only if road, traffic, and weather conditions permit and you will
not be distracted from your driving.
x If you cannot use the Infotainment System, your cell phone, or the cell phone controls
safely while driving, wait until later or find a safe spot where you can pull off the road and
park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other
warning sounds outside the vehicle.
.For device search, select a location with the likelihood of only a few unknown Bluetooth devices,
for example in the garage. The search range for Bluetooth is approximately 10 meters.
Pairing a cell phone via Bluetooth-HFP
.

x If necessary activate “wait for incoming Bluetooth connections”.
x Hold the cell phone in your hand ready to enter the password within the time limit.
x Select the cell phone from the device list in the vehicle by pressing the corresponding function key.
x Select the required pairing protocol below the cell phone found.
x On the cell phone, confirm the connection queries from the vehicle if required.
x Confirm the 4-digit password displayed on the Infotainment System screen.
x Enter the password on the cell phone within 30 seconds.26
x Confirm password entry.
x If necessary, confirm further queries on the mobile phone.
Pairing procedure if a cell phone has already been paired with the telephone control
x Set the Bluetooth connection to visible on the cell phone , step 1.
x Switch on the ignition.
x Access the SETUP main menu with the SETUP Infotainment button.
x Press the Telephone function key.
x Press the Bluetooth settings function key.
x In the Bluetooth settings menu, press the Search for Bluetooth devices function key.
x If necessary, confirm the query about whether Bluetooth has been activated on the cell phone with
Next .
x CARry out pairing as described , step 3.
Failed pairing
There is no limit on the number of attempts to pair the device with the telephone control.
Linking will not be successful if the password input time limit is exceeded or if the PIN code is entered
incorrectly.
Restart linking if the process fails despite correct entries.
Copying telephone directory to the telephone control
Once pairing has been successfully completed, the telephone directory entries from the cell phone26
are loaded automatically into the data memory of the telephone control Depending on the number of
entries copied, the process can take several minutes.
The telephone directory memory of the telephone control is limited to 5000 entries. Each user profile
can be assigned a maximum of 2000 entries as well as 100 user-created or edited entries.
Automatic connection to a paired cell phone
.

When connecting automatically, the system will first search for the telephone that was last used in
order to reconnect it with the telephone control. If this cell phone is not in the Bluetooth range, the
system will start to search for the cell phone (user) that was used before it.
x Switch on the ignition.
x Enter the PIN code if it is not stored in the telephone control21.
Requirements for automatic connection
d The cell phone needs to have already been paired with the telephone control.
d The cell phone must be switched on and contain a valid SIM CARd to make telephone calls.
d Bluetooth must be activated on the cell phone.
d The mobile phone should have no connection to another Bluetooth device.
d The cell phone must be within the Bluetooth range of the telephone control.
d The ignition must be switched on.
d The cell phone must have been last connected to the telephone control or another cell phone
connected via Bluetooth is no longer in the Bluetooth range of the telephone control or its
Bluetooth feature has been switched off.
.If the automatic connection is made during an active telephone call, the telephone control can
only make a connection via HFP Change the Bluetooth connection to rSAP in order to use all
telephone control functions 27.
.If a Bluetooth connection cannot be set up even though all requirements are fulfilled or if the
telephone control does not function “normally”, the cell phone's system may have crashed. Remove
the battery and insert again. Switch the mobile phone back on and try to establish a Bluetooth
connection.
.Volkswagen recommends not switching on authorization on the cell phone so that you confirm
the connection queries again before each automatic connection setup.

21 country specific

Bluetooth settings
.
