2012 Citroen C5 RHD Owner's Manual

303

QUESTION



ANSWER



SOLUTION


TA is selected. However,
certain traffi c jams
along the route are not
indicated in real time. On starting, it is several minutes before the system begins to receive
the traffi c information. Wait until the traffi c information is being received
correctly (displaying of the traffi c information
symbols on the map).
In certain countries, only major routes (motorways...) are listed for
the traffi c information. This phenomenon is normal. The system is
dependent on the traffi c information available.
I receive a speed camera
alert for a camera which
is not on my route. The system announces all speed cameras located in a conical zone
forward of the vehicle. It may detect speed cameras on nearby or parallel
roads. Zoom the map to view the exact position of the
speed camera.
The audible speed
camera alert is not
working. Audible alerts are not active. Activate audible alerts in Navigation Menu,
Settings, Set parameters for risk areas.
The alert volume level is set to minimum. Increase the speed camera alert volume.
The altitude is not
displayed. On starting, the initialisation of the GPS may take up to 3 minutes to
receive more than 3 satellites correctly. Wait until the system has started up completely.
Check that there is a GPS coverage of at least
3 satellites (long press on the SETUP button,
then select GPS coverage).
Depending on the geographical environment (tunnel...) or the weather,
the conditions of reception of the GPS signal may vary. This phenomenon is normal. The system is
dependent on the conditions of reception of
the GPS signal.
The route is not
calculated successfully. The exclusion criteria may confl ict with the current location
(exclusion of toll roads on a motorway with tolls). Check the exclusion criteria.

304

QUESTION



ANSWER



SOLUTION


There is a long waiting
time after inserting a CD. When a new medium is inserted, the system reads a certain amount of
data (directory, title, artist, etc.). This may take a few seconds. This phenomenon is normal.
I cannot connect my
Bluetooth telephone. The telephone's Bluetooth function may be deactivated or the equipment
may not be visible.

- Check that your telephone's Bluetooth
function is activated.

- Check that your telephone is visible.
A telephone connected
by Bluetooth is inaudible. The volume level depends on both the system and the telephone. Increase the MyWay volume setting, possibly to
maximum, and increase the telephone volume
level if necessary.

305
AUDIO SYSTEM


Your Audio system is coded in such a way that it will
only operate in your vehicle. If it is to be installed in
another vehicle, contact your CITROËN dealer for
confi guration of the system.

For safety reasons, the driver must carry out operations
which require prolonged attention while the vehicle is
stationary.
When the engine is switched off and to prevent
discharging of the battery, the audio equipment may
switch off after a few minutes.



AUDIO SYSTEM/BLUETOOTH

01 First steps

02 Steering mounted controls

03 Main menu

04 Audio

05 USB Box

06 Bluetooth functions

07 Configuration

08 Trip computer

09 Screen menu map

Frequently asked questions p.
p.
p.
p.
p.
p.
p.
p.
p.
p. 306
307
308
309
312
315
317
318
319
323
CONTENTS

306
01
1 2
1011
13 14 153456 789
12
FIRST STEPS








1. On/Off and volume adjustment.

2. CD eject.

3. Selection of the display on the screen from
the following modes:
Audio (AUDIO), Trip Computer (TRIP) and
Telephone (TEL) functions.

4. Selection of source:
radio, audio CD/MP3 CD, USB, Jack
connection, Streaming.

5. Selection of FM1, FM2, FMast and AM
wavebands.

6. Setting audio options: front/rear fader, left/
right balance, loudness, sound ambience.
7. Display the list of local stations, of the tracks
on the CD or of the MP3 folders.

8. Abandon current operation.

9. TA (Traffi c Announcement) function on/off.
Long press: access to the PTY (Types of radio
programme) mode.

10. Confi rmation.

11. Automatic search for a lower/higher frequency.
Selection of previous/next CD, MP3 or USB
track.
12. Selection of a lower/higher radio frequency.
Selection of the previous/next MP3 folder.
Selection of the previous/next USB device
folder/genre/artist/playlist.

13. Display the main menu.

14. Buttons 1 to 6:
Selection of a stored radio station.
Long press: store a station.

15. The DARK button changes the display on the
screen to improve driving comfort at night.
1st press: lighting the upper band only.
2nd press: display of a black screen.
3rd press: return to the standard display.

307
02
LISTMENU
1
2
4
3
5
6
7
8
9
9
10
STEERING MOUNTED CONTROLS












1. Activation/deactivation of the
Black Panel mode (night driving).
3. Access to the short-cut menus depending on the display
on the screen.
Confi rmation of the function selected from a menu.
Rotation:
Selection of the previous/next stored RADIO station.
Selection of the previous/next CD or MP3 directory.

4. Abandon the current operation.
Reject an incoming call.
Long press: return to the main display.

5. Access to the main menu.

6. Volume increase.

7. Volume decrease.

8. Mute.

9. RADIO: automatic search for a lower/higher frequency.
CD/MP3:
selection of the previous/next track.
continuous press: fast forward/rewind play.

10. RADIO: display the list of stations available.
Long press: update the list of radio stations.
CD/MP3:
display the list of CD and folder tracks.

2. Pick up an incoming call/end a call
which is in progress.
Open the telephone menu and
display the calls list.
Long press: reject an incoming
call.

308
03 MAIN MENU



AUDIO FUNCTIONS
: radio,
CD, USB, options.


TRIP COMPUTER
: entering of
distances, alerts, status of functions.

TELEPHONE
: Bluetooth
hands-free, pairing,
management of a call.


PERSONALISATION-
CONFIGURATION
: vehicle
parameters, display, languages.







> MONOCHROME SCREEN C










> MONOCHROME SCREEN A


For a detailed global view of the
menus available, refer to the
"Screen menu map" section.

309
04
1
2
3
4
1
2
3
4
AUDIO

Press the SOURCE button several
times in succession and select the
radio.

Press the BAND AST button to select
a waveband: FM1, FM2, FMast, AM.

Briefl y press one of the buttons to
carry out an automatic search of the
radio stations.

Press one of the buttons to carry
out a manual search of the radio
stations.

Press the LIST REFRESH button to
display the list of stations received
locally (30 stations maximum).
To update this list, press for more
than two seconds.
The external environment (hills, buildings, tunnels, basement car parks, ...)
may block reception, including in RDS mode. This is a normal effect of the
way in which radio waves are transmitted and does not indicate any failure
of the audio equipment.

RDS





RADIO

SELECTING A STATION
Select AUDIO FUNCTIONS then
press OK. Press the MENU button.
Select ACTIVATE RDS then press OK.
RDS appears on the screen. Select the FM WAVEBAND
PREFERENCES function then
press OK.
The RDS, if displayed, enables you to continue listening to the
same station by automatic retuning to alternative fequencies.
However, in certain conditions, coverage of an RDS station may
not be assured throughout the country as radio stations do not
cover 100 % of the territory. This explains the loss of reception of
the station during a journey.

310
04
1
2
3
1
AUDIO


Insert circular compact discs only.
Some anti-pirating systems, on original discs or CDs copied using a
personal recorder, may cause faults which are no refl ection on the
quality of the original player.
Without pressing the EJECT button, insert a CD in the player, play
begins automatically.


CD
PLAYING A CD


To play a disc which has already been
inserted, press the SOURCE button
several times in succession and
select CD.

Press one of the buttons to select a
track on the CD.

Press the LIST REFRESH button to display the list of tracks on
the CD.

Press and hold one of the buttons for
fast forward or backward.








RECEIVING TA MESSAGES


Press the TA button to activate or
deactivate traffi c messages.

The TA (Traffi c Announcement) function gives priority to TA alert
messages. To operate, this function needs good reception of a
radio station transmitting this type of message. When a traffi c
report is transmitted, the current audio source (Radio, CD, ...) is
interrupted automatically to play the TA message. Normal playback
of the audio source resumes at the end of the transmission of the
message.
