2011 TOYOTA AVALON cruise control

1
2
3
4
5
6
7
3
AVALON_U (OM41428U)
2-1. Driving procedures
Driving the vehicle............... 138
Engine (ignition) switch
(with smart key
system) ............................. 149
Engine (ignition) switch
(without smart key
system) ............................. 153
Automatic transmission ....... 156
Turn signal lever ................. 161
Parking brake ...................... 162
Horn .................................... 163
2-2. Instrument cluster
Gauges and meters ............ 164
Indicators and warning
lights ................................. 167
Multi-information display ..... 170
2-3. Operating the lights and
windshield wipers
Headlight switch .................. 173
Fog light switch ................... 176
Windshield wipers and
washer .............................. 1772-4. Using other driving systems
Cruise control ..................... 182
Rear view monitor
system .............................. 186
Driving assist systems ........ 195
2-5. Driving information
Cargo and luggage ............. 200
Vehicle load limits............... 205
Winter driving tips ............... 207
Trailer towing ...................... 212
Dinghy towing ..................... 213
2When driving

15
AVALON_U (OM41428U)
Audio remote control switches P. 274
Engine (ignition) switch
(vehicles without smart key
system)
P. 153
: If equipped
*: Refer to “Navigation System Owner’s Manual”.
Telephone switch P. 281
Engine (ignition) switch
(vehicles with smart key system)
P. 149
Climate remote control
switches
P. 224
Talk switch* P. 281
“DISP” switch P. 170
Cruise control switch P. 182

19
AVALON_U (OM41428U)
Installation of a mobile two-way radio system
As the installation of a mobile two-way radio system in your vehicle could
affect electronic systems such as the multiport fuel injection system/sequen-
tial multiport fuel injection system, electronic throttle control system, cruise
control system, vehicle stability control system, SRS airbag system and seat
belt pretensioner system, be sure to check with your Toyota dealer for pre-
cautionary measures or special instructions regarding installation.
Scrapping of your Toyota
The SRS airbag and seat belt pretensioner devices in your Toyota contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by your Toyota
dealer before you scrap your vehicle.
Perchlorate Material
Special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These compo-
nents may include airbag, seat belt pretensioners, and wireless remote con-
trol batteries.

When driving2
137
AVALON_U (OM41428U)
2-1. Driving procedures
Driving the vehicle............ 138
Engine (ignition) switch
(with smart key
system) .......................... 149
Engine (ignition) switch
(without smart key
system) .......................... 153
Automatic
transmission................... 156
Turn signal lever .............. 161
Parking brake ................... 162
Horn ................................. 1632-2. Instrument cluster
Gauges and meters ......... 164
Indicators and warning
lights .............................. 167
Multi-information
display............................ 170
2-3. Operating the lights and
windshield wipers
Headlight switch ............... 173
Fog light switch ................ 176
Windshield wipers and
washer ........................... 177
2-4. Using other driving systems
Cruise control ................... 182
Rear view monitor
system ........................... 186
Driving assist systems ..... 195
2-5. Driving information
Cargo and luggage .......... 200
Vehicle load limits ............ 205
Winter driving tips ............ 207
Trailer towing ................... 212
Dinghy towing .................. 213

159 2-1. Driving procedures
2
When driving
AVALON_U (OM41428U)■Shift ranges and their functions
●Automatically selecting gears between 1 and 6 according to
vehicle speed and driving condition. (However the gear is limited
according to selected shift range.)
●You can choose from 6 levels of engine braking force.
●A lower shift range will provide greater engine braking force than
a higher shift range, and the engine speed will also increase.
■S mode
●When the shift range is 5 or lower, holding the shift lever toward “+” sets
the shift range to 6.
●To prevent excessive engine speed, a function was adopted that auto-
matically selects a higher shift range before engine speed becomes too
high.
●To protect the automatic transmission, a function is adopted that auto-
matically selects a higher shift range when the fluid temperature is high.
■Down shifting restrictions warning buzzer (in the S mode)
To help ensure safety and driving performance, downshifting operation may
sometimes be restricted. In some circumstances, downshifting may not be
possible even when the shift lever is operated. (The warning buzzer will
sound twice.)
■When driving with the cruise control system
Engine braking will not occur in the S mode, even when downshifting to 5 or
4. (P. 182)
■If the shift lever cannot be shifted from P
P. 491

168 2-2. Instrument cluster
AVALON_U (OM41428U)
■Indicators
The indicators inform the driver of the operating state of the
vehicle’s various systems.
*1: These lights turn on when the “ENGINE START STOP” switch is
turned to IGNITION ON mode (vehicles with smart key system) or
the engine switch is turned to the “ON” position (vehicles without
smart key system) to indicate that a system check is being per-
formed. They will turn off after the engine is started, or after a few
seconds. There may be a malfunction in a system if the lights do not
come on, or turn off. Have the vehicle inspected by your Toyota
dealer.
*2: The light flashes to indicate that the system is operating.
Turn signal indicator
(P. 161)Cruise control indicator
(P. 182)
Headlight high beam
indicator (P. 174)Slip indicator (P. 195)
(U.S.A.)
Headlight indicator
(P. 173)VSC OFF indicator
(P. 195)
(Canada)
Tail light indicator
(P. 173)
(U.S.A.)
TRAC OFF indicator
(P. 196)
Security indicator
(P. 91, 94)
(Canada)
TRC OFF indicator
(P. 196)
Shift position and shift
range indicators
(P. 156)
SRS airbag on-off
indicator (P. 114)
“SET” indicator
(P. 182)
*1, 2
*1
*1

182
AVALON_U (OM41428U)
2-4. Using other driving systems
Cruise control
Use the cruise control to maintain a set speed without using the
accelerator.
Indicator
Cruise control switch
■Set the vehicle speed
Press the “ON-OFF” button to
activate the cruise control.
Press the button once more to
deactivate the cruise control.
Accelerate or decelerate the
vehicle to the desired speed,
and push the lever down to set
the speed.
“SET” indicator will come on.

184 2-4. Using other driving systems
AVALON_U (OM41428U)
■Cruise control can be set when
●The shift lever is in the “D” or range “4” or higher of “S” has been
selected.
●Vehicle speed is above approximately 25 mph (40 km/h).
■Accelerating
The vehicle can be accelerated normally. After acceleration, the set speed
resumes.
■Canceling and resuming regular acceleration
Pulling the lever toward you
cancels the constant speed
control.
The speed setting is also can-
celed when the brakes are
applied.
Pushing the lever up
resumes the constant
speed control.
Resuming is available when
the vehicle speed is more than
approximately 25 mph (40
km/h).
