2013 JEEP GRAND CHEROKEE Owner handbook (in English)

Do not attempt sharp turns, abrupt maneuvers,
or other unsafe driving actions that can cause
loss of vehicle control. Failure to operate this
vehicle safely may result in a collision, rollover
of the vehicle, and severe or fatal injury. Drive
carefully.
Failure to use the driver and passenger seat
belts provided is a major cause of severe or
fatal injury. In a rollover crash, an unbelted
person is significantly more likely to die than a
person wearing a seat belt. Always buckle up.IMPORTANT NOTICE
ALL MATERIAL CONTAINED IN THIS PUBLI-
CATION IS BASED ON THE LATEST INFOR-
MATION AVAILABLE AT TIME OF PUBLICA-
TION APPROVAL. THE RIGHT IS RESERVED
TO PUBLISH REVISIONS AT ANY TIME.
This Owner’s Manual has been prepared with
the assistance of service and engineering spe-
cialists to acquaint you with the operation and
maintenance of your new vehicle. It is supple-
mented by a Warranty Information Booklet and
various customer-oriented documents. You are
urged to read these publications carefully. Fol-
lowing the instructions and recommendations in
this Owner’s Manual will help assure safe and
enjoyable operation of your vehicle.
After you have read the Owner’s Manual, it should
be stored in the vehicle for convenient reference
and remain with the vehicle when sold.
The manufacturer reserves the right to make
changes in design and specifications, and/or to
make additions to or improvements in its prod-
ucts without imposing any obligations upon
itself to install them on products previously
manufactured.The Owner’s Manual illustrates and describes
the features that are standard or available as
extra cost options. Therefore, some of the
equipment and accessories in this publication
may not appear on your vehicle.
NOTE:
Be sure to read the Owner’s Manual first
before driving your vehicle and before at-
taching or installing parts/accessories or
making other modifications to the vehicle.
In view of the many replacement parts and
accessories from various manufacturers avail-
able on the market, the manufacturer cannot be
certain that the driving safety of your vehicle will
not be impaired by the attachment or installation
of such parts. Even if such parts are officially-
approved (for example, by a general operating
permit for the part or by constructing the part in
an officially approved design), or if an individual
operating permit was issued for the vehicle after
the attachment or installation of such parts, it
cannot be implicitly assumed that the driving
safety of your vehicle is unimpaired. Therefore,
neither experts nor official agencies are liable.
Rollover Warning Label
5

The manufacturer only assumes responsibility
when parts, which are expressly authorized or
recommended by the manufacturer, are at-
tached or installed at an authorized dealer. The
same applies when modifications to the original
condition are subsequently made on the manu-
facturer’s vehicles.
Your warranties do not cover any part that the
manufacturer did not supply. Nor do they cover
the cost of any repairs or adjustments that might
be caused or needed because of the installation
or use of non-manufacturer parts, components,
equipment, materials, or additives. Nor do your
warranties cover the costs of repairing damageor conditions caused by any changes to your
vehicle that do not comply with the manufactur-
ers specifications.
Original Mopar® parts and accessories and
other products approved by the manufacturer,
including qualified advice, are available at your
authorized dealer.
When it comes to service, remember that your
authorized dealer knows your vehicle best, has
the factory-trained technicians and genuine
Mopar® parts, and is interested in your satis-
faction.
Copyright © 2012 Chrysler International.HOW TO USE THIS MANUAL
Consult the Table of Contents to determine which
section contains the information you desire.
Since the specification of your vehicle depends
on the items of equipment ordered, certain
descriptions and illustrations may differ from
your vehicle’s equipment.
The detailed index at the back of this Owner’s
Manual contains a complete listing of all sub-
jects.
Consult the following table for a description of
the symbols that may be used on your vehicle or
throughout this Owner’s Manual:
6

7

WARNINGS AND CAUTIONS
This Owners Manual containsWARNINGS
against operating procedures that could result
in a collision or bodily injury. It also contains
CAUTIONS against procedures that could re-
sult in damage to your vehicle. If you do not
read this entire Owners Manual, you may miss
important information. Observe all Warnings
and Cautions.
VEHICLE IDENTIFICATION
NUMBER
The Vehicle Identification Number (VIN) is
found on a plate located on the left front corner
of the instrument panel pad, visible from outside
of the vehicle through the windshield. This num-
ber also is stamped into the right front body,
behind the right front seat. Move the right front
seat forward to allow better viewing of the
stamped VIN. NOTE:
It is illegal to remove or alter the VIN.
VEHICLE MODIFICATIONS/
ALTERATIONS
WARNING!
Any modifications or alterations to this ve-
hicle could seriously affect its roadworthi-
ness and safety and may lead to a collision
resulting in serious injury or death.
VIN Location
Right Front Body VIN Location
8

2
THINGS TO KNOW BEFORE STARTING
YOUR VEHICLE
•A WORD ABOUT YOUR KEYS ......................12•Wireless Ignition Node (WIN) ......................12
• KeyFob..................................12
• Removing Key Fob From Ignition ...................13
• Key-In-Ignition Reminder ........................14
•STEERING WHEEL LOCK — IF EQUIPPED ..............14•To Manually Lock The Steering Wheel ................14
• To Release The Steering Wheel Lock .................15
•SENTRY KEY® ...............................15•Replacement Keys ...........................15
• Customer Key Programming ......................16
• General Information ...........................16
•PREMIUM VEHICLE SECURITY ALARM — IF EQUIPPED .....16•To Arm The System ...........................17
• To Disarm The System .........................17
• Security System Manual Override ...................18
•ILLUMINATED ENTRY ...........................18
9

•REMOTE KEYLESS ENTRY (RKE) .....................19•To Unlock The Doors .............................19
• To Lock The Doors ..............................20
• Programming Additional Transmitters ...................20
• Transmitter Battery Replacement .....................20
• General Information .............................21
•DOOR LOCKS ..................................21•Power Door Locks ..............................22
• Child-Protection Door Lock System — Rear Doors ...........23
•KEYLESS ENTER-N-GO™ ..........................23
• WINDOWS ....................................26
•Power Windows ...............................26
• Wind Buffeting ................................28
•LIFTGATE ....................................28•Liftgate Flipper Glass ............................28
• Power Liftgate — If Equipped .......................29
•OCCUPANT RESTRAINTS ..........................31•Lap/Shoulder Belts .............................33
• Lap/Shoulder Belt Operating Instructions ................34
• Lap/Shoulder Belt Untwisting Procedure ................35
• Adjustable Upper Shoulder Belt Anchorage ...............36
• Seat Belts In Passenger Seating Positions ................36
• Automatic Locking Retractor Mode (ALR) — If Equipped .......37
• Energy Management Feature ........................37
• Seat Belt Pretensioners ...........................37
• Supplemental Active Head Restraints (AHR) ...............38
• Enhanced Seat Belt Use Reminder System (BeltAlert®) ........40
10

•Seat Belt Lock Out ............................40
• Seat Belts And Pregnant Women ...................41
• Supplemental Restraint System (SRS) — Air Bags ........41
• Advanced Front Air Bag Features ...................42
• Air Bag Deployment Sensors And Controls .............44
• Event Data Recorder (EDR) ......................49
• Child Restraints .............................50
•ENGINE BREAK-IN RECOMMENDATIONS ..............59•Additional Requirements For Diesel Engine — If Equipped ....59•SAFETY TIPS ................................59•Transporting Passengers ........................59
• Exhaust Gas ...............................60
• Safety Checks You Should Make Inside The Vehicle ........60
• Periodic Safety Checks You Should Make Outside
The Vehicle ................................61
11

A WORD ABOUT YOUR KEYS
Your vehicle uses a keyless ignition system.
This system consists of a Key Fob with Remote
Keyless Entry (RKE) transmitter and a Wireless
Ignition Node (WIN) with integral ignition switch.
You can insert the Key Fob into the ignition
switch with either side up.
Keyless Enter-N-Go™ Feature
If this vehicle is equipped with the Keyless
Enter-N-Go™ feature, refer to “Starting Proce-
dures” in “Starting And Operating” for further
information.
Wireless Ignition Node (WIN)The Wireless Ignition Node (WIN) operates
similar to an ignition switch. It has four operating
positions, three of which are detented and one
spring-loaded. The detented positions are OFF,
ACC, and ON/RUN. The START position is a
spring-loaded momentary contact position.
When released from the START position, the
switch automatically returns to the detented
ON/RUN position.NOTE:
With the Keyless Enter-N-Go™ feature, the
Electronic Vehicle Information Center (EVIC)
will display the ignition switch position
(OFF/ACC/RUN). Refer to “Electronic Ve-
hicle Information Center (EVIC)” in “Under-
standing Your Instrument Panel” for further
information.
Key FobThe Key Fob operates the ignition switch. Insert
the square end of the key fob into the ignition
switch located on the instrument panel and
rotate to the desired position. It also contains
the Remote Keyless Entry (RKE) transmitter
and an emergency key, which stores in the rear
of the Key Fob.
The emergency key allows for entry into the
vehicle on the driver’s side should the battery in
the vehicle or the RKE transmitter go dead. The
emergency key is also for locking the glove box.
You can keep the emergency key with you when
valet parking.
NOTE:
Entering a vehicle using the emergency key
with the security alarm armed, will result in
the alarm sounding. Insert the Key Fob
(even if the Key Fob battery is dead) into the
ignition switch to disarm security alarm.
To remove the emergency key, slide the me-
chanical latch at the top of the Key Fob side-
ways with your thumb and then pull the key out
with your other hand.
Wireless Ignition Node (WIN)
1 — OFF
2 — ACC (ACCESSORY)
3 — ON/RUN
4—START
12
