2013 VOLKSWAGEN EOS Owners Manual

Volkswagen Information System

Menu structure – overview

▪ Lights & Vision
– Coming home
– Leaving home
– Footwell light
– Conv. turn sig. (convenience turn signal)
– Factory setting
▪ Time
– Hours
– Minutes
– 24 hr. mode
– Daylight save
▪ Snow tires (winter tires)
– --- mph (--- km/h)
– On
– + 5 mph (10 km/h)
– - 5 mph (10 km/h)
▪ Units
– Temperature
– Consump./dist.
▪ Alt. speed dis. (alternative speed display On / Off)
▪ Service
– Info
– Reset
▪ Factory setting
Using the instrument cluster menus

Fig. 15 Right side of the multi-function steering wheel: Controls for menus in the instrument cluster.

x Push buttons # or ∃ to move to another main menu, and push the arrow up and down buttons *
and + to navigate inside the current main menu. For example, in the Settings main menu, press the
arrow down button * to navigate to the MFI data submenu.
Displaying a submenu
x Press the /+ button to display submenu items. For instance, after scrolling to MFI data in the
Settings main menu, press the /+ button to display items available under the MFI data submenu.
Selecting a setting
x Some menus are used to select settings for certain features. Push the /+ button () to select a set-
ting.
x Use the arrow up and down buttons * and + on the multi-function steering wheel to navigate
through the available options.
x The selected menu item is located between the 2 horizontal lines. There is also a triangle (Å) on
the right.
x Push the /+ button to select the setting.
Returning to the main menu
x Via menu: Use the arrow down button + to select Back and then press the /+ button .
x For operation with multi-function steering wheel: Press E
Main menu

MFI menu (Multi-Function Indicator)

Display Function
Average speed
-- mph Average speed on trips per trip memories 1 and 2 (toggle). Displayed
once the vehicle has been driven about 300 feet (100 m). Until then,
dashes may appear instead of a number. The value displayed is updated
every 5 seconds. Average speed
-- km/h
-- mph Digital display of current vehicle speed. -- km/h
Speed warning
--- mph When the set speed (from 20–155 mph or 30–250 km/h) is exceeded, an
acoustic warning sounds, and a visual message may also appear in the
instrument cluster display. Speed warning
--- km/h

Switching between the displays
x Use the arrow up and down buttons * and + on the multi-function steering wheel.
Storing speed for the speed warning
x Navigate to MFI > Speed warning (Speed warning -- mph or Speed warning -- km/h.
x Press the /+ button to save the current speed and to activate the warning.
x If the speed is not right, press buttons * or + on the multi-function steering wheel to set a different
speed within about 5 seconds. Then press the /+ button a second time or just wait a few seconds. The
speed is saved and the warning is activated.
x To deactivate, toggle to --- mph or --- km/h and press the /+ button. The set speed is deleted.
Manually erasing trip memory 1 or 2
x Navigate to MFI > Route.
x Select the memory to be erased.
x Press the /+ button for about 2 seconds.
Enabling and disabling displays
Use the Settings menu, submenu MFI data to enable displays you want to be available under the
MFI menu in the instrument cluster display. The units in which data is displayed can also be changed

Settings menu

Settings menu Function
Lights & Vision Vehicle lighting settings
Time
Set hours and minutes for the instrument cluster clock and the Radio &
Navigation System clock. The time can be displayed in 12 or 24 hour
format, and can also be set to daylight savings time.
Snow tires
Set up a visual and acoustic speed warning. Use the feature only when
winter tires are installed that have a speed rating less than top vehicle
speed.
Units
Set the units in which temperature, fuel consumption, and distances
should be displayed (for example, whether to show distance driven in
miles or kilometers).
Alt. speed dis. Activate/deactivate alternative speed display (mph or km/h).
Service Display service messages or reset service reminder display.
Factory setting Reset the functions in the Settings menu back to the factory settings.

Convenience submenu

Convenience
menu Function
Auto unlock
You can enable or disable Auto unlock. If Auto unlock is
enabled (box checked), it is triggered on vehicles without
Keyless Access by taking the key out of the ignition.
On Keyless Access vehicles, Auto unlock is triggered by
opening the driver door. Auto unlock works only if the
vehicle has been automatically locked after reaching a
speed of 10 mph (15 km/h) . It unlocks the doors that
would be unlocked if you pushed the unlock button on the
remote control vehicle key once.
Window op.

Off Manual unlocking/locking: No windows open or close when
the key is held in the unlocking or locking position .
All Manual unlocking/locking: All windows open or close when
the key is held in the unlocking or locking position.
Driver
Manual unlocking: The driver window opens when the key
is held in the unlocking position.
Manual locking: All windows close when the key is held in
the locking position.
Back The display switches back to the Convenience menu.
Mirror down Tilts passenger mirror down when backing up so you can see the curb
Mirror adjust

Individually Both outside mirrors are adjusted separately.
Both mirrors The front passenger outside mirror is adjusted at the same
time as the driver outside mirror.
Back The display switches back to the Convenience menu.
Factory
setting Resets the features in the Convenience submenu back to the factory settings.
Back The display returns to the Settings menu.

Lights & Vision submenu
