CHANGING THE TIRES
If you get a flat tire while driving, do not apply the brake heavily.
Instead, gradually decrease your speed. Hold the steering wheel firmly
and slowly move to a safe place on the side of the road.
Note:The tire pressure monitoring system (TPMS) indicator light will
illuminate when the spare tire is in use. To restore the full functionality
of the monitoring system, all road wheels equipped with tire pressure
monitoring sensors must be mounted on the vehicle.
Have a flat serviced by an authorized dealer in order to prevent damage to
the TPMS sensors, refer to Tire pressure monitoring system (TPMS) in
the Tires, Wheels and Loading chapter. Replace the spare tire with a road
tire as soon as possible. During repairing or replacing of the flat tire, have
the authorized dealer inspect the TPMS sensor for damage.
WARNING: The use of tire sealants may damage your tire
pressure monitoring system (TPMS) and should not be used.
However, if you must use a sealant, the TPMS sensor and valve stem on
the wheel must be replaced by an authorized Ford dealer.
WARNING: Refer toTire pressure monitoring system (TPMS)
in the Tires, Wheels and Loading chapter for important
information. If the tire pressure monitor sensor becomes damaged, it
will no longer function.
Dissimilar Spare Tire and Wheel Assembly Information
WARNING: Failure to follow these guidelines could result in an
increased risk of loss of vehicle control, injury or death.
If you have a dissimilar spare tire and wheel assembly , then it is
intended for temporary use only. This means that if you need to use it,
you should replace it as soon as possible with a road tire and wheel
assembly that is the same size and type as the road tires and wheels that
were originally provided by Ford. If the dissimilar spare tire or wheel is
damaged, it should be replaced rather than repaired.
A dissimilar spare tire and wheel assembly is defined as a spare tire or
wheel that is different in brand, size or appearance from the road tires
and wheels and can be one of three types:
1. T-type mini-spare: This spare tire begins with the letter “T” for tire
size and may have “Temporary Use Only” molded in the sidewall
Roadside Emergencies 287
2012 Focus Electric Vehicle(fob)
Owners Guide gf, 1st Printing
USA (fus)

A. Air compressor (inside)
B. Diverter knob
C. On/Off button
D. Air pressure gauge
E. Sealant bottle/canister
F. Sealant filling clear tube
G. Sealant tube – tire valve
connector
H. Yellow cap tool
I. Air compressor hose
J. Air hose – tire valve connector
K. Accessory power plug
L. Casing/housing
General Information
WARNING: Failure to follow these guidelines could result in an
increased risk of loss of vehicle control, injury or death.
Note: Do not use the temporary mobility kit if a tire has become
severely damaged by driving the vehicle with a tire that has insufficient
air pressure. Only punctured areas located within the tire tread can be
sealed with the temporary mobility kit.
Do not attempt to repair punctures larger than
14inch (6.4 mm) or
damage to the tire’s sidewall. The tire may not completely seal.
Loss of air pressure may adversely affect tire performance. For this
reason:
• Note: Do not drive the vehicle above 50 mph (80 km/h).
• Note: Do not drive further than 120 miles (200 km). Drive only to the
closest Ford Motor Company authorized dealer or tire repair shop to
have your tire inspected.
• Drive carefully and avoid abrupt steering maneuvers.
• Periodically monitor tire inflation pressure in the affected tire; if the
tire is losing pressure, have the vehicle towed.
• Read the information in the Tips for use of the temporary mobility
kit section to ensure safe operation of the temporary mobility kit and
your vehicle.
A
L
BCD
E
F
GHI
K
J
290 Roadside Emergencies
2012 Focus Electric Vehicle (fob)
Owners Guide gf, 1st Printing
USA (fus)

INSTRUMENT PANEL/INTERIOR TRIM AND CLUSTER LENS
Clean the instrument panel, interior trim areas and cluster lens with a
clean, damp, white cotton cloth, then use a clean and dry white cotton
cloth to dry these areas.
•Avoid cleaners or polishes that increase the gloss of the upper portion
of the instrument panel. The dull finish in this area helps protect the
driver from undesirable windshield reflection.
• Be certain to wash or wipe your hands clean if you have been in
contact with certain products such as insect repellent and suntan
lotion in order to avoid possible damage to the interior painted
surfaces.
• Do not use household or glass cleaners as these may damage the
finish of the instrument panel, interior trim and cluster lens.
• Do not allow air fresheners and hand sanitizers to spill on interior
surfaces. If a spill occurs, wipe off immediately.Damage may not be
covered by your warranty.
WARNING: Do not use chemical solvents or strong detergents
when cleaning the steering wheel or instrument panel to avoid
contamination of the airbag system.
If a staining liquid like coffee/juice has been spilled on the instrument
panel or on interior trim surfaces, clean as follows:
1. Wipe up spilled liquid using a clean, white, cotton cloth.
2. Wipe the surface with a damp, clean, white cotton cloth. For more
thorough cleaning, use a mild soap and water solution. If the spot cannot
be completely cleaned by this method, the area may be cleaned using a
commercially available cleaning product designed for automotive
interiors.
3. If necessary, apply more soap and water solution or cleaning product
to a clean, white, cotton cloth and press the cloth onto the soiled
area–allow this to set at room temperature for 30 minutes.
4. Remove the soaked cloth, and if it is not soiled badly, use this cloth to
clean the area by using a rubbing motion for 60 seconds.
5. Following this, wipe area dry with a clean, white, cotton cloth.
Cleaning 315
2012 Focus Electric Vehicle (fob)
Owners Guide gf, 1st Printing
USA (fus)

Multi-Point Inspection
In order to keep your vehicle running right, it is important to have the
systems on your vehicle checked regularly. This can help identify
potential issues and prevent major problems. Ford Motor Company
recommends the following multi-point inspection be performed at every
scheduled maintenance interval to help make sure your vehicle keeps
running great.
Multi-point inspection – Recommended each visit
Battery performance Radiator, cooler, heater and A/C hoses
Exterior lamps and hazard
warning system operation Suspension component for leaks or
damage
Fluid levels*; fill if necessary Tires for wear and proper pressure, including spare
For oil and fluid leaks Steering and linkage
Half-shaft dust boots
(if equipped) Windshield for cracks, chips or pits
Horn operation Washer spray and wiper operation
*Brake, coolant recovery reservoir and window washer
Be sure to ask your dealership service advisor or technician about the
multi-point vehicle inspection. It’s a comprehensive way to perform a
thorough inspection of your vehicle. It’s your checklist that gives you
immediate feedback on the overall condition of your vehicle. You’ll know
what’s been checked, what’s okay, as well as those things that may
require future or immediate attention. The multi-point vehicle inspection
is one more way to keep your vehicle running great!
Scheduled Maintenance 349
2012 Focus Electric Vehicle(fob)
Owners Guide gf, 1st Printing
USA (fus)

NORMAL SCHEDULED MAINTENANCE AND LOG
Normal Scheduled Maintenance
At every 1 year or
10,000 miles
(16,000 km) service
interval
1
Rotate tires, inspect tire wear and measure tread
depth
Perform multi-point inspection (recommended)
Inspect brake pads, shoes, rotors, drums, brake
linings, hoses and parking brake
Inspect cabin air filter (if equipped)
Inspect cooling system level, strength and hoses
Inspect half-shaft boots (if equipped)
Inspect steering linkage, ball joints, suspension,
tie-rod ends, driveshaft and U-joints; lubricate if
equipped with grease fittings
Inspect wheels and related components for
abnormal noise, wear, looseness or drag
Every 20,000 miles
(32,000 km) Replace cabin air filter (if equipped)
At 10 years or
150,000 miles
(240,000 km)
2
Change coolant and coolant filter*
1Do not exceed 1 year or 10,000 miles (16,000 km) between
service intervals
2Initial replacement at 10 years or 150,000 miles (240,000 km), then
every 5 years or 50,000 miles (80,000 km). The coolant must be
exchanged as indicated in the Ford Motor Company Workshop
Manual. If not performed properly, damage could occur to the cooling
system components. Only use pre-mixed coolant that meets Ford
Motor Company specifications found in the Maintenance and
Specifications chapter.
Scheduled Maintenance 351
2012 Focus Electric Vehicle(fob)
Owners Guide gf, 1st Printing
USA (fus)

C
Capacities for refilling fluids ....337
Cargo management system ......154
CD ................................................39
CD player ....................................74
CD voice commands ...................74
Cell phone use ............................13
Changing a tire .........................287
Child safety seats ......................212attaching with tether
straps .......................................219
in front seat ............................213
in rear seat ..............................213
LATCH .....................................216
recommendations ...................210
Child safety seats -
booster seats .............................221
Cleaning the touchscreen ..........51
Cleaning your vehicle engine compartment ..............313
instrument panel ....................315
interior .....................................316
plastic parts ............................314
washing ....................................312
waxing .....................................312
wheels ......................................313
wiper blades ............................314
Climate control (see Air
conditioning or Heating) ..........123
Climate voice commands .........111
Clock ..........................................101
Console ......................................140
Controls steering column ......................148
Coolant ......................................331 checking and adding ..............331 refill capacities ........................337
specifications ..........................337
Cruise control
(see Speed control) ..................146
Customer Assistance ................275 Ford Extended Service
Plan ..................................342, 345
Getting assistance outside
the U.S. and Canada ..............308
Getting roadside assistance ...275
Getting the service you
need .........................................304
Ordering additional owner’s
literature .................................310
Utilizing the
Mediation/Arbitration
Program ...................................308
D
Daytime running lamps
(see Lamps) ..............................129
Dipstick automatic transmission
fluid ..........................................334
Display settings .........................101
Doors central unlocking ....................161
Driving under special
conditions ..................................266 through water .........................274
E
Emergencies, roadside jump-starting ..........................299
End user license agreement ....356
Engine cleaning ...................................313
service points ..........................320
Index 375
2012 Focus Electric Vehicle (fob)
Owners Guide gf, 1st Printing
USA (fus)

Engine fan .................................320
Event data recording ..................11
F
Fan, Engine Cooling .........318, 320
Fleet MyKey programming ......155
Floor mats .........................152, 154
Fluid capacities .........................337
Fuses ..................................278–279
G
Garage door opener ..................148
Gauges .........................................20
H
Hazard flashers .........................276
HD Radio™ .................................64
Headlamps .................................128aiming ......................................130
autolamp system .....................128
bulb specifications ..................134
daytime running lights ...........129
flash to pass ............................129
high beam ...............................129
replacing bulbs .......................135
turning on and off ..................128
Head restraints .........................173
Heated steering wheel ..............109
Heating heating and air conditioning
system .....................................123
Help ............................................108
High-voltage battery charging ...................................325 service disconnect ..................330
High-voltage shut off ................277
Hill start assist ..........................265
Homelink wireless control
system ........................................149
Hood ..........................................319
How to use voice commands .....56
I
Ignition .......................................252
Illuminated visor mirror ...........140
Infant seats
(see Safety seats) .....................212
Infotainment display ...................54
Instrument panel cleaning ...................................315
cluster ........................................16
lighting up panel and
interior .....................................130
Intelligent Access Key ..............155
Intelligent Access with push
button start ...............................164
J
Jack ............................................287 positioning ...............................287
storage .....................................287
Jump-starting your vehicle ......299
K
Keyless entry system autolock ...................................162
Keys ...........................................171 positions of the ignition .........252
376 Index
2012 Focus Electric Vehicle (fob)
Owners Guide gf, 1st Printing
USA (fus)

Power mirrors ...........................144
Powerpoint ................................141
Power steering ..........................261
Power Windows .........................142
Privacy information ....................53
Push button start system .........253
Q
Quick touch buttons .................120
R
Radio ............................................39AM/FM .......................................62
Single CD ..................................39
Radio voice commands ...............68
Rear view camera display ........102
Rear-view camera system .........268
Receiving a text message ...........87
Recommendations for
attaching safety restraints for
children ......................................210
Relays ........................................278
Remote entry system .......163–164 illuminated entry ............167–168
locking/unlocking doors .165–166
opening the trunk ...................166
replacement/additional
transmitters .............................167
replacing the batteries ...........166
Reverse sensing system ...........266
Roadside assistance ..................275
Route preferences ....................116 S
Safety belts (see Safety
restraints) ..................185–187, 189
Safety defects, reporting ..........311
Safety information ......................51
Safety restraints ........185–187, 189
Belt-Minder ...........................190
extension assembly ................189
for adults .........................186–187
for children .............................208
Occupant Classification
Sensor ......................................183
warning light and chime ........190
Safety restraints -
LATCH anchors .........................216
Safety seats for children ..........212
Safety Compliance
Certification Label ....................338
Satellite Radio .............................69
Satellite Radio Information ........45
Scheduled Maintenance Guide Normal Scheduled
Maintenance and Log .............351
SD card ................................75, 112
Seats ..........................................173 child safety seats ....................212
heated ......................................178
SecuriLock passive anti-theft
system ........................................170
Sending new text messages .......87
Servicing your vehicle ..............318
Setting a destination ................112
Setting a destination by
voice ...........................................113
Setting the clock .......................101
378 Index
2012 Focus Electric Vehicle (fob)
Owners Guide gf, 1st Printing
USA (fus)
