2013 JEEP GRAND CHEROKEE Owner handbook (in English)

•REAR WINDOW FEATURES ......................154•Rear Window Wiper/Washer .................... .154
• Rear Window Defroster ........................154
•ROOF LUGGAGE RACK — IF EQUIPPED ..............155
69

MIRRORS
Inside Day/Night MirrorA single ball joint mirror is provided in the
vehicle. It is a twist on mirror that has a fixed
position at the windshield. The mirror installs on
the windshield button with a counterclockwise
rotation and requires no tools for mounting. The
mirror head can be adjusted up, down, left, and
right for various drivers. The mirror should be
adjusted to center on the view through the rear
window.
Headlight glare from vehicles behind you can
be reduced by moving the small control under
the mirror to the night position (toward the rear
of the vehicle). The mirror should be adjusted
while the small control under the mirror is set in
the day position (toward the windshield).
Automatic Dimming Mirror — If
Equipped
This mirror automatically adjusts for headlight
glare from vehicles behind you. You can turn the
feature on or off by pressing the button at the
base of the mirror. A light in the button will
illuminate to indicate when the dimming feature
is activated. The mirror is twisted on the wind-
shield button counterclockwise and requires no
tools for mounting.NOTE:
This feature is disabled when the vehicle is
moving in reverse.
CAUTION!
To avoid damage to the mirror during clean-
ing, never spray any cleaning solution di-
rectly onto the mirror. Apply the solution onto
a clean cloth and wipe the mirror clean.
Adjusting Rearview Mirror
Automatic Dimming Mirror
70

Outside MirrorsTo receive maximum benefit, adjust the outside
mirrors to center on the adjacent lane of traffic
with a slight overlap of the view obtained on the
inside mirror.
WARNING!
Vehicles and other objects seen in the pas-
senger side convex mirror will look smaller
and farther away than they really are. Rely-
ing too much on your passenger side convex
mirror could cause you to collide with an-
other vehicle or other object. Use your inside
mirror when judging the size or distance of a
vehicle seen in the passenger side convex
mirror. Some vehicles will not have a convex
passenger side mirror.
Outside Mirrors Folding FeatureAll outside mirrors are hinged and may be
moved either forward or rearward to resist dam-
age. The hinges have three detent positions:
•full forward
• full rearward and
• normal.
Outside Automatic Dimming
Mirrors — If Equipped
The driver and passenger outside mirrors will
automatically adjust for glare from vehicles be-
hind you. This feature is controlled by the inside
automatic dimming mirror and can be turned on
or off by pressing the button at the base of the
inside mirror. The mirrors will automatically ad-
just for headlight glare when the inside mirror
adjusts.
Power MirrorsThe power mirror switch is located on the
driver’s side door trim panel.
The power mirror controls consist of mirror select
buttons and a four-way mirror control switch. To adjust a mirror, press the mirror select button
for the mirror that you want to adjust. Using the
mirror control switch, press on any of the four
arrows for the direction that you want the mirror to
move.
Power mirror preselected positions can be con-
trolled by the optional Memory Seat Feature.
Refer to “Driver Memory Seat” in “Understand-
ing The Features Of Your Vehicle” for further
information.
Power Mirror Switch
1 — Mirror Direction Control
2 — Mirror Selection
71

Power Folding Outside Mirrors — If
Equipped
The switch for the power folding mirrors is
located between the power mirror select
switches (L and R).
Press the switch once and the mirrors will fold
in, pressing the switch a second time will return
the mirrors to the normal driving position.
NOTE:
Pressing the power folding mirror switch for
more than 4 seconds, or if the vehicle speed
is greater than 10 mph (16 km/h) will disable
the folding feature.
If the mirrors are in the folded position, and
vehicle speed is equal or greater than 10 mph
(16 km/h), they will automatically unfold.
The mirrors must be fully open or closed for this
feature to operate properly, and must be manu-
ally opened or closed if necessary.
Heated Mirrors — If Equipped
These mirrors are heated to melt frost
or ice. This feature is activated when-
ever you turn on the rear window de-
froster. Refer to “Rear Window Fea-
tures” in “Understanding the Features of Your
Vehicle” for further information.
Illuminated Vanity MirrorsTo access an illuminated vanity mirror, flip down
one of the visors.
Lift the cover to reveal the mirror. The light will
turn on automatically.
Sun Visor Extension — If EquippedThis feature has a pull out extension on the sun
visor for increased coverage.
Uconnect® Phone — IF
EQUIPPED
NOTE:
For Uconnect® Phone with Navigation or
Multimedia radio, refer to the Navigation or
Multimedia radio’s User’s Manual (separate
booklet) Uconnect® Phone section.
Uconnect® Phone is a voice-activated, hands-
free, in-vehicle communications system.
Uconnect® Phone allows you to dial a phone
number with your mobile phone* using simple
voice commands (e.g., “Call”…“Jim”… “Work” or
“Dial”…“151-1234 -5555”). Your mobile phone’s
audio is transmitted through your vehicle’s audio
system; the system will automatically mute your
radio when using the Uconnect® Phone.
Uconnect® Phone allows you to transfer calls
between the Uconnect® Phone and your mobile
phone as you enter or exit your vehicle and
enables you to mute the Uconnect® Phone’s
microphone for private conversation.
Illuminated Vanity Mirror
72

The Uconnect® Phone is driven through your
Bluetooth® “Hands-Free profile” mobile phone.
Uconnect® Phone features Bluetooth® technol-
ogy - the global standard that enables different
electronic devices to connect to each other with-
out wires or a docking station, so Uconnect®
Phone works no matter where you stow your
mobile phone (be it your purse, pocket, or brief-
case), as long as your phone is turned on and has
been paired to the vehicle’s Uconnect® Phone.
The Uconnect® Phone allows up to seven mobile
phones to be linked to the system. Only one
linked (or paired) mobile phone can be used with
the Uconnect® Phone at a time. The Uconnect®
Phone is available in English, Dutch, French,
German, Italian or Spanish languages (as
equipped).
WARNING!
Any voice commanded system should be
used only in safe driving conditions following
all applicable laws. Your attention should be
focused on safely operating the vehicle. Fail-
ure to do so may result in a collision causing
serious injury or death.Uconnect® Phone Button
The radio or steering wheel con-
trols (if equipped) will contain the
two control buttons (Uconnect®
Phone
button and Voice Com-
mandbutton) that will enable
you to access the system. When you press the
button you will hear the word Uconnect® fol-
lowed by a BEEP. The beep is your signal to
give a command.
Voice Command Button
Actual button location may vary
with radio. The individual buttons
are described in the “Operation”
section.
The Uconnect® Phone can be used with
Hands-Free Profile certified Bluetooth® mobile
phones. Some phones may not support all the
Uconnect® Phone features. Refer to your mo-
bile service provider or the phone manufacturer
for details. The Uconnect® Phone is fully integrated with
the vehicle’s audio system. The volume of the
Uconnect® Phone can be adjusted either from
the radio volume control knob or from the
steering wheel radio control, if so equipped.
The radio display will be used for visual prompts
from the Uconnect® Phone such as CELL or
caller ID on certain radios.
Compatible Phones* The Uconnect® Phone requires a mobile
phone equipped with the Bluetooth® “Hands-
Free Profile”, version 1.0 or higher.
See
Uconnect® website for supported phones.
• www.UconnectPhone.com
To find the list of compatible phones navigate
through the following menus:
• Select model year for the vehicle
• Select type of the vehicle
• In the getting started tab, select compatible
phones
73

OperationVoice commands can be used to operate the
Uconnect® Phone and to navigate through the
Uconnect® Phone menu structure. Voice com-
mands are required after most Uconnect®
Phone prompts. You will be prompted for a
specific command and then guided through the
available options.
•Prior to giving a voice command, one must
wait for the beep, which follows the “Ready”
prompt or another prompt.
• For certain operations, compound com-
mands can be used. For example, instead of
saying “Setup” and then “Pair a Device”, the
following compound command can be said:
“Pair a Bluetooth® Device”.
•
For each feature explanation in this section,
only the compound form of the voice command
is given. You can also break the commands
into parts and say each part of the command
when you are asked for it. For example, you
can use the compound form voice command
“Phonebook New Entry”, or you can break the
compound form command into two voice com-
mands: “Phonebook” and “New Entry”. Please remember, the Uconnect® Phone works best
when you talk in a normal conversational tone,
as if speaking to someone sitting a few feet/
meters away from you.
Voice Command Tree
Refer to “Voice Tree” in this section.
Help Command
If you need assistance at any prompt, or if you
want to know your options at any prompt, say
“Help” following the beep. The Uconnect®
Phone will play all the options at any prompt if
you ask for help.
To activate the Uconnect® Phone from idle,
simply press the
button and follow the au-
dible prompts for directions. All Uconnect®
Phone sessions begin with a press of the
button on the radio control head.
Cancel Command
At any prompt, after the beep, you can say
“Cancel” and you will be returned to the main
menu. However, in a few instances the system
will take you back to the previous menu. Pair (Link) Uconnect® Phone To A Mobile
Phone
To begin using your Uconnect® Phone, you
must pair your compatible Bluetooth® enabled
mobile phone (refer to “Compatible Phones”
section to learn about the phone type).
To complete the pairing process, you will need to
reference your mobile phone owner’s manual.
The Uconnect® website may also provide de-
tailed instructions for pairing.
The following are general phone to Uconnect®
Phone pairing instructions:
•
Press the
button to begin.
• After the “Ready” prompt and the following
beep, say “Setup Phone Pairing”.
• When prompted, after the beep, say “Pair a
Phone” and follow the audible prompts.
• You will be asked to say a four-digit Personal
Identification Number (PIN), which you will
later need to enter into your mobile phone.
You can enter any four-digit PIN. You will not
need to remember this PIN after the initial
pairing process.
74

•For identification purposes, you will be
prompted to give the Uconnect® Phone a
name for your mobile phone. Each mobile
phone that is paired should be given a unique
phone name.
• You will then be asked to give your mobile
phone a priority level between 1 and 7, with 1
being the highest priority. You can pair up to
seven mobile phones to your Uconnect®
Phone. However, at any given time, only one
mobile phone can be in use, connected to
your Uconnect® System. The priority allows
the Uconnect® Phone to know which mobile
phone to use if multiple mobile phones are in
the vehicle at the same time. For example, if
priority 3 and priority 5 phones are present in
the vehicle, the Uconnect® Phone will use
the priority 3 mobile phone when you make a
call. You can select to use a lower priority
mobile phone at any time (refer to “Advanced
Phone Connectivity”).
Dial By Saying A Number
• Press the
button to begin.
• After the “Ready” prompt and the following
beep, say “Dial.” •
The system will prompt you to say the num-
ber you want to call.
• For example, you can say “151-1234-5555.”
• The Uconnect® Phone will confirm the phone
number and then dial. The number will ap-
pear in the display of certain radios.
Call By Saying A Name
• Press the
button to begin.
• After the “Ready” prompt and the following
beep, say “Call.”
• The system will prompt you to say the name
of the person you want to call.
•
After the “Ready” prompt and the following
beep, say the name of the person you want to
call. For example, you can say “John Doe”,
where John Doe is a previously stored name
entry in the Uconnect® Phonebook or down-
loaded phonebook. To learn how to store a
name in the phonebook , refer to “Add Names
to Your Uconnect® Phonebook”.
• The Uconnect® Phone will confirm the name
and then dial the corresponding phone num-
ber, which may appear in the display of
certain radios. Phonebook Download — Automatic
Phonebook Transfer From Mobile Phone
If equipped and specifically supported by your
phone, Uconnect® Phone automatically down-
loads names (text names) and number entries
from your mobile phone’s phonebook. Specific
Bluetooth® Phones with Phone Book Access
Profile may support this feature. See Uconnect®
website for supported phones.
•To call a name from downloaded (or
Uconnect®) Phonebook, follow the procedure
in “Call by Saying a Name” section.
•Automatic download and update, if supported,
begins as soon as the phone Bluetooth® wire-
less connection is made to the Uconnect®
Phone. For example, after you start the
vehicle.
•
Maximum of 1000 entries per phone will be
downloaded and updated every time a phone
is connected to the Uconnect® Phone.
• Depending on the maximum number of en-
tries downloaded, there may be a short delay
before the latest downloaded names can be
used. Until then, if available, the previously
downloaded phonebook is available for use.
75

•Only the phonebook of the currently con-
nected mobile phone is accessible.
• Only the mobile phone’s phonebook is down-
loaded. SIM card phonebook is not part of
the mobile phonebook unless the phone’s
phonebook has less than 20 entries.
• This downloaded phonebook cannot be ed-
ited or deleted on the Uconnect® Phone.
These can only be edited on the mobile
phone. The changes are transferred and
updated to Uconnect® Phone on the next
phone connection.
Add Names To Your Uconnect®
Phonebook
NOTE:
Adding names to the Uconnect® Phonebook
is recommended when the vehicle is not in
motion.
• Press the
button to begin.
• After the “Ready” prompt and the following
beep, say “Phonebook New Entry”. •
When prompted, say the name of the new
entry. Use of long names helps the Voice
Command and it is recommended. For ex-
ample, say “Robert Smith” or “Robert” in-
stead of “Bob”.
•
When prompted, enter the number designation
(e.g., “Home”, “Work”, “Mobile”, or “Other”).
This will allow you to store multiple numbers for
each phonebook entry, if desired.
• When prompted, recite the phone number for
the phonebook entry that you are adding.
After you are finished adding an entry into the
phonebook, you will be given the opportunity to
add more phone numbers to the current entry or
to return to the main menu.
The Uconnect® Phone will allow you to enter up
to 32 names in the phonebook with each name
having up to four associated phone numbers and
designations. Each language has a separate 32-
name phonebook accessible only in that lan-
guage. In addition, if equipped and supported by
your phone, Uconnect® Phone automatically
downloads your mobile phone’s phonebook.
Edit Uconnect® Phonebook Entries
NOTE:
• Editing names in the phonebook is rec-
ommended when the vehicle is not in
motion.
• Automatic downloaded phonebook en-
tries cannot be deleted or edited.
• Press the
button to begin.
• After the “Ready” prompt and the follow-
ing beep, say “Phonebook Edit Entry”.
• You will then be asked for the name of the
phonebook entry that you wish to edit.
• Next, choose the number designation
(home, work, mobile, or other) that you
wish to edit.
• When prompted, recite the new phone
number for the phonebook entry that you
are editing.
After you are finished editing an entry in the
phonebook, you will be given the opportunity to
edit another entry in the phonebook, call the
number you just edited, or return to the main
menu.
76
