2013 VOLKSWAGEN TIGUAN Owners Manual

Emergency unlocking of the rear hatch

Fig. View from luggage compartment: Emergency unlocking rear hatch with the remote control vehicle key.

Fig. Releasing the selector lever lock.

Vehicle tool kit

Fig. On the right in the luggage compartment: Storage compartment.

using this number. Record the code number of the wheel bolt lock and store it separate from
the vehicle.
(3) Screw-in towing eye.
(4) Hubcap puller clips for removing hubcaps, full wheel covers or wheel bolt caps.
(5) Jack. Before putting the jack back, be sure to completely crank the jack down to its original
position. Then the crank must be clamped against the side of the jack.
(6) Lug wrench.
(7) Folding chocks
Folding chocks

Fig. Unfolding the folding chock.

Wheel covers

Hubcap

Fig. Pulling off hubcap.

x Slide the lug wrench through the clip ⇒ fig. and pull the wheel cover off in the direction of the
arrow.
Installing the wheel cover
Before installing the wheel cover, the anti-theft wheel bolt must be screwed into position ⇒ fig. (2) or
(3). Otherwise, the wheel cover cannot be installed.
Make sure that the valve cutout is aligned with the valve ⇒ fig. (1), and press the wheel cover onto
the wheel rim. Make sure that the wheel cover is latched onto the rim along the entire circumference.
Wheel bolt caps

Fig. Pulling cover caps off wheel bolts.
