2012 TOYOTA AVALON Owners Manual

25
Symbols used throughout this manual
Cautions & Notices
CAUTION
This is a warning against anything which may cause injury to people if the
warning is ignored. You are informed about what you must or must not do in
order to reduce the risk of injury to yourself and others.
NOTICE
This is a warning against anything which may cause damage to the vehicle or
its equipment if the warning is ignored. You are informed about what you must
or must not do in order to avoid or reduce the risk of damage to your Toyota
and its equipment.

26
Symbols used in illustrationsSafety symbol
The symbol of a circle with a slash through it means “Do not”,
“Do not do this”, or “Do not let this happen”.
Arrows indicating operationsIndicates the action (pushing, turn-
ing, etc.) used to operate switches
and other devices.
Indicates the outcome of an opera-
tion (e.g. a lid opens).

Before driving1
27
1-1. Key informationKeys ................................... 28
1-2. Opening, closing and locking the doors and trunk
Smart key system .............. 30
Wireless remote control ..... 42
Doors ................................. 47
Trunk .................................. 54
1-3. Adjustable components (seats, steering wheel,
mirrors)
Front seats ......................... 59
Rear seats.......................... 61
Driving position memory system ............................. 63
Head restraints................... 67
Seat belts ........................... 70
Steering wheel ................... 78
Inside rear view mirror ....... 80
Outside rear view mirrors.............................. 82 1-4. Opening and closing the
windows and moon roof
Power windows .................. 85
Moon roof ........................... 88
1-5. Refueling Opening the fuel tank cap ................................... 92
1-6. Theft deterrent system Engine immobilizer system ............................. 96
Alarm.................................. 99
Theft prevention labels (U.S.A.) .......................... 103
1-7. Safety information Correct driving posture..... 104
SRS airbags ..................... 106
Front passenger occupant classification system ...... 119
Child restraint systems..... 125
Installing child restraints ........................ 130

28
1-1. Key information
Keys
Using the mechanical key (vehicles with smart key system)Take out the mechanical key.
After using the mechanical key,
store it in the electronic key. Carry
the mechanical key together with
the electronic key. If the electronic
key battery is depleted or the
smart key system does not oper-
ate properly, you will need the
mechanical key.
The following keys are provided with the vehicle.
Vehicles with smart key system
Electronic keys
• Operating the smart keysystem ( P. 30)
• Operating the wireless remote control function
( P. 42)
Mechanical keys
Key number plate
Vehicles without smart key system Master keys
Operating the wireless remote
control function (
P. 42)
Key number plate

29
1-1. Key information
1
Before driving
■
When required to leave a key to th e vehicle with a parking attendant
(Vehicles with smart key system)
Lock the glove box as circumstances demand. (P. 350)
Remove the mechanical key for your own use and provide the attendant with
the electronic key only.
■ Key number plate
Keep the plate in a safe place such as your wallet, not in the vehicle. In the
event that a key is lost, a new key can be made at your Toyota dealer using
the key number plate. ( P. 504)
■ When riding in an aircraft
When bringing a key onto an aircraft, make sure you do not press any but-
tons on the key while inside the aircraft cabin. If you are carrying a key in
your bag etc., ensure that the buttons are not likely to be pressed acciden-
tally. Pressing a button may cause the key to emit radio waves that could
interfere with the operation of the aircraft.
NOTICE
■To prevent key damage
●Do not disassemble the key.
● Do not subject the keys to strong shocks, expose them to high tempera-
tures by placing them in direct sunlight, or get them wet.
● Do not expose the keys to electromagnetic materials or attach any mate-
rial that blocks electromagnetic waves to the key surface.

30
1-2. Opening, closing and locking the doors and trunk
Smart key system
: If equipped
The following operations can be performed simply by carrying the
electronic key on your person, for example in your pocket.
(The driver should always carry the electronic key.)
Locks and unlocks the doors ( P. 3 1 )
Unlocks the trunk ( P. 3 1 )
Starts and stops the engine ( P. 154)
Electronic key
Electronic key
Electronic key

31
1-2. Opening, closing and locking the doors and trunk
1
Before driving
Unlocking and locking the doors
Grip the driver’s door handle to
unlock the door. Grip the passen-
ger’s door handle to unlock all
the doors.
*
Make sure to touch the sensor on
the back of the handle.
The door cannot be unlocked for
3 seconds after the door is
locked.
*: The door unlock settings can bechanged. ( P. 35)
Press the lock button to lock the
door.
Unlocking the trunk
Press the button to unlock the
trunk.

32 1-2. Opening, closing and locking the doors and trunk
Antenna location and effective range
■ Antenna location
Antennas outside cabin
Antenna outside trunk
Antenna inside trunk
Antennas inside cabin
