2013 VOLKSWAGEN TIGUAN Owners Manual

x Light switch in position  if the vehicle has no orientation lighting
WARNING
Daytime running lights and parking lights are not bright enough to let you see ahead or be
seen by others when it is dark.
x Always switch on the low-beam headlights at dusk or when it is dark and whenever the
weather is bad or visibility is poor.
x Never use the daytime running lights to see where you are going. They are not bright
enough and will not let you see far enough ahead for safety, especially at dusk or when it is
dark. Always switch on the low-beam headlights at dusk or when it is dark.
x The taillights do not come on with the daytime running lights. Unless the taillights are on,
a vehicle cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, the taillights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in the United States
Lights and vision features

The static cornering lights work only when the headlights are on. The static cornering lights do not
come on when the headlight switch is in the / position or when the fog lights themselves have been
switched on
Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams switched on and only at speeds
above about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumination
during cornering.
On vehicles equipped with the Adaptive Front Lighting System, the feature is switched on and off via
the Assistant menu
WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, rear lights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in Canada
Lights and vision features

Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams switched on and only at speeds
above about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumination
during cornering.
On vehicles equipped with the Adaptive Front Lighting System, the feature is switched on and off via
the Assistant menu
WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, rear lights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
“Coming home” and “Leaving home” feature (orientation lighting)

Background lighting in the outside mirrors
The background lighting in the outside mirrors lights up the area close to the doors while you are
getting into or out of the vehicle. It is switched on when the vehicle is unlocked, a vehicle door is
opened, or the “Coming home” or “Leaving home” feature is activated. If the vehicle is equipped with a
light sensor, the background lighting in the outside mirrors is only switched on in darkness.
The delay period can be adjusted and the feature can be switched on and off in the Lights &
Vision menu
If the “Coming home” feature is switched on and the driver door is opened, no acoustic chime will
sound to alert you that the lights are still on.
Instrument panel lighting , headlight range adjustment

Fig. 84 Next to the headlight switch: control for instrument cluster lighting.

Interior and reading lights

Windshield wiper and washer

Lights
up Possible cause Proper response
Y Not enough windshield washer fluid. Refill windshield washer reservoir at the next
opportunity

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Windshield wiper lever

Fig. 87 Operating the front windshield wiper.

Fig. 88 Operating the rear wiper.

Move the lever to the desired position ⇒:
(B) z
Intermittent wiping for the windshield.
Adjust the interval settings with switch ⇒ fig. 87 (1) (vehicles without rain sensors) or
the sensitivity of the rain sensor (vehicles with rain sensors).
(C) LOW Slow wiper speed.
(D) HIGH Fast wiper speed.
(E) 1x One-tap wiping – brief wiping. Hold the lever pressed down longer to wipe more often.
(F) W Pull the lever toward the steering wheel to activate the windshield washers, then
release.
(G) Z Intermittent wiping for the rear window. The wiper wipes about every 6 seconds.
(H) \ Press the lever forward as far as it will go to activate the rear window washers, then
release.

NOTICE
x To help prevent damage to the wiper blades and the wiper motor when it is cold outside,
always make sure that blades are not frozen to the windshield before operating the wipers.
Using the service position can be helpful in cold weather so the wipers do not freeze to the
windshield
x If the ignition is switched off while the wipers are running, the wipers will continue at the
same wiping speed when the ignition is switched on again. Frost, ice, snow, leaves, and other
objects on the windshield can damage the wipers and the wiper motor.
x Remove snow and ice from the wipers before you begin driving.
x If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen
recommends using a deicing spray.
NOTICE
Never switch on the windshield wipers when the windshield is dry because the windshield can
be scratched.
The windshield wipers work only if the ignition is switched on and the engine hood is closed. The
windshield wipers turn off automatically when the engine hood is opened. The rear windshield wipers
turn off automatically when the rear hatch is opened.
If the front wipers are on, the rear wiper is switched on automatically when backing up.
If the windshield wiper lever is in the rear window intermittent wiping position ⇒ fig. 88 (G) when
the ignition is switched off and back on or the engine is started, rear window wiper action does not
resume until the windshield wipers are activated. This is to keep the wiper from working when the
window is dry. By switching rear window intermittent wiping off and then back on, you can override this
feature and activate the rear window wiper immediately.
The intermittent wiping for the front windshield depends on the driving speed. The higher the
speed, the faster the wipers move.
