2012 TOYOTA DYNA 100/150 Owners Manual (in English)

CORROSION PREVENTION AND APPEARANCE CARE179
Use mud shields on your wheels.If you
drive on salted or gravel roads, mud
shields help protect your vehicle. Full−size
shields, which come as near to the ground
as possible, are the best. We recommend
that the fittings and the area where the
shields are installed be treated to resist
corrosion. Your authorized Toyota dealer
or repairer, or another duly qualified and
equipped professional, will be happy to
assist in supplyingand installing the
shields if they are recommended for your
area.
Keep your vehicle in a well ventilated
garage or a roofed place. Do not park
your vehicle in a damp, poorly venti-
lated garage.If you wash your vehicle in
the garage, or if you drive it covered with
water or snow, your garage may be so
damp as to cause corrosion. Even if your
garage is heated, a wet vehicle can cor-
rode if the ventilation is poor.Washing your Toyota
Keep your vehicle clean by regular
washing.
The following cases may cause weakness
to the paint or corrosion to the body and
parts. Wash your vehicle as soon as pos-
sible.
DWhen driving in a coastal area
DWhen driving on a road sprinkled with
antifreeze
DWhen exposed to coal tar, tree sap,
bird droppings and carcass of an insect
DWhen driving in areas where there is
a lot of smoke, soot, dust, iron dust or
chemical substances
DWhen the vehicle becomes remarkably
dirty with dust and mud
Hand−washing your Toyota
Work in the shade and wait until the
vehicle body is not hot to the touch.
CAUTION
DWhen cleaning under floor or chas-
sis, be careful not to injure your
hands.
DExhaust gases cause the exhaust
pipe to become quite hot. When
washing the vehicle, be careful not
to touch the pipe until it has cooled
sufficiently, as touching a hot ex-
haust pipe can cause burns.
1. Rinse off loose dirt with a hose. Re-
move any mud or road salt from the
underside of the vehicle or in the
wheel wells.
2. Wash with a mild car−wash soap,
mixed according to the manufacturer ’s
instructions. Use a soft cotton mitt and
keep it wet by dipping it frequently into
the wash water. Do not rub hard—let
the soap and water remove the dirt.
Dyna100/150_EE
Washing and waxing your
To y o t a

180CORROSION PREVENTION AND APPEARANCE CARE
Exterior lights: Wash carefully. Do not use
organic substances or scrub them with a
hard brush. This may damage the sur-
faces of the lights.
Road tar: Remove with turpentine or
cleaners that are marked safe for painted
surfaces.
3. Rinse thoroughly—dried soap can
cause streaking. In hot weather you
may need to rinse each section right
after you wash it.
4. To prevent water spots, dry the vehicle
using a clean soft cotton towel. Do not
rub or press hard—you might scratch
the paint.
NOTICE
zDo not use organic substances
(gasoline, kerosene, benzine or
strong solvents), which may be tox-
ic or cause damage.
zDo not scrub any part of the ve-
hicle with a hard brush, which may
cause damage.
Waxing your Toyota
Polishing and waxing is recommended
to maintain the original beauty of your
Toyota’s finish.
Apply wax once a month or if the vehicle
surface does not repel water well.
1. Always wash and dry the vehicle be-
fore you begin waxing, even if you are
using a combined cleaner and wax.
2. Use a good quality polish and wax. If
the finish has become extremely weath-
ered, use a car−cleaning polish, fol-
lowed by a separate wax. Carefully fol-
low the manufacturer ’s instructions and
precautions. Be sure to polish and wax
the chrome trim as well as the paint.Exterior lights: Do not apply wax on the
surfaces of the lights. Wax may cause
damage to the lenses. If you accidentally
put wax on the light surfaces, wipe or
wash it off.
3. Wax the vehicle again when water
does not bead but remains on the sur-
face in large patches.
Touch−up paint
Touch−up paint may be used to cover
small chips or scratches.
Apply the paint soon after the damage
occurs or corrosion may set in. To do a
good job, use a small artist’s brush and
stir the paint well. Make sure the area is
clean and dry. To apply the touch−up paint
so it is hardly noticeable, the trick is to
apply it only to the bare spots. Apply only
the smallest amount possible and do not
paint the surface around the scratch or
chip.
Dyna100/150_EE

CORROSION PREVENTION AND APPEARANCE CARE181
CAUTION
DDo not splash or spill liquid in the
vehicle. Doing so may cause electri-
cal components etc. to malfunction
or catch fire.
DWhen cleaning the interior (espe-
cially instrument panel), do not use
polish wax or polish cleaner. The
instrument panel may reflect off the
windshield, obstructing the driver ’s
view and leading to an accident,
resulting in death or serious injury.
NOTICE
zDo not wash the vehicle floor with
water, or allow water to get onto
the floor when cleaning the vehicle
interior or exterior. Water may get
into audio components or other
electrical components above or un-
der the floor carpet (or mat) and
cause a malfunction; and it may
cause body corrosion.
zWhen cleaning the interior, do not
use polish wax or polish cleaner.
The instrument panel’s or other in-
terior part’s painted surface may be
damaged.
Vinyl interior
The vinyl upholstery may be easily
cleaned with a mild soap or detergent
and water.
First vacuum over the upholstery to re-
move loose dirt. Then, using a sponge or
soft cloth, apply the soap solution to the
vinyl. After allowing it to soak in for a few
minutes to loosen the dirt, remove the dirt
and wipe off the soap with a clean damp
cloth. If all the dirt do not come off, re-
peat the procedure. Commercial foaming−
type vinyl cleaners are also available
which work well. Follow the manufacturer ’s
instructions.
NOTICE
Do not use solvent, thinner, gasoline
or window cleaner on the interior.
Seat belts
The seat belts may be cleaned with
mild soap and water or with lukewarm
water.
Use a cloth or sponge. As you are clean-
ing, check the belts for excessive wear,
fraying, or cuts.
NOTICE
zDo not use dye or bleach on the
belts—it may weaken them.
zDo not use the belts until they be-
come dry.
Windows
The windows may be cleaned with any
household window cleaner.
Dyna100/150_EE
Cleaning the interior

182CORROSION PREVENTION AND APPEARANCE CARE
Air conditioning control panel, audio
panel, instrument panel, console panel,
door switch panels, and switches
Use a soft damp cloth for cleaning.
Soak a clean soft cloth in water or luke-
warm water then lightly wipe off dirt.
NOTICE
zDo not use organic substances (sol-
vents, kerosene, alcohol, gasoline,
etc.) or alkaline or acidic solutions.
These chemicals can cause discol-
oring, staining or peeling of the
surface.
zIf you use cleaners or polishing
agents, make sure their ingredients
do not include the substances men-
tioned above.
zIf you use a liquid car freshener, do
not spill the liquid onto the ve-
hicle’s interior surfaces. It may con-
tain the ingredients mentioned
above. Immediately clean any spill
using the method mentioned above.
If you have any questions about the
cleaning of your Toyota, any authorized
Toyota dealer or repairer, or another
duly qualified and equipped profession-
al, will be pleased to answer them.
Dyna100/150_EE

MAINTENANCE REQUIREMENTS183
Section 6
MAINTENANCE REQUIREMENTS
DMaintenance facts 184.................................
DDoes your vehicle need repairing? 185..................
Dyna100/150_EE

184MAINTENANCE REQUIREMENTS
Regular maintenance is essential.
We urge you to protect your new vehicle
by having your Toyota serviced according
to the maintenance schedule given in the
separate booklet. Regular maintenance will
aid:
DGood fuel economy
DLong vehicle life
DDriving enjoyment
DSafety
DReliability
DWarranty coverage
DCompliance with government regula-
tions
Your Toyota has been designed for eco-
nomical driving and economical mainte-
nance. Many formerly required mainte-
nance items are no longer required or are
not required as often. To make sure your
vehicle runs at peak efficiency, follow the
maintenance schedule.
For full details of your maintenance
schedule, read the separate “Toyota
Service Booklet” or “Toyota Warranty
Booklet”.Where to go for service?
In order to maintain your vehicle in the
highest possible condition, Toyota recom-
mends that all repairs and service opera-
tions are carried out by authorized Toyota
dealers or repairers or other duly qualified
and equipped professionals. For repairs
and services covered by your warranty,
please visit an authorized Toyota dealer or
repairer, who will use genuine Toyota
parts in repairing any difficulties you may
encounter. There can also be advantages
to utilizing authorized Toyota dealers or
repairers for non−warranty repairs and
services, as due to their specialization of
working with Toyota vehicles, members of
the Toyota network will be able to expertly
assist you with any difficulties you may
encounter.
Your Toyota dealer or repairer, or another
duly qualified and equipped professional
service department will perform all of the
scheduled maintenance on your vehicle—
reliably and economically.
What about do−it−yourself maintenance?
Many of the maintenance items are easy
to do yourself if you have a little mechani-
cal ability and a few basic automotive
tools. Simple instructions for how to per-
form them are presented on page 187 in
Section 7.
Dyna100/150_EE
Maintenance facts

MAINTENANCE REQUIREMENTS185
Note, however, that some maintenance
tasks require special tools and skills.
These are best performed by qualified
technicians. Even if you’re an experienced
do−it−yourself mechanic, we recommend
that repairs and maintenance be con-
ducted by an authorized Toyota dealer or
repairer, or another duly qualified and
equipped professional. Any authorized
Toyota dealer or repairer will keep a
record of maintenance, which could be
useful should you ever require Warranty
Service. Should you choose to select a
qualified and equipped professional other
than an authorized Toyota repairer to
service or maintain your vehicle, we
recommend that you request that a record
of maintenance be kept.
The service interval for scheduled main-
tenance is determined by the odometer
reading or time interval, whichever
comes first, shown in the schedule.
Rubber hoses (for cooling and heater
system, brake system and fuel system)
should be inspected by a qualified tech-
nician in accordance with the Toyota
maintenance schedule.
They are particularly important mainte-
nance items. Have any deteriorated or
damaged hoses replaced immediately.
Note that rubber hoses will deteriorate
with age, resulting in swelling, chafing or
cracks.Be on the alert for changes in perfor-
mance, sounds, and visual tip−offs that
indicate service is needed. Some impor-
tant clues are as follows:
DEngine missing, stumbling, or pinging
DAppreciable loss of power
DStrange engine noises
DA leak under the vehicle (However, wa-
ter dripping from the air conditioning
after use is normal.)
DChange in exhaust sound (This may
indicate a dangerous carbon monoxide
leak. Drive with the windows open and
have the exhaustsystem checked im-
mediately.)
DFlat−looking tire; excessive tire squeal
when cornering; uneven tire wear
DVehicle pulls to one side when driving
straight on a level road
DStrange noises related to suspension
movement
DLoss of brake effectiveness; spongy
feeling brake or clutch pedal; pedal al-
most touches floor; vehicle pulls to one
side when braking
DEngine coolant temperature continually
higher than normal
If you notice any of these clues, take your
vehicle to any authorized Toyota dealer or
repairer, or another duly qualified and
equipped professional, as soon as pos-
sible. It probably needs adjustment or re-
pair.
CAUTION
Do not continue driving with the ve-
hicle unchecked. It could result in se-
rious vehicle damage and possibly se-
rious injury.
Dyna100/150_EE
Does your vehicle need
repairing?

186MAINTENANCE REQUIREMENTS
Dyna100/150_EE
