97 1-6. Theft deterrent system
1
Before driving
AVALON_U (OM41428U)
■Panic mode
Vehicles with smart key system
Vehicles without smart key system
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.
When is pushed for longer than
about one second, an alarm will sound for
about 60 seconds and the vehicle lights
will flash to deter any person from trying
to break into or damage your vehicle.
To stop the alarm, push any button on the
wireless remote control.

111 1-7. Safety information
1
Before driving
AVALON_U (OM41428U)
CAUTION
■SRS airbag precautions
●Do not attach anything to or lean any-
thing against areas such as the dash-
board, steering wheel pad or lower
portion of the instrument panel. These
items can become projectiles when
SRS driver, front passenger and knee
airbags deploy.
●Do not attach anything to areas such as
the door, windshield glass, side door
glass, front and rear pillars, roof side
rail or assist grip.
●Do not hang coat hangers or other hard
objects on the coat hooks. All of these
items could become projectiles and
seriously injure or kill you, should the
SRS curtain shield airbag deploy.
●Vehicles without smart key system: Do
not attach any heavy, sharp or hard
objects such as keys or accessories to
the key. The objects may restrict the
SRS knee airbag inflation or be thrust
into the driver’s seat area by the force
of the deploying airbag, thus causing a
danger.

When driving2
137
AVALON_U (OM41428U)
2-1. Driving procedures
Driving the vehicle............ 138
Engine (ignition) switch
(with smart key
system) .......................... 149
Engine (ignition) switch
(without smart key
system) .......................... 153
Automatic
transmission................... 156
Turn signal lever .............. 161
Parking brake ................... 162
Horn ................................. 1632-2. Instrument cluster
Gauges and meters ......... 164
Indicators and warning
lights .............................. 167
Multi-information
display............................ 170
2-3. Operating the lights and
windshield wipers
Headlight switch ............... 173
Fog light switch ................ 176
Windshield wipers and
washer ........................... 177
2-4. Using other driving systems
Cruise control ................... 182
Rear view monitor
system ........................... 186
Driving assist systems ..... 195
2-5. Driving information
Cargo and luggage .......... 200
Vehicle load limits ............ 205
Winter driving tips ............ 207
Trailer towing ................... 212
Dinghy towing .................. 213

138
AVALON_U (OM41428U)
2-1. Driving procedures
Driving the vehicle
The following procedures should be observed to ensure safe driv-
ing.
■Starting the engine
P. 149, 153
■Driving
With the brake pedal depressed, shift the shift lever to “D”.
(P. 156)
Release the parking brake. (P. 162)
Gradually release the brake pedal and gently push the
accelerator pedal to accelerate the vehicle.
■Stopping
With the shift lever in “D”, push the brake pedal.
If necessary, set the parking brake.
When the vehicle is stopped for an extended period of time, shift
the shift lever to “P”. (
P. 156)
■Parking the vehicle
With the shift lever in “D”, push the brake pedal.
Set the parking brake. (P. 162)
Shift the shift lever to “P”. (P. 156)
Stop the engine.
Lock the door, making sure that you have the key on your
person.

149
2-1. Driving procedures
2
When driving
AVALON_U (OM41428U)
Engine (ignition) switch (with smar t key system)
Performing the following operations when carrying the electronic
key on your person starts the engine or changes “ENGINE START
STOP” switch modes.
■Starting the engine
Check that the parking brake is set.
Check that the shift lever is set in “P”.
Sit in the driver’s seat and firmly depress the brake pedal.
The “ENGINE START STOP” switch indicator turns green.
Press the “ENGINE START
STOP” switch.
The engine can be started
from any mode.

151 2-1. Driving procedures
2
When driving
AVALON_U (OM41428U)
■When the steering lock cannot be released
■If the engine does not start
The engine immobilizer system may not have been deactivated. (P. 91)
■When the “ENGINE START STOP” switch indicator flashes in amber
The system may be malfunctioning. Have the vehicle inspected by your
Toyota dealer immediately.
■Auto power OFF function
The “ENGINE START STOP” switch will automatically turn OFF when left in
ACCESSORY mode for 1 hour or more.
■Electronic key battery depletion
P. 3 2
■When the electronic key battery is discharged
P. 428
■Conditions affecting operation
P. 3 0
The green indicator light on the “ENGINE
START STOP” switch will flash. Press the
“ENGINE START STOP” switch again
while turning the steering wheel slightly in
either direction.

153
2-1. Driving procedures
2
When driving
AVALON_U (OM41428U)
Engine (ignition) switch (without smar t key system)
■Starting the engine
Check that the parking brake is set.
Check that the shift lever is set in “P”.
Sit in the driver’s seat and firmly depress the brake pedal.
Turn the engine switch to the “START” position and start
the engine.
■Engine (ignition) switch
“LOCK”
The steering wheel is locked
and the key can be removed.
(The key can be removed only
when the shift lever is in “P”.)
“ACC”
Some electrical components
such as the audio system can
be used.
“ON”
All electrical components can
be used.
“START”
For starting the engine.

154 2-1. Driving procedures
AVALON_U (OM41428U)
■Turning the key from “ACC” to “LOCK”
Shift the shift lever to “P”.
■When the steering lock cannot be released
■If the engine does not start
The engine immobilizer system may not have been deactivated. (P. 91)
■Key reminder function
A buzzer sounds if the driver’s door is opened, while the engine switch is in
the “ACC” or “LOCK” position to remind you to remove the key.
Push in the key and turn to the “LOCK”
position.
When starting the engine, the engine
switch may seem stuck in the “LOCK”
position. To free it, turn the key while turn-
ing the steering wheel slightly in either
direction.
