2013 VOLKSWAGEN TIGUAN Owners Manual

WARNING
The elastic luggage net has to be stretched when being attached to the tie-downs in the
luggage compartment. The metal hooks can cause serious personal injury if not handled
properly and attached securely.
x Always hold the hooks on the luggage net bag firmly when attaching to the vehicle and do
not let them spring back and hit you.
x Always protect eyes and face from injury from the metal hooks when attaching them to the
tie-downs in the luggage compartment.
x First attach the luggage net bag hooks to the tie-downs on the rear seat backrest or on the
shopping bag hooks in the luggage compartment and then to the tie-downs near the loading
edge of the luggage compartment. If one of the hooks on the luggage bag net snaps back, it
will move away from you and not towards you, increasing the risk of injury.
Variable luggage compartment floor

Fig. In the luggage compartment: Opening and securing the variable luggage compartment floor.

Fig. Extending the luggage compartment floor forward or downward.

x To secure, push the retaining pin to the right.
x To close, push the retaining pin (1) to the left and guide the luggage compartment floor
downwards.
Extending the luggage compartment floor forward
x Remove the luggage compartment cover
x Remove the rear head restraints
x Push both sections of the rear seat forward
x Fold the rear backrests forward
x Fold the cover forward ⇒ fig. (1).
Extending the luggage compartment floor downward
x Remove the luggage compartment cover
x Raise the luggage compartment floor, pull from the side pins (2) and remove it from the vehicle to
the rear.
There may be a foam element with the spare wheel ⇒ fig. located beneath the variable luggage
compartment floor. If a spare wheel is present, remove it and remove the foam element from the
luggage compartment.
WARNING
During hard braking or an accident, loose objects can fly through the passenger
compartment and cause serious or even fatal injuries.
x Even if the luggage compartment floor panel is properly raised, it is still necessary to
secure all objects.
x Objects stowed between the rear seat bench and the luggage compartment floor panel
must never be more than 2/3 as high as the raised floor panel.
x Objects stowed between the rear seat bench and the raised luggage compartment floor
panel must never weigh more than about 16.5 lbs. (7.5 kg).
NOTICE
Do not let the luggage compartment floor fall freely when closing it. Always guide it down into
place. The trim or the luggage compartment floor could be damaged.
If you slide the rear seats forward, there is a gap between the luggage compartment floor and the
rear seats. Make certain there are no objects in this space before sliding the rear seats back again.

Roof rack

Securing a load on the roof rack

Trailer towing

WARNING
Improper use of the trailer hitch can cause accidents and injuries. An improperly installed,
incorrect, or damaged trailer hitch can cause the trailer to separate from the towing vehicle
and cause serious personal injuries.
x Only use an undamaged, properly mounted trailer hitch.
x Never repair or modify the trailer hitch.
x To reduce the risk of injury in rear-end collisions, and the risk to pedestrians and cyclists
when the vehicle is parked, always remove the ball mount when you are not towing a trailer.
x Never install a “weight distributing” or “load equalizing” trailer hitch on your vehicle. The
vehicle was not designed for these kinds of trailer hitches. The trailer hitch attachment can
fail, causing the trailer to tear loose from the vehicle.
WARNING
Improper trailer towing can cause loss of vehicle control and serious personal injury.
x Driving with a trailer and carrying heavy or large things can change the way the vehicle
handles, increase the distance it needs to stop safely, and cause accidents.
x Always secure the load properly with suitable and undamaged straps so that the load will
not shift.
x Always adapt your speed and driving to the heavier load and the weight distribution in the
vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Reduce your speed even more than you otherwise would when going downhill and under
unfavorable load, weather, or wind conditions.
x Trailers with a high center of gravity tip more easily than trailers with a low center of
gravity.
x Always avoid sudden maneuvers and hard braking.
x Be especially careful when passing other vehicles.
x Reduce speed immediately if the trailer shows the slightest sign of swaying.
x Never try to stop the swaying by accelerating.
x Always obey speed limits. In some areas, the speed limits for vehicles towing trailers are
lower than for vehicles without trailers. Never drive faster than 50 mph (80 km/h; under
exceptional circumstances 60 mph - km/h) when towing a trailer. This applies even if the
local speed limit is higher.
If you are driving a new vehicle or a vehicle with a new or rebuilt engine, do not tow a trailer
during the break-in period, about miles ( 0 km)
If you tow a trailer, your vehicle may need maintenance more often because of the extra load it
has to move.
When you are not towing, remove the trailer hitch ball. This helps keep the trailer hitch from
causing damage to your vehicle and to others if your vehicle is hit from behind.
Some models need a trailer hitch to tow or tow-start other vehicles. You may want to always
carry the ball mount in the vehicle after it has been removed. Be sure to stow it securely.

Technical requirements

Electrical load Maximum power
Turn signals per side 54 watts
Side marker lights total4 watts
Taillights lights total 54 watts

WARNING
x An improperly installed or incorrect trailer hitch can cause a trailer to separate from the
tow vehicle and cause serious personal injuries.
x If you don't have to tow a trailer any more, remove the entire trailer hitch. Always seal all
bolt holes to prevent water and deadly exhaust fumes from getting into the vehicle.
NOTICE
x If the trailer lights are not connected properly, the vehicle's electronics may be damaged.
x If the trailer uses too much electricity, the vehicle's electronics may be damaged.
x Never connect the electrical system for the trailer directly to the electrical connections for
the rear lights or to any other unsuitable power sources. Use only a suitable connector to
provide power to the trailer.
If you tow a trailer frequently, Volkswagen recommends having the vehicle serviced between the
regular maintenance and inspection intervals because of the extra load it has to pull.
In some countries an additional fire extinguisher must be carried if the total weight of the trailer
exceeds 5, lbs. (2, kg).
Hitching up and connecting a trailer
