2013 Lexus GX460 Owner's Manual

400
3-1. Using the air conditioning system and defogger
GX460_OM_OM60J63U_(U)
Multi-information display (Accessory meters)
Driver’s side temperature displayFront passenger’s side temperature display
Rear passenger’s side temperature display
(vehicles with a rear automatic air conditioning system)
Cooling and dehumidification function on/off display
Fan speed displayAir outlet display
GX460_OM_OM60J63U_(U).book Page 400 Thursday, March 29, 2012 9:10 AM

401
3-1. Using the air conditioning system and defogger
3
Interior features
GX460_OM_OM60J63U_(U)
Using the automatic air conditioning system
Vehicles without a rear autom atic air conditioning system
Press the “AUTO” button.
The air conditioning system begins to operate. Air outlets and fan
speed are automatically adjusted according to the temperature
setting.
Press “ ∧” on the temperature control button on the driver’s side
to increase the temperature and “ ∨” to decrease the tempera-
ture.
When the “DUAL” button is pressed (the indicator on the “DUAL” but-
ton is on) or the passenger’s side temperature control button is pressed,
the temperature for the driver and passenger seats can be adjusted
separately.
Vehicles with a rear automat ic air conditioning system
Press the “AUTO” button.
The air conditioning system begins to operate. Air outlets and fan
speed are automatically adjusted according to the temperature
setting.
Press to switch to automatic air intake mode.
The air conditioning system automatically switches between out-
side air and recirculated air modes.
Press “ ∧” on the temperature control button on the driver’s side
to increase the temperature and “ ∨” to decrease the tempera-
ture.
When the “3ZONE” button is presse d (the indicator on the “3ZONE”
button is on), the front passenger’s side temperature control button is
pressed or “REAR/TEMP” button is pressed, the temperature for the
driver’s, front passenger’s and rear seats ( →P. 413) can be adjusted
separately.
STEP1
STEP2
STEP1
STEP2
STEP3
GX460_OM_OM60J63U_(U).book Page 401 Thursday, March 29, 2012 9:10 AM

402
3-1. Using the air conditioning system and defogger
GX460_OM_OM60J63U_(U)
Adjusting the settings manually■ Basic setting
Vehicles without a rear auto matic air conditioning system
To turn on the air conditioning system and adjust the fan speed,
press “ ∧” on to increase the fan speed and “ ∨” to
decrease the fan speed.
Press to turn the fan off.
To adjust the temperature setting, press “ ∧” on the temperature
control button on the driver’s side to increase the temperature
and “ ∨” to decrease the temperature.
The air conditioning system switch es between individual and simulta-
neous modes each time the “DUAL” button is pressed.
When the “DUAL” button is pressed (the indicator on the “DUAL” but-
ton is on) or the passenger’s side temperature control button is pressed,
the temperature for the driver and passenger seats can be adjusted
separately.
To change the air outlets, press “ <” or “ >” on .
The air outlets used are switched each time either side of the button is
pressed. The air flow shown on the display indicates the following:
STEP1
STEP2
STEP3
GX460_OM_OM60J63U_(U).book Page 402 Thursday, March 29, 2012 9:10 AM

403
3-1. Using the air conditioning system and defogger
3
Interior features
GX460_OM_OM60J63U_(U)Vehicles with a rear automat
ic air conditioning system
To turn on the air conditioning system and adjust the fan speed,
press “ ∧” on to increase the fan speed and “ ∨” to
decrease the fan speed.
Press to turn the fan off.
To adjust the temperature setting, press “ ∧” on the temperature
control button on the driver’s side to increase the temperature
and “ ∨” to decrease the temperature.
The air conditioning system switches between individual and simulta-
neous modes each time the “3ZONE” button is pressed.
When the “3ZONE” button is presse d (the indicator on the “3ZONE”
button is on), the front passenger’s side temperature control button is
pressed or the “REAR/TEMP” button is pressed, the temperature for
the driver’s, front passenger’s and rear seats ( →P. 413) can be adjusted
separately.
To change the air outlets, press “ <” or “ >” on .
The air outlets used are switched each time either side of the button is
pressed. The air flow shown on the display indicates the following:
STEP1
STEP2
STEP3
GX460_OM_OM60J63U_(U).book Page 403 Thursday, March 29, 2012 9:10 AM

404
3-1. Using the air conditioning system and defogger
GX460_OM_OM60J63U_(U)Air flows to the upper body.
*1: Only the in automatic mode (Air may not always flow.)
*2: Vehicles without a rear automatic air conditioning system
Air flows to the upper body and
feet.
*: Vehicles without a rear automatic air conditioning system
GX460_OM_OM60J63U_(U).book Page 404 Thursday, March 29, 2012 9:10 AM

405
3-1. Using the air conditioning system and defogger
3
Interior features
GX460_OM_OM60J63U_(U) Air flows to the feet.
*: Vehicles without a rear automatic air conditioning system
Air flows to the feet and the wind-
shield defogger operates.
The air intake is automatically
switched to (outside air)
mode.
The air conditioning system oper-
ates automatically.
*: Vehicles without a rear automatic air conditioning system
GX460_OM_OM60J63U_(U).book Page 405 Thursday, March 29, 2012 9:10 AM

406
3-1. Using the air conditioning system and defogger
GX460_OM_OM60J63U_(U)■
Switching between outside air and recirculated air modes
Vehicles without a rear auto matic air conditioning system
Press .
The mode switches between (recirculated air mode) and (out-
side air mode) modes each time the button is pressed.
Vehicles with a rear automatic air conditioning system Press .
The mode switches among (recirculated air mode), automatic and (outside air mode) modes each time the button is pressed.
When the system is switched to automatic mode, the air conditioning sys-
tem operates automatically.
Changing the rear seat settings (vehicles with a rear automatic air con-
ditioning system)
■ Adjusting the temperature setting
Press “ ∧” on the “REAR/TEMP” button to increase the temperature
and “ ∨” to decrease the temperature.
The air conditioning system switch es between individual and simulta-
neous modes each time the “3ZONE” button is pressed.
GX460_OM_OM60J63U_(U).book Page 406 Thursday, March 29, 2012 9:10 AM

407
3-1. Using the air conditioning system and defogger
3
Interior features
GX460_OM_OM60J63U_(U)
Defogging the windshield
Defogging
The air intake is automatically
switched to (outside air)
mode. It is not possible to recircu-
lated air mode when the switch is
on.
The air conditioning system oper-
ates automatically.
Micro dust and pollen filter mode buttonOperates micro dust and pollen fil-
ter on/off.
Outside air mode switches to (recirculated air) mode. Pol-
len is removed from the air and the
air flows to the upper part of the
body.
Usually the system will turn off
automatically after approximately
3 minutes.
GX460_OM_OM60J63U_(U).book Page 407 Thursday, March 29, 2012 9:10 AM
