2013.5 Citroen DS4 RHD Owner's Manual

95Comfort







Automatic tilting in reverse gear

System which provides a view of the ground
during parking manoeuvres in reverse gear.


Programming




With the engine running, engage reverse
gear.


Select and adjust the left-hand and right-
hand mirrors in succession.
The adjustment is stored immediately.


Switching on




With the engine running, engage reverse
gear.


Move control A
to the right or to the left to
select the corresponding mirror.
The glass of the mirror selected tilts
downwards, in accordance with its
programming.


Switching off




Exit reverse gear and wait ten seconds.
or



Return control A
to the central position.
The mirror glass returns to its initial position.
The mirror glass also returns to its initial
position:


- if the speed exceeds 6 mph (10 km/h),

- if the engine is switched off.

Rear view mirror

Adjustable mirror providing a central rear ward view.
Equipped with an anti-dazzle system, which darkens the mirror glass and reduces the nuisance to
the driver caused by the sun, headlamps from other vehicles...


Manual day/night model

Adjustment




Adjust the mirror so that the glass is
directed correctly in the "day" position.



Day/night position




Pull the lever to change to the "night"
anti-dazzle position.


Push the lever to change to the normal
"day" position.

By means of a sensor, which measures the
light from the rear of the vehicle, this system
automatically and progressively changes
between the day and night uses.







Automatic day/night model


In order to ensure optimum visibility
during your manoeuvres, the mirror
lightens automatically when reverse
gear is engaged.

As a safety measure, the mirrors should be adjusted to reduce the "blind spot".

97Comfort

004
Access

Remote control key
System which permits central unlocking or locking of the vehicle using the door lock or from a distance. It is also used to locate and start the vehicle,
as well as providing protection against theft.









Unlocking the vehicle


Unfolding the key




Press this button to unfold the key.



Complete unlocking using the
remote control

Selective unlocking using the
remote control



Press the open padlock to unlock
the vehicle completely.




Press the open padlock once to
unlock the driver's door only.


Press the open padlock again to unlock the
other doors and the boot.



Opening the windows using the
remote control



Maintain the press on the open
padlock until the desired position
is obtained. The windows stop as
soon as you release the button.



Programming the unlocking

The complete or selective door
unlocking parameter is set via the
vehicle configuration menu.

101Access

Unlocking using the key




Turn the key for wards in the driver's door
lock to unlock the vehicle completely.



Selective unlocking of the boot




Press the central button on the
remote control to unlock the
boot. The doors remain locked.
If selective unlocking of the boot is deactivated,
pressing this button also unlocks the doors.

Programming the unlocking

The complete or selective boot
unlocking parameter is set via the
vehicle configuration menu.
Selective unlocking of the boot is
activated by default.

Don't forget to lock the boot again by
pressing the closed padlock button.
The direction indicators flash for a few
seconds.
The spotlamps in the door mirrors
come on.
Depending on version, the door mirrors
unfold, the welcome lighting comes on,
the alarm is deactivated.

Locking the vehicle


Normal locking using the remote
control

Normal locking using the key




Turn the key towards the rear in the driver's
door lock to lock the vehicle.



Press the closed padlock to lock
the vehicle.

If one of the doors or the boot is still
open, the central locking does not take
place.
However, the alarm (if present) will be
completely activated after about
45 seconds.
If the vehicle is unlocked inadvertently
and with no action on the doors or
boot, the vehicle will lock itself again
automatically after about 30 seconds.
If the alarm had previously been
activated, it will not be reactivated
automatically.
The folding and unfolding of the door
mirrors using the remote control can be
deactivated by a CITROËN dealer or a
qualified workshop.


The direction indicators flash for a few
seconds.
Depending on version, the door mirrors fold,
the alarm is activated.
