2013 VOLKSWAGEN TIGUAN Owners Manual

Power sunroof

Applicable only in Canada
Opening and closing the power sunroof

Fig. 34 In the headliner: Rotary switch for the power sunroof. A: Turn the rotary switch to slide the sunroof
open or closed. B: Press or pull the switch to tilt open or to close.

The sunshade opens automatically when the power sunroof opens if the shade was previously com-
pletely closed or in front of the glass roof. The sunshade remains in the previous position and does not
close automatically with the sunroof. The sunshade cannot be closed completely until the power
sunroof is closed.
If your power sunroof will not close properly, do not try to close it yourself, doing so can cause serious
and expensive damage that will not be covered by any Volkswagen Limited Warranty. Special know-
ledge and tools are required to close the power sunroof if it will not close on its own. To help prevent
damage to the sunroof, have an authorized Volkswagen dealer or an authorized Volkswagen Service
Facility help you close and repair the power sunroof.
The comfort position (2) provides sufficient ventilation without loud wind noise.
Applicable only in the United States
Opening or closing the power sunroof

Fig. 35 In the headliner: Rotary switch for the power sunroof. A: Turn the rotary switch to slide the sunroof
open or closed. B: Press or pull the switch to tilt open or to close.

Function Switch position Action
To tilt open the tilting roof
fully:
(4) Push the rear part of the switch briefly.
To stop the one-touch
feature:
(4) or (5) Push or pull switch again briefly.
To set an intermediate
position: (4) to (5) Pull or push the rear part of the switch briefly
until the desired position is reached.
To close fully: (5) Pull the rear part of the switch briefly.

The power sunroof only works when the ignition is on. You can still open or close the power sunroof
for several minutes after you switch off the ignition, as long as the driver or front passenger door has
not been opened.
All procedures are interrupted as soon as the rotary switch is operated.
The sunshade opens automatically when the power sunroof opens if the shade was previously com-
pletely closed or in front of the glass roof. The sunshade remains in the previous position and does not
close automatically with the sunroof. The sunshade cannot be closed completely until the power
sunroof is closed.
If your power sunroof will not close properly, do not try to close it yourself, doing so can cause serious
and expensive damage that will not be covered by any Volkswagen Limited Warranty. Special know-
ledge and tools are required to close the power sunroof if it will not close on its own. To help prevent
damage to the sunroof, have an authorized Volkswagen dealer or an authorized Volkswagen Service
Facility help you close and repair the power sunroof.
The comfort position (2) provides sufficient ventilation without loud wind noise.
Applicable only in the United States
Opening or closing the sunshade

Fig. 36 In the headliner: buttons for sunshade.

Function Response
To open fully (one-touch
feature): Briefly press the ⇒ fig. 36 (1) button.
To stop the one-touch
feature: Briefly press the (1) button or the (2) button.
To set an intermediate
position:
Keep the (1) button or (2) button pressed until the position has been
reached.
To close fully (one-touch
feature): Briefly press the (2) button.

You can still use the sunshade for several minutes after the ignition is switched off as long as the
driver or passenger door has not been opened.
When the power sunroof is completely open the sunshade is automatically moved to a ventilation
position.
When the power sunroof is in the tilt position the sunshade will also open a small gap.
When the power sunroof is open, the electrical sunshade can only be closed up to the front edge
of the glass roof.
Applicable only in Canada
Opening or closing the sunshade

Fig. 37 In the headliner: buttons for sunshade.

Function Response
To close fully (one-touch
feature): Briefly press the (2) button.

You can still use the sunshade for several minutes after the ignition is switched off as long as the
driver or passenger door has not been opened.
When the power sunroof is completely open the sunshade is automatically moved to a ventilation
position.
When the power sunroof is in the tilt position the sunshade will also open a small gap.
When the power sunroof is open, the electrical sunshade can only be closed up to the front edge
of the glass roof.
Power sunroof – convenience closing feature

WARNING
Careless or unsupervised use of the sunroof can cause serious injuries.
x Always make sure that no one is in the way of the power sunroof when it is closing.
x Always take all vehicle keys with you when leaving the vehicle.
x Never leave children or persons requiring assistance unattended in the vehicle, especially
if they have access to the remote control vehicle key. Unsupervised use of the remote control
vehicle key can lock the vehicle, start the engine, switch on the ignition and operate the su-
nroof.
x The sunroof can still be opened or closed for a short period after the ignition has been
switched off, as long as the driver or passenger door is not opened.
WARNING
Closing the sunroof without pinch protection can cause severe injuries.
x Always be careful when closing the sunroof.
x Always make sure that no one is in the way when overriding pinch protection to close the
sunroof.
x Pinch protection does not prevent fingers or other body parts from being pressed against
the roof frame, thereby causing injury.
If the sunroof malfunctions or pinch protection does not operate properly. See an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.

Adjusting the seating position
