2013 VOLKSWAGEN EOS Owners Manual

Emergency closing and opening

WARNING
Before using the emergency procedure to close the CSC roof, park the vehicle as far away
from moving traffic as possible. If necessary, switch on the emergency flashers and set up a
warning triangle. Obey all applicable legal requirements.
NOTICE
If the vehicle's battery fails or the power windows won't work, the door windows are not
lowered when the door is opened or closed. Always close and open the door carefully to help
prevent damage to the window, the paint, or the rubber seal.
NOTICE
x Before using the emergency procedure to close the CSC roof and while doing it, check the
area behind the vehicle for possible obstacles and make sure there is enough room to avoid
damage. Rear lid assist does not work before and during the emergency closing procedure.
x Never close the CSC roof if the car is on a workshop hoist, parked with one side on a curb,
or raised on a car jack or jackstands.
NOTICE
To help prevent vehicle damage, carefully remove and properly reinstall parts after emergency
locking or unlocking.
Manually unlocking and locking the driver door

Fig. 166 Door handle on driver door: Concealed lock cylinder.

x Insert the key bit from below into the opening of the cover cap on the driver door ⇒ fig. 166 (arrow)
and lift the cover cap off. Grasping the door handle and pulling slightly makes it easier to remove the
cap.
x Insert the key bit into the lock cylinder of the driver door and unlock or lock the door.
x Reinsert the cover cap from top to bottom and press until it clicks into place. Grasping the door
handle and pulling slightly makes it easier to reinstall the cap.
Special considerations when unlocking:
x If the vehicle is equipped with an anti-theft alarm system, the system remains activated for the
unlocked vehicle. But no alarm is triggered at first
x Open the driver door. The alarm will sound.
x Switch on the ignition. The electronic immobilizer recognizes a valid remote control vehicle key
when the ignition is switched on and deactivates the anti-theft alarm system.
The driver door can be unlocked separately from the inside the vehicle by pulling the door handle
to open the door
The anti-theft alarm system is not activated when the vehicle is locked manually with the key bit
43.
Manually locking the passenger door

Fig. 167 On the front side of the passenger door: Emergency lock, covered by a rubber seal.

Fig. 168 On the front side of the passenger door: Manual vehicle locking with the key bit in the vehicle key.

Fig. 170 Inside the luggage compartment: Release lever for luggage compartment lid.

Fig. 172 Right side of luggage compartment: Emergency release of fuel filler flap.

x Within 2 seconds, pull the switch again and hold it until the sunroof closes completely. The sunroof
will close with extra force. Pinch protection will be disabled while the sunroof is closing!
In some cases, the emergency closing procedure for the CSC roof can be used to close the
power sunroof
Emergency closing of the CSC roof

Fig. 174 CSC roof switch in the center console.

Fig. 175 Driver's door control to open and close all windows.

Possible situations for emergency closing
Provided the preliminary requirements have been met, the CSC roof can be closed using the
emergency procedure if you have one or more of the following problems:
x The windows in the doors will not go down.
x The soft-close feature of the luggage compartment lid is not working.
x Sensors that determine the position of the CSC roof when it is opening and closing are not
working.
Emergency CSC roof closing
x Check whether there is enough room behind the vehicle for the luggage compartment lid to swing
out backwards.
x Open the driver and passenger door and leave the doors open.
x Press your thumb on the top part of the Volkswagen emblem on the luggage compartment lid, and
flip lower part of the emblem outward. This unlocks the rear lid. But do not lift the luggage
compartment lid.
x Switch the ignition off and back on again.
x Start the engine.
x Pull and hold the center console lever ⇒ fig. 174 for at least 30 seconds.
x Release the lever.
x Pull and hold the lever again and immediately pull back and hold the driver door switch ⇒ fig. 175
(1) until the CSC roof has completely closed and locked.
It takes a few seconds for the closing process to start after you pull both controls. A tone sounds and
the indicator light X in the instrument cluster display lights up during the emergency closing process.
There may also be a message in the instrument cluster display.
The closing process is immediately interrupted if you let go of the lever or the switch or if one of the
cancel conditions changes ( 324, Cancel conditions for emergency closing). The process can be
restarted by again pulling the center console lever and the switch in the driver door.
x After emergency roof closing is complete, continue to hold the lever and switch to close all
windows.
x OR: After emergency closing, pull switch (1).
x OR: Insert the key in the lock of the driver's door, turn in the closing direction, and hold until all
windows are closed.
x Have the vehicle checked immediately by an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility.
Cancel conditions for emergency closing
Emergency closing the CSC roof is canceled if any of the following situations occurs:
x The lever in the center console or the switch in the driver door is released.
x The ignition is switched off.
x Any door is shut.
x The vehicle battery voltage is less than 9 Volts.
x The luggage compartment lid is closed before the roof frames are locked into the mountings on the
windshield.
x The vehicle moves at a speed greater than about 0.6 mph (1 km/h).
x The outside temperature is below +5° F (- 15° C).
Emergency closing using the lever-switch combination is possible only if the CSC control unit has
detected a malfunction that is caused by one of the listed feasible problems 324, Possible situations
for emergency closing.
