11 9Access

If you are filling your tank to the top, do not
persist after the third cut- off; this could
cause your vehicle to malfunction.

The petrol or Diesel engine of your vehicle is
fitted with a catalytic converter, a device which
helps to reduce the level of harmful emissions
in the exhaust gases.

For petrol engines, the use of unleaded fuel
is compulsory.

The filler neck is narrower, admitting unleaded
petrol nozzles only.



Fuel supply cut- of f



If you have put in the wrong fuel for
your vehicle, you must have
the tank
drained and refilled with the correct
fuel before you star t the engine.





Introduce the nozzle so as to push in the
metal non-return flap B.


Make sure that the nozzle is pushed in as
far as possible before starting to refuel
(risk of blowback).


Maintain this position while refuelling.


Push the fuel flap to close it. Your vehicle is equipped with a safety device
which cuts off the fuel supply in the event of a
collision.

Quality of the fuel used for
petrol engines

The petrol engines are per fectly compatible
with E10 or E24 type petrol biofuels (containing
10 % or 24 % ethanol), conforming to European
standards EN 228 and EN 15376.
E85 type fuels (containing up to 85 % ethanol)
are reserved exclusively for vehicles marketed
for the use of this type of fuel (BioFlex
vehicles). The quality of the ethanol must
comply with European standard EN 15293.
For Brazil only, special vehicles are marketed
to run on fuels containing up to 100 % ethanol
(E100 type).














Quality of the fuel used for
Diesel engines

The Diesel engines are per fectly compatible
with biofuels which conform to current and
future European standards (Diesel fuel
which complies with standard EN 590 mixed
with a biofuel which complies with standard
EN 14214) available at the pumps (containing
up to 7 % Fatty Acid Methyl Ester).
The B30 biofuel can be used in certain Diesel
engines; however, this use is subject to strict
application of the special ser vicing conditions.
Contact a CITROËN dealer or a qualified
workshop.
The use of any other type of (bio)fuel
(vegetable or animal oils, pure or diluted,
domestic fuel...) is strictly prohibited (risk of
damage to the engine and fuel system).

121Access


Travelling abroad

As Diesel fuel pump nozzles may be
different in other countries, the presence
of the misfuel prevention device may
make refuelling impossible.
Before travelling abroad, we
recommend that you check with the
CITROËN dealer network, whether your
vehicle is suitable for the fuel pumps in
the country in which you want to travel.



















Misfuel prevention (Diesel) *
Mechanical device which prevents filling the tank of a Diesel vehicle with petrol. It avoids the risk of
engine damage that can result from filling with the wrong fuel.
Located in the filler neck, the misfuel prevention device appears when the filler cap is removed.
When a petrol filler nozzle is introduced into the
fuel filler neck of your Diesel vehicle, it comes
into contact with the flap. The system remains
closed and prevents filling.

Do not persist but introduce a Diesel type
filler nozzle.




Operation

It remains possible to use a fuel can to
fill the tank.
In order to ensure a good flow of fuel,
do not place the nozzle of the fuel can
in direct contact with the flap of the
misfuel prevention device and pour
slowly.

*
According to country of sale.

005
Visibility

Lighting controls
System for selection and control of the various front and rear lamps providing the vehicle's lighting.
The various front and rear lamps of the vehicle
are designed to adapt the driver's visibility
progressively according to the climatic
conditions:


- sidelamps, to be seen,

- dipped beam headlamps to see without
dazzling other drivers,

- main beam headlamps to see clearly when
the road is clear.



Main lighting

Other lamps are provided to meet the
requirements of particular driving conditions:


- rear foglamps,

- front foglamps with cornering lighting,

- directional headlamps for improved
visibility when cornering,

- daytime running lamps to be more visible
during the day,

- guide-me-home and welcome lighting to
facilitate access to the vehicle,

- parking lamps as vehicle position markers.



Additional lighting

The setting of some functions can be adjusted:


- daytime running lamps,

- automatic illumination of headlamps,

- guide-me-home lighting,

- welcome lighting,

- directional lighting.



Programming

In some weather conditions (e.g. low
temperature or humidity), the presence
of misting on the internal sur face of the
glass of the headlamps and rear lamps
is normal; it disappears after the lamps
have been on for a few minutes.

125Visibility


Model without AUTO lighting



Model with AUTO lighting



Manual controls

The lighting is controlled directly by the driver
by means of the ring A
and the stalk B
.





Sidelamps (lighting signature).
Automatic illumination of headlamps.

B.
Stalk for switching headlamps: pull the stalk
towards you to switch the lighting between
dipped and main beam headlamps.
In the lamps off and sidelamps modes, the
driver can switch on the main beam headlamps
temporarily ("headlamp flash") by maintaining a
pull on the stalk.
A.
Main lighting mode selection ring: turn it
to position the symbol required facing the
mark.
Lighting off / daytime running lamps.
Sidelamps.

Dipped headlamps or main beam headlamps.


Displays

Illumination of the corresponding indicator
lamp in the instrument panel confirms that the
lighting selected is on. Daytime lighting, compulsory in certain
countries, which comes on automatically when
the engine is started making the vehicle more
visible to other users.

This function is assured:


- in countries where it is imposed by
regulations,
by illumination of the dipped beam
headlamps associated with illumination of
the sidelamps and number plate lamps; this
function cannot be deactivated.

- for other countries where it is provided,
by illumination of dedicated lamps; this
function can be activated or deactivated via
the vehicle configuration menu.







Daytime running lamps

The lighting control must be in position "0"
or
"AUTO "
(day mode).

C.
Foglamp selection ring.
The foglamps operate with the dipped and main
beam headlamps.
Rotate and release the ring C
:



for wards a first time to switch on the front
foglamps ,


for wards a second time to switch on the
rear foglamps,


rear wards a first time to switch off the rear
foglamps,


rear wards a second time to switch off the
front foglamps.



Model with front and rear
foglamps
In good or rainy weather, by both day
and night, the front foglamps and the
rear foglamps are prohibited. In these
situations, the power of their beams
may dazzle other drivers. They should
only be used in fog or falling snow.
In these weather conditions, you should
switch on the foglamps and dipped
beam headlamps manually, as the
sunshine sensor may detect sufficient
light.
Do not forget to switch off the front and
rear foglamps when they are no longer
necessary. front and rear foglamps
When the headlamps switch off with automatic
illumination of headlamps (AUTO model)
or when the dipped beam headlamps are
switched off manually, the foglamps and
sidelamps remain on.



Turn the ring rear wards to switch off the
foglamps, the sidelamps will then switch off.
