2013 Lexus GX460 Owner's Manual

192
2-1. Driving procedures
GX460_OM_OM60J63U_(U)
■Selecting second start mode
Use second start mode for accelerating and driving on slippery
road surfaces such as snow.
Press the menu switch.
The multi-information display
will change modes to electronic
features control mode.
Press the “ENTER” switch
upwards or downwards until
“2ND START” appears.
Press the “ENTER” switch to
change to “ON”.
The “2nd STRT” indicator will be
displayed.
Each pressing of the switch
turns second start mode on and
off.
Press the menu switch to
change to the normal display.
STEP1
STEP2
GX460_OM_OM60J63U_(U).book Page 192 Thursday, March 29, 2012 9:10 AM

193
2-1. Driving procedures
2
When driving
GX460_OM_OM60J63U_(U)
Changing shift ranges in S modeWhen the shift lever is in the S position, the shift lever can be operated as
follows: For upshifting
For downshifting
The initial shift range in S mode is set automatically to 5 or 4 according to
vehicle speed. However, the initial shift range may be set to 3 or 2 if AI-
SHIFT has operated while the shift lever was in the D position.
(→ P. 1 9 4 )
■ Shift ranges and their functions
● You can choose from 6 levels of engine braking force.
● A lower shift range will provide greater engine braking force than a
higher shift range, and the engine speed will also increase.
GX460_OM_OM60J63U_(U).book Page 193 Thursday, March 29, 2012 9:10 AM

194
2-1. Driving procedures
GX460_OM_OM60J63U_(U)
■S mode
When the shift range is 5 or lower, holding the shift lever toward “+” sets the shift
range to 6.
■AI-SHIFT
AI-SHIFT automatically selects a suitable gear according to driver performance
and driving conditions.
AI-SHIFT automatically operates when the shift lever is in the D position. (Shifting
the shift lever to the S position cancels the function.)
The engine speed remain high after releasing the accelerator pedal. This does not
indicate a malfunction.
■When driving with the cruise control or dynamic radar cruise control
Engine braking will not occur in S mode, even when downshifting to 5 or 4.
( → P. 2 5 0 , 2 5 4 )
■If the shift lever cannot be shifted from P
→ P. 74 2
■If the “S” indicator does not come on even after shifting the shift lever to S
This may indicate a malfunction in the automatic transmission system. Have the
vehicle inspected by Lexus dealer immediately.
(In this situation, the transmission will operate in the same manner as when the shift
lever is in D.)
■Downshift restriction warning buzzer (S mode)
To help ensure safety and driving performance, downshifting operation may some-
times be restricted. In some circumstances, downshifting may not be possible even
when the shift lever is operated. (A buzzer will sound twice.)
GX460_OM_OM60J63U_(U).book Page 194 Thursday, March 29, 2012 9:10 AM

195
2-1. Driving procedures
2
When driving
GX460_OM_OM60J63U_(U)
CAUTION
■When driving on slippery road surfaces
Do not accelerate or shift gears suddenly. Sudden changes in engine braking may
cause the vehicle to spin or skid, resulting in an accident.
GX460_OM_OM60J63U_(U).book Page 195 Thursday, March 29, 2012 9:10 AM

196
2-1. Driving procedures
GX460_OM_OM60J63U_(U)
Turn signal lever
■Turn signals can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
■If the indicators flash faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned out.
The turn signal lever can be used to show the following intentions of the
driver:Right turn
Left turn
Lane change to the right
(push and hold the lever part-
way)
The right hand signals will flash
until you release the lever.
Lane change to the left (push
and hold the lever partway)
The left hand signals will flash
until you release the lever.
GX460_OM_OM60J63U_(U).book Page 196 Thursday, March 29, 2012 9:10 AM

197
2-1. Driving procedures
2
When driving
GX460_OM_OM60J63U_(U)
Parking brake
■Usage in winter time
See “Winter driving tips” for parking brake usage in winter time. (→P. 3 7 1 )
NOTICE
■Before driving
Fully release the parking brake.
Driving the vehicle with the parking brake set will lead to brake components over-
heating, which may affect braking performance and increase brake wear.
To set the parking brake, fully
depress the parking brake pedal
with your left foot while
depressing the brake pedal with
your right foot.
(Depressing the pedal again
releases the parking brake.)
U.S.A. Canada
GX460_OM_OM60J63U_(U).book Page 197 Thursday, March 29, 2012 9:10 AM

198
2-1. Driving procedures
GX460_OM_OM60J63U_(U)
Horn
To sound the horn, press on or
close to the mark.
GX460_OM_OM60J63U_(U).book Page 198 Thursday, March 29, 2012 9:10 AM

199
2
When driving
GX460_OM_OM60J63U_(U)
2-2. Instrument cluster
Gauges and meters
Tachometer
Displays the engine speed in revolutions per minute.
Engine coolant temperature gauge
Displays the engine coolant temperature.
Multi-information display
→P. 2 0 8
Fuel gauge
Displays the quantity of fuel remaining in the tank.
Speedometer
Displays the vehicle speed.
Rear height control air suspension display (if equipped)
→P. 3 2 0
Shift position and shift range display
→P. 1 9 0
GX460_OM_OM60J63U_(U).book Page 199 Thursday, March 29, 2012 9:10 AM
