2013 VOLKSWAGEN EOS Owners Manual

x If the distance remains the same, the warning tone volume decreases after a few seconds. If a
continuous tone sounds, its volume remains the same.
x If the vehicle moves away from the obstacle, the beeping sound stops automatically. The beep
turns on again automatically if the vehicle approaches the obstacle again.
x For vehicles with automatic transmissions, there is no beeping when the transmission is in Park
(P).
x The volume of the audible signals can be adjusted by an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
x Rear lid assist only works when the vehicle is not moving.
Rear lid assist during opening and closing the CSC roof
Before the CSC roof opens or closes, the rear lid assist system uses the PDC sensors to check that
there is enough room behind the vehicle for the rear lid to swing out past the rear bumper.
x If an obstacle is detected, roof operation stops. Unlike the Park Distance Control system, rear lid
assist has no acoustical alert signal. Remove any obstacles behind the vehicle or move the vehicle
forward so that there is enough room for the luggage compartment lid to swing out.
x If you operate the CSC roof lever again after roof has automatically stopped (because rear lid
assist has detected an obstacle), roof operation will start again after a few seconds. The CSC roof will
not stop again automatically if an obstacle is detected a second time. Instead, a warning will appear in
the instrument cluster display.
x Because the rear lid assist system uses the PDC sensors, its operation depends on whether or not
the PDC system is working properly. PDC is working properly if the warning chime sounds when you
shift into Reverse.
WARNING
Never rely completely on the PDC for information about people and objects that might be in
the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may
not always be able to detect them.
If there is a malfunction in the Park Distance Control, a brief continuous warning tone will sound
and the indicator light in the button will blink when you first switch the system on. Switch off the Park
Distance Control system with the button and have it immediately checked by an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility.
Rear lid assist can be deactivated by an authorized Volkswagen dealership or authorized
Volkswagen Service Facility. If this is done, Park Distance Control still works and will give an acoustic
warning if the CSC roof is opened or closed while the vehicle is in Reverse. The signal sounds as
soon as the luggage compartment lid swings into the area scanned by the PDC sensors.

Rear Assist

WARNING
Rear Assist technology cannot overcome the laws of physics and the limits of the system.
Careless or unintentional use of Rear Assist may result in accidents and severe injuries.
x Always adjust your speed and driving style to road, traffic, weather, and visibility
conditions.
x Always keep an eye on the parking direction and the vehicle surroundings. The front of
the vehicle swings out more than the rear of the vehicle.
x Never pay so much attention to the graphics shown on the screen that you fail to notice
what is going on around you.
x Always watch for people, especially small children, animals, and objects, because the
camera may not always be able to detect them.
x The system may not be able to clearly show everything behind the vehicle.
x Use Rear Assist only when the luggage compartment lid is completely closed.
NOTICE
x The camera shows only two-dimensional images on the screen. Due to the lack of depth of
field, it may be difficult or impossible to identify protruding objects or recesses in the road, for
example.
x Things like thin rods, fences, posts, and trees may not be detected by the camera and could
damage the vehicle.
Operation instructions

Fig. 132 In the luggage compartment lid: Location of the Rear Assist camera.

Fig. 133 Rear Assist display.

1) Do not use Rear Assist in the following situations:
– If the position or angle of the camera has changed, such as after a rear-end collision. Have the
system checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.


2) Examples of optical distortion by the camera
The Rear Assist camera displays only two-dimensional images. Recesses and protruding objects on
the ground or protruding parts on other vehicles are difficult or impossible to identify due to the lack
of depth of field.
Objects or another vehicle may seem closer or farther away on the screen than they really are:
– When driving from a level surface onto an upward or downward slope.
– When driving up or down a slope onto a level surface.
– If the rear of the vehicle is heavily loaded.
– When approaching protruding objects. These objects can disappear from the field of view when
backing up.

Cleaning the camera lens
Keep the camera lens clean and free of snow and ice:
x Engage the parking brake.
x Switch on the ignition.
x Select the reverse gear.
x Wet the camera lens with a commercially available alcohol-based glass cleaner and clean with a
dry cloth ⇒ .
x Remove snow with a brush.
x Remove ice with deicer spray ⇒ .
NOTICE
x Never use abrasive cleaning agents to clean the camera lens.
x Never remove snow or ice on the camera lens with warm or hot water. This can damage the
camera lens.
Volkswagen recommends practicing parking with Rear Assist in a safe place with little or no
traffic or in a parking lot under good visibility and weather conditions in order to familiarize yourself
with the system, the orientation lines and the way they work.
Rear Assist does not work when the luggage compartment lid is open.

Parking

Fig. 134 On the screen: Static orientation lines for the parking space behind the vehicle.

Cruise Control System (CCS)

Applicable only in the United States
Indicator lights

Fig. 135 In the instrument cluster display: Cruise control status indications.
