2013 VOLKSWAGEN EOS Owners Manual

Heating and air conditioning

WARNING
Poor visibility increases the risk of collisions and other accidents that cause serious
personal injuries.
x Always make sure all windows are clear of ice, snow and condensation for good visibility
to the front, sides, and rear.
x Maximum heating output and defrosting performance are not possible until the engine has
reached operating temperature. Wait until you have good visibility before driving off.
x Always make sure you know how to properly use the climate control system as well as the
rear window defroster that you will need for good visibility.
x Never use air recirculation for long periods of time. When the air conditioner is off and
recirculation mode is on, condensation can quickly form on the windows and greatly reduce
visibility.
x Always switch off recirculation mode when it is not needed.
WARNING
Stale air causes driver fatigue and reduces driver alertness, which can cause accidents,
collisions and serious personal injury.
x Never switch off the fan for a long period of time and never use air recirculation a long
period of time because no fresh air will enter the passenger compartment.
NOTICE
x If you think the air conditioner is not working properly or may be damaged, switch it off to
help prevent more damage. Have the air conditioner checked by an authorized Volkswagen
dealer or an authorized Volkswagen Service Facility.
x Air conditioner repair requires specialized knowledge and special tools. Volkswagen
recommends that you see an authorized Volkswagen dealer or an authorized Volkswagen
Service Facility.
x Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation
system can leave residue on the evaporator and on the dust and pollen active carbon filter,
resulting in permanent odors whenever the air conditioner is switched on.
If the air conditioner is switched off, the fresh outside air will not be dehumidified. To help keep
the windows from fogging over, Volkswagen recommends leaving the air conditioner (compressor)
switched on. Press the !

Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle
battery has been replaced may change or delete system settings (including time, date, personal
convenience settings, and programming). Check the settings and correct as necessary once the
vehicle battery has built up a sufficient charge.
Controls

Fig. 140 In the center console: Manual AC controls.

Fig. 141 In the center console: Climatronic controls.

Buttons,
knobs
More information: Manual AC ⇒ fig. 140
and Climatronic ⇒ fig. 141.
Fan (2) Manual AC: Setting 0: the fan and manual AC are switched off.
Setting 4: highest fan speed.
e Climatronic: The fan speed is automatically controlled depending on the vehicle
speed in order to help prevent unnecessary noise. The fan can also be adjusted
manually.
Air
distribution
(3)
Manual AC: Direct airflow by turning knob to any setting (continuously adjustable).
Climatronic: Air flow is automatically adjusted to a comfortable level. It can also be
manually adjusted with buttons (3).
Displays (4) Climatronic: Left-side and right-side digital temperature displays.
< Manual AC: Defrost button. Airflow is directed to the windshield. Recirculation mode
switches off automatically in this position. Increases the fan speed to clear the
windshield as quickly as possible. The cooling system switches on automatically to
dehumidify the air.


Climatronic: Defrost button. The incoming outside air is directed to the windshield,
and air recirculation automatically switches off. To defrost the windshield as quickly as
possible, humidity is removed from the air at temperatures above about 35 °F
(+1.5 °C), and the blower is set to a high speed.
K Air distribution to the air vents in the instrument panel.
L Air distribution to the footwells.
u· Manual AC: Air distribution to the windshield and footwells.
Climatronic: Air is directed upward.
Rear window defroster: Works only when the engine is running and switches off
automatically after 10 minutes or less.
3 Manual AC: Air recirculation
Û

Buttons,
knobs
More information: Manual AC ⇒ fig. 140
and Climatronic ⇒ fig. 141.
Switching
off.
Manual AC: Turn fan switch to position 0.
/&& Climatronic: Press OF F button or set the fan manually to 0. If the system is switched
off, an indicator light in the OFF button lights up.

WARNING
Stale air causes driver fatigue and reduces alertness, which can cause accidents, collisions,
and serious personal injury.
x Never switch off the fan for a long time, because no fresh air will enter the passenger
compartment.
Air conditioner operation

Heating
Maximum heating output and defrosting performance are not possible until the engine has reached
operating temperature.
Air conditioner does not work
The air conditioner may not switch on for one of the following reasons:
x The engine is not running.
x The fan is switched off.
x The air conditioner fuse has blown.
x The outside air temperature is colder than about +38 °F (+3 °C).
x The air conditioner compressor has been temporarily switched off due to excessive engine coolant
temperature.
x There is another malfunction in the vehicle. Have the air conditioner checked by an authorized
Volkswagen dealer or authorized Volkswagen Service Facility.
Special considerations
When it is very hot and humid outside, water condensation can drip from the air conditioner
evaporator and form a puddle under the vehicle. This is normal and does not indicate a leak.
The climate control system adjusts the passenger compartment temperature as fast as possible
considering the outside temperature.
Due to residual moisture in the air conditioner, the windshield may fog up after the engine is
started. Switch on the windshield defroster to help evaporate the condensation as quickly as possible.
Air vents

Fig. 142 In the instrument panel: Air vents.

Additional, non-adjustable air vents are located in the front pillars and the instrument panel (2), in the
footwells, as well as in the rear area of the passenger compartment.
NOTICE
Do not place food, medications, or other heat-sensitive things in front of the air vents. Food,
medications, and other things that are sensitive to heat or cold can be damaged or made
unusable by the air flow from the vents.
Air recirculation

x The cooling system and the windshield wiper are switched off and the outside air temperature is
cooler than about +50 °F (+10 °C).
x The cooling system is switched off, the outside air temperature is cooler than about +59 °F
(+15 °C), and the windshield wiper is switched on.
Switching automatic air recirculation on and off
Switching on: Press the
